Seite 1/31
User Guide
MRB3
Bluetooth® Media Controller
Corporate: SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
Web: www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,Inc. and any use of such
marks by SSV Works is under license. © 2016 SSV Works, Oxnard, CA 93030 MRB3 Rev. B 3-22-16
Do not attempt to disassemble or repair the MRB3 yourself. Please call SSV Works for
technical assistance or repair information. Changes or modications to the MRB3 not
authorized by SSV Works will void the warranty.
SSV Works recommends disconnecting the negative battery terminal before
beginning any installation.
SAFETY INFORMATION
!
RADIO FUNCTIONS
CONNECTING AN EXTERNAL AUDIO DEVICE (OPTIONAL)
BLUETOOTH AUDIO STREAMING
MRB3
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship. All
SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship. Labor for
replacement of defective components is not covered. All SSV Works Speakers are covered by a limited 1 year warranty
against defects in material or workmanship. Contact SSV Works for further warranty information.
Selecting FM/AM Band: Press until the FM or AM band shows on the display. MODE
Automatic Station Search: Press or to start automatic station search. The search
stops when a station is found.
Manual Station Search: Press and hold or until M - SEEK. Press the or
briey to change the frequency until the desired frequency is set. Change to Automatic
search (A - SEEK) mode after a station is found.
- Press until AUX shows on the display.MODE
Add 3.5mm AUX-in
and USB Charging with
SSV Works 3PUSB35A
(sold separately)
1. Open the Bluetooth setup program on the mobile device and activate the Bluetooth feature
2. The device will show up as “SSV”. Select this device and enter passkey: OOOO
3. After successfully pairing, a Bluetooth logo will appear on the phone menu screen and
show “CONNECT” “BT MUSIC” on the device LCD display.
Stop Playback: Press briey to pause music. Press button again to continue playback.
Skip Track: Press or to play previous/next song.
Line in
MRB3
1. Play/Pause
Power On/Off
Mute
2. Volume Up/Down
3. Mode
4. Track Forward/Back
Station Forward/Back
Menu Settings Up/Down
5. LCD Display
BUTTON LOCATIONS AND FUNCTIONS
GENERAL OPERATIONS
1
5
3 42
AMPLIFIER WIRING DIAGRAM
12v+ Yellow
does not read
USB data
USB 1A charge input
Signal ground
(Black)
AMP turn on
(Blue)
Power On/Off: Press to power on. Press and hold to power off.
Volume: Press the VOL(+) (-)or button to increase or decrease the volume.
Mute On/Off: Press again to un-mute the sound. briey to mute the sound. Press
Mode Sources: Press the button to switch between AUX, FM, AM, Bluetooth (BT MUSIC).MODE
Mode Settings (Bass/Treble/Balance/Fader/EQ/Loudness): Press the button for MODE
2 seconds and then press the button until the function you want is shown on the display.
Press to change the settings of the menu item displayed.VOL(+) (-)
Bass (BAS)/Treble (TRE): Press the button to adjust Bass & Treble.VOL(+) or (-)
Balance (BAL): Press VOL(+) or (-) to adjust balance (sound distribution between the right and
left speakers).
Fader (FAD): Press VOL(+) or (-) to adjust sound distribution between the front and rear speakers.
Equalizer (EQ): Press or to select one of the EQ options: OFF, FLAT, CLASS, POP, VOL(+) (-)
ROCK, JAZZ, METAL. The equalizer will be disabled if EQ OFF is set. The equalizer setting is shown
at the bottom of the display.
Loudness (LOUD): Press (LOUD ON) or to disable the function (LOUD OFF). When VOL(+) or (-)
the loudness function is on, LOUD is shown on the right of the display.
2 sec.
MODE BASS TRE BAL FAD EQ LOUD
Disassembly, Wire and
Amplier Plate Installation
Glovebox Subwoofer
Installation
Kick Panel Speakers
Installation
MRB3 and Dash Kit
Installation
pg 2
pg 9
pg 17
pg 21
