Assembly and Disassembly Instructions
for Trampoline and Enclosure
Two people are required for assembly. Installation
typically takes two hours to complete.
Keep small children at least 25  (7.5 m) away while
assembling the trampoline; they could be injured by
improperly assembled rods releasing and ejecting
from the frame.
Do not attempt to use the trampoline until it is
completely assembled.
Be aware that when loaded, the rods can spring back
and may cause injury. Keep your face well clear of
the rods during assembly or disassembly. An
improperly installed rod could release and cause
facial injury or blindness.
The sleeves on the rods are intended to provide
protection from fibres or splinters. Do not remove. If
they are damaged, replace them.
Maintain a minimum clearance of 16.5 . (5 m) above
the mat [in USA and Canada, 24  (7.3 m) above the
trampoline from ground level] in order to prevent
users from inadvertently contacting overhead
hazards such as electric wires, tree limbs or
clothesline.
Maintain a minimum clearance of 5  (1.5 m) [in EU
countries, 6.5  (2.0 m)] on all sides of the trampo-
line. This area should not include concrete, bitumen,
brick or other hard surfaces or be in the proximity of
other conflicting installations (e.g. pools, swings,
slides, climbing frames) as these can cause serious
injuries if users fall o the trampoline.
A.
B.
C.
D.
E.
F.
G.
Do not locate the trampoline on top of other
objects or store anything underneath the
trampoline bed.
Place the trampoline in a well-lit area.
Record the date of purchase on the enclosure label
in the space provided.
Only use approved Springfree® Trampoline
accessories, and install in accordance to installa-
tion instructions. Do not make modifications to the
trampoline or accessories.
Secure the trampoline against unauthorized and
unsupervised use.
The owner and supervisors of the trampoline are
responsible to make all users aware of practices
specified in the User Guide.
Trampoline enclosure is supplied as part of the
trampoline. Do not install enclosures that are not
suited to your product.
The trampoline is intended for indoor/outdoor
usage. Refer to Trampoline location information in
the User Guide for more details.
Use only with mature, knowledgeable supervision.
Enforce all safety rules.
Record the purchase date of your trampoline on
the net serial number tag. It is located under the net
warnings, which are sewn into the edge of the net
next to the entrance.
H.
I.
J.
K.
L.
M.
N.
O.
P.
Q.
WARNING Please read the following precautions carefully
before beginning the assembly process. Retain for
future reference. 1
2
Lay out the parts as shown.
Black Net Rods
Spare Small Bolt & Nut
Spare C-clips
Part Qua ity Part Qu titynt an
Mat
White Mat Rods
Net
1
32
1
8
1
3
D.
E.
F.
A.
B.
C.
SCAN HERE
or visit for a helpful installation overview video.http://springfr.ee/g4-install-ov
Part Qua ity Part Qu titynt an
C-clips (Attached to Frame)
Small Bolts & Nuts
Large Bolts & Nuts
Curved Frame Sections
Legs
Center Posts
Wrenches
A.
B.
C.
D.
E.
F.
G.
4
4
4
2
8
8
4
Lay out the remaining parts as shown. The colored stickers all face upwards.
If you are missing any parts please contact Springfree Trampoline directly.
WARNING - Use the tools provided to fasten the nuts. Do not over tighten the nuts. Do not use
power driver, torque wrench, or drill.
SCAN HERE or visit for a helpful installation video for Step 2.http://springfr.ee/g4-step-2
3
TIP - Fastening the final two frame sections oen requires additional eort. Two people are
required for assembly.
TIP - When installing the legs, it is easiest when one person to holds the frame up and horizontal
while the other person inserts the legs into the leg sockets.
Position the frame sections together.
Connect and fasten frame sections using the large nuts and bolts. When finished, the bolt head should be
flush with the frame and the nut should face the center of the trampoline.
Attach a center post to the middle of each leg section.
Then, in the order shown, carefully li the frame and evenly insert the legs into the leg sockets on the
underside of the frame.
Fasten each leg to the frame using the small nuts and bolts before going to the next leg.
The information in this document is subject to change without notice.
© Copyright Springfree® Trampoline Inc. 2005, 2019. All rights reserved.
