4-096-858-31 (1)

Operating Instructions

LCD Colour TV

KF-50SX300U

KF-60SX300U

Before operating the TV, please read the “Safety Information”

section of this manual. Retain this manual for future reference.

NOTICE FOR CUSTOMERS IN THE UNITED

KINGDOM

A moulded plug complying with BS1363 is fitted to this equipment for your safety and convenience.

Should the fuse in the plug supplied need to be replaced, a 5 AMP fuse approved by ASTA or BSI to BS

1362 (i.e. marked with or ) must be used.

When an alternative type of plug is used it should be fitted with a 5 AMP FUSE, otherwise the circuit

should be protected by a 5 AMP FUSE at the distribution board.

If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after

you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please

contact your nearest Sony service station.

How to replace the fuse

Open the fuse compartment with a blade screwdriver, and replace the fuse.

• IMPORTANT

If the plug supplied is not suitable for the socket outlets in your home, it should be cut off and

an appropriate plug fitted in accordance with the following instructions:

The wires in this mains lead are coloured in accordance with the following code:

Blue Neutral

Brown Live

As the colours of the wires in the mains lead of this apparatus may not correspond with the

coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the

letter N or coloured black. The wire which is coloured brown must be connected to the

terminal which is marked with the letter L or coloured red. Do not connect either wire to the

earth terminal in the plug which is marked by the letter E or by the safety earth symbol Y

or coloured green or green and yellow.

WARNING

• To prevent the risk of electric shock, do not insert the plug cut off from the mains lead into a

socket outlet. This plug cannot be used and should be destroyed.

• To prevent the risk of fire or electric shock, do not expose the unit to rain or moisture.

• Dangerously high voltages are present inside the set. Do not open the cabinet. Refer servicing

to qualified personnel only.

FUSE

Introduction

Thank you for choosing this Sony product.

Before operating the TV, please read this manual thoroughly and retain it for future reference.

• Symbols used in the manual:

Table of Contents

Notice for Customers in the United Kingdom............................................ ....................... ................................... 2

Introduction ............................................... .................................. ......................................................................... 3

Safety Information................................................................................................................................................ 4

Overview & Installation

Checking the Accessories Supplied........... ........................................................ ................................................... 6

Inserting Batteries into the Remote Control......................................................................................................... 6

Overview of Remote Control Buttons.................................................................................................................. 7

Overview of the TV Buttons ................................................................................................................................ 8

Connecting the Aerial and VCR............................................. ............................................. ................................. 9

Stabilizing the TV set ........................................................................................................................................... 9

First Time Operation

Switching on the TV and Automatically Tuning ............................................................................................... 10

TV Functions

Introducing and Using the Menu System .......................................................................................................... 12

The Picture Adjustment menu ..................................................................................................................... 13

The Sound Adjustment menu .............. .............................................................................. ........................... 14

The Features menu........................................................................................................................................ 16

Autoformat ............................................................................................................................................. 16

AV3 Output............................................................................................................................................ 17

Connection Guide.......................... ................................................................... ...................................... 17

RGB Centring......................................................................................................................................... 17

The Set Up menu .......................................................................................................................................... 18

Language ................................................................................................................................................18

Country...................... ......................................................................................... .................................... 18

Auto Tuning ........................................................................................................................................... 18

Programme Sorting ................................................................................................................................ 18

Programme Labels ................................................................................................................................. 19

AV Preset ............................................................................................................................................... 19

Manual Programme Preset .....................................................................................................................20

PAP (Picture And Picture).................................................................................................................................. 21

Teletext.................................................................................................................................................................. 22

NexTView...............................................................................................................................................................23

Additional Information

Connecting Equipment to the TV........................................................................................................................24

Viewing pictures from equipment connected to the TV......................................................................................25

Remote Control Configuration for VCR or DVD ...............................................................................................26

Optimum Viewing area .......................................................................................................................................27

Replacing the lamp ..............................................................................................................................................28

Technical Specifications......................................................................................................................................30

PC Input Specifications .......................................................................................................................................31

Troubleshooting...... ............ ................................................................ ...................... ...........................................32

Television Channel Guide for United Kingdom......................................... .................................. .......................34

How to lift the TV ................................................................................................................................Back cover

• Buttons shaded white on the remote control show you

the buttons you have to press to follow the sequence of

the instructions.

• Informs you of the result of the instructions.

• Important information.

• Information on a feature.

• 1,2... Sequence of instructions.