762602
6  (1.85 m)
MAT
DIAMETER
175 lbs (80 kg)
MAXIMUM USER
WEIGHT
2.6  (0.8 m)
MAT HEIGHT FROM
GROUND
5  (1.5 m)
MINIMUM NET HEIGHT
FROM MAT
4
Lay out the mat with the yellow stripes facing upwards inside the trampoline frame.
The blue tags on the mat should approximately align with the blue stickers on the frame.
Before moving to the next step, ensure that the mat rod holders are correctly positioned with the mat
rod holder tag outside the mat rod holder pocket, as per the insert. If the mat rod holder tag is under
the pocket, adjust accordingly.
5
NOTE - As you install the white mat rods into the mat rod sockets the net will become tight
against the frame. Handle the net with care and be sure that it does not get caught or it may tear.
Locate the blue tag on the bottom edge of the net and match it with any blue sticker on your trampo-
line frame.
Holding the net so that the blue tag is facing you, gently place the rest of the net inside the frame as
shown. DO NOT let go of the blue tag.
Put a white mat rod through the hole to the immediate le of the blue tag in the net and then into the
mat rod socket next to the blue sticker.
Then, working carefully around the frame, insert the remaining white mat rods through the net holes and
into the corresponding mat rod socket. When finished, the net should be stretched tightly around the
OUTSIDE of the frame.
Be sure that the white mat rods are seated down to the bottom of each mat rod socket.
SCAN HERE or visit for a helpful installation video for Step 5.http://springfr.ee/g4-step-5
6a
Check that the center posts of the leg sections are correctly seated under the trampoline frame. If they
are not, adjust them now.
To install the mat, begin by attaching one white mat rod at each location where the blue tags on the
mat match with the blue stickers on the frame.
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or
uninstalled. Keep your face well away from any loaded rod.
WARNING - Both people must maintain a steady grip on the rod until it is securely installed in
the mat rod holder.
NOTE - Before you install the first white mat rod into a mat rod holder, read the instructions in
Step 6b and 6c.
NOTE - Following the sequence shown spreads the tension evenly across the mat. If you do not
follow this sequence, it will be very diicult to attach the mat.
TOP VIEW
KG
LBS
0-6
The Maximum User Weight for this
trampoline is located on the front
panel of this manual. Jumpers at or
near the Maximum User Weight should
take extra precautions in their
manoeuvres to ensure they do not
initiate contact with the ground while
jumping as this can cause serious
injury.
Entrapment and choking hazard
possible for children under 6 years of
age.
No more than one person at a time.
Multiple jumpers increase the chances
of loss of control and collision and can
result in serious head, neck, back, leg,
arm or other injuries.
Treat any loaded rod with caution
until you are sure it is properly
installed or uninstalled. Keep face
clear of loaded rods. An improperly
installed rod could release and cause
facial injury or blindness.
Never attempt to remove a black net
rod from its net pocket or disengage
(unlock) the rod sleeve while the black
net rod is under tension.
No somersaults or flips. Landing on
the head or neck can cause serious
injury, paralysis, or death, even when
landing in the middle of the bed.
WARNING Read the warnings on this page and those
contained in the User Guide before you assemble
and use the trampoline and enclosure.
Do not hold onto, or place fingers
between the rods while someone is
jumping on the trampoline.
If you anticipate severe weather,
consider lowering the enclosure,
moving the trampoline to a sheltered
location or disassembling the trampo-
line completely.
E F GD
A
C
D
B
1 2
3
4
E F
START HERE
INSTALLATION VIDEOS
1
When installing your trampoline it’s
important to follow the instructions
carefully, so we’ve created a series of
step-by-step installation videos to
help. To watch, simply scan or take a
photo of the QR code and follow the
prompts.
http://springfr.ee/install-ov
WARRANTY REGISTRATION
2
We encourage you to register your
Springfree Trampoline warranty.
Doing so will create a customer profile
which will allow us to provide future
support and to send you important
product notifications. Scan or take a
photo of the QR code to get started.
http://springfr.ee/wclaim
0:04 / 0:45
WA S AFENT TO JUMP? IT DO ! ONE T A ME. A TI
ENVIE E TED S AU R? FA S EN TOU RITÉ! À A .ITE -LE TES ÉCU UNE L FOIS
B
C
A
1
2
4
3
6c
Outside
Person: Rocking
from your heels to
the balls of your
feet, use your
body weight to
push the white
mat rod towards
the center of the
mat.
Inside Person:
As the outside
person pushes,
carefully pull the
rod in and up in the
direction of the mat
rod holder.
Outside Person:
Do not twist or
rotate the mat to
remove a rod from a
mat rod holder. This
could cause serious
injury or damage
the trampoline.
78
10
Inside Person:
Guide the white
mat rod up and
over the back edge
of the mat rod
holder and into
position. Check that
the rod is fully
seated in the mat
rod holder before
continuing.
9
TIP - Keep the mat level when you install or uninstall the white mat rods.
TIP - If you need to uninstall a white mat rod, see the Disassembly Instructions on the reverse.
SCAN HERE or visit for a helpful installation video for Step 6.http://springfr.ee/g4-step-6 NOTE - If you purchased a FlexrHoopTM with your trampoline, you could stop and install it right
now. This will save you a couple of steps later.
Assemble the black net rods as shown.
Locate the pockets at the top edge of the net and install all of the black net rods.
Take care to fully push the ball of the black net rod into the pocket as shown. There is an internal catch at
the top of the pocket and the ball must be pushed past this internal catch or else it will come out. You will
feel some resistance as the ball is pushed through.
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or
uninstalled. Keep your face well away from any loaded rod.
9
Unfold
an aligd n Secure
8
WARNING - Do not use the trampoline until it is completely assembled. Failure to follow these
instructions may cause rods to break or eject from the trampoline frame.
NOTE - Check that the net is not caught on the trampoline frame or the bolts – if the net catches,
it may tear.
Moving clockwise around the frame, carefully slide the net up to the top of the white mat rods.
Then, starting at one of the blue stickers on the curved frames, gently and slowly pull the net up and over the
edge of the mat. It is normal for the net to be tight. Take extra care not to tug the net and check that the net
is not snagged on the trampoline frame or the bolts.
Working slowly around the frame, carefully li the rest of the net over the edge of the mat until the bottom
band of the net is pulled all the way to the top of the white mat rods.
TOP VIEW
7
NOTE - Follow the mat rod installation sequence. Do not install multiple mat rods in one
location. If you do not follow this sequence, it will be very diicult to attach the mat.
NOTE -
Each time you circle the trampoline, check that the center posts of the leg sections
are correctly seated under the trampoline frame. If they are not, adjust them before installing
any more rods. You may need to uninstall rods to release the tension.
Go back to the very first rod you attached to the mat in Step 6a. Now, moving clockwise, attach ONE white
mat rod next to the initially installed rod.
Moving clockwise around the trampoline, attach ONE additional rod next to each of the already installed
rods as shown above.
Continue circling the trampoline several more times following this sequence, installing only ONE rod per
grouping, until all the white mat rods are attached to the mat.
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or
uninstalled. Keep your face well away from any loaded rod.
6b
Have one person
position themselves
inside the frame of
the trampoline
while the other
stands outside as
shown.
Inside Person:
Ensure that the mat
rod holder is correctly
positioned with the
small tag positioned
outside the mat rod
holder pocket.
Inside Person:
Take hold of the rod
with both hands and
maintain a steady
grip until it is
securely installed in
the mat rod holder.
Outside Person:
Stand with one leg
forward and bend
your knees. Push
your elbow into
your hip.
Outside Person:
Hold the white mat
rod with your palm
facing up and bend
your arm at a right
angle.
Outside Person:
Pushing across your
body in the direction
shown will make it
easier to get the mat
rods in or out of the
mat rod holders.
12
3
5
4
6
TOP VIEW TOP VIEW
3
SCAN HERE
or visit for a helpful disassembly demonstration http://springfr.ee/disassem
video.
WARNING - Never remove a black net rod from its net rod pocket or disengage (unlock) the rod
sleeve while the black net rod is under tension. First, remove the net rod from the net rod socket
on the frame. Always ensure a solid grip when handling and do not stand directly in front of the rods.
Outside Person: Remove the white c-clips located on the net rod sockets. Li the bottom end of the black
net rods out of the net rod sockets and lower the net.
Outside Person: Remove the black net rods from the net rod pockets.
Outside Person: Starting at a corner, carefully pull the top edge of the net down over the edge of the mat.
Continue around the trampoline until the net is sitting at the bottom of the mat rods.
Disassembly
1
SCAN HERE or visit for a helpful installation video for Step 10.http://springfr.ee/g4-step-10
To install the net, raise the black net rods and carefully flex the bottom of the rods into the corresponding
net rod socket on the trampoline frame. Take care to completely insert the net rod into the socket. You will
hear a click when the net rod is fully seated.
For increased stability, your trampoline comes with sandbags. Fill these with sand and place over the
trampoline legs as required.
Congratulations! You have successfully installed your trampoline. Happy bouncing!
WARNING - Never attempt to remove a black net rod from its net rod pocket or disengage (unlock)
the rod sleeve while the black net rod is under tension.
12
6
7
8
5
10
WA SAFENT TO JUMP? IT DO !ONE T A ME. A TI
ENVIE E D S AU R? FA S EN TOU RITÉ! À A .TE ITE -LE TES ÉCU UNE L FOIS
WA DO TINT T ?O JUMP IT ! ONE T A SAFE A ME.
ENVIE E D S AU R? FA S EN TOU RITÉ! À A .TE ITE -LE TES ÉCU UNE L FOIS
2b Outside Person:
Push forward,
rocking from your
heels to the balls of
your feet, using the
weight of your body
to push the white
mat rod over the
back edge of the mat
rod holder. Keep the
mat edge horizontal
with your other hand.
5 Inside Person:
Once the ball comes
to the back edge of
the mat rod holder,
pull the white mat
rod down and out.
Sometimes a
forceful pull is
needed to dislodge
the ball from the
mat rod holder.
6
Inside and Outside
Person: Lower the
white mat rod and
carefully ease it to a
resting position.
7 Outside Person:
When you remove a
rod from the mat, do
not twist or rotate
the mat edge as
shown. This could
cause serious injury
or damage the
trampoline.
8
2a Outside Person:
Hold the white mat
rod with your palm
facing up and bend
your arm at a right
angle.
1 Outside Person:
Stand with one leg
forward and bend
your knees. Push
your elbow into
your hip.
2
Inside Person:
Take hold of the rod
with both hands.
3 Inside and
Outside Person:
Ensure the outside
person's hands are
positioned as
shown. Check that
their le hand is
tight against the
corner of the mat
rod holder but not
obstructing the
opening.
4
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or
uninstalled. Keep your face well away from any loaded rod.
WARNING - Both people must maintain a steady grip on the rod until it is in its resting position.
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or
uninstalled. Keep your face well away from any loaded rod.
WARNING - Treat any loaded rod with caution until you are sure it is properly installed or uninstalled.
Keep your face well away from any loaded rod.
NOTE - Following the sequence shown spreads the tension evenly across the mat. If you do not
follow this sequence, it will be very diicult to remove the mat.
Following the sequence show in Image A and moving in a counter-clockwise direction, uninstall ONE white
mat rod at each blue tag.
Then following the sequence shown in Image B and still moving in a counter-clockwise direction, uninstall
ONE additional rod next to each of the already uninstalled in figure A.
Continue circling the trampoline in a counter-clockwise direction several more times following this
sequence until all the white mat rods have been uninstalled.
Remove the white mat rods from the frame and then pack the net, mat and rods.
Disassemble the frame in the reverse order to which it was assembled.
A
3
2
1
4B
8
5
6
7
Produktspezifikationen
| Marke: | Springfree |
| Kategorie: | Trampolin |
| Modell: | Compact Round R54 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Springfree Compact Round R54 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Trampolin Springfree
23 August 2024
23 August 2024
23 August 2024
26 Juli 2024
16 September 2023
12 August 2023
Bedienungsanleitung Trampolin
- Trampolin Crivit
- Trampolin JYSK
- Trampolin Christopeit
- Trampolin Domyos
- Trampolin Klarfit
- Trampolin SereneLife
- Trampolin EXIT
- Trampolin Amigo
- Trampolin Berg
- Trampolin Little Tikes
- Trampolin Salta
- Trampolin AXI
- Trampolin Funfit
- Trampolin Avyna
- Trampolin Etan
- Trampolin Game On Sport
Neueste Bedienungsanleitung für -Kategorien-
11 Oktober 2024
5 Oktober 2024
4 September 2024
27 August 2024
25 August 2024
22 August 2024
21 August 2024
21 August 2024
21 August 2024
21 August 2024
