Seite 1/112
Redbox
User Handbook No3
Mixers & Source Selectors, Microphone
Ampliers, Stereo to Mono Converters,
General Interfaces
RB-SS10 10 way stereo analogue source selector/mixer
RB-DSS10 10 way stereo digital source selector
RB-PMX4 10 input, 4 output analogue preset mixer
RB-SSML1 Mic/line source selector with compressor/limiter
RB-MA1 Microphone amplier, single
RB-MA2 Microphone amplier, dual
RB-DMA2 Dual digital microphone amplier
RB-ML2 Microphone limiter, 2 channel
RB-SL2 Twin mono, or stereo limiter
RB-SM1 Stereo to mono converter, single
RB-SM2 Stereo to mono converter, dual
RB-LC3 3 way light/power controller
RB-MM1 Mix minus generator
RB-OA3 3 studio on-air switcher
RB-OA3R Remote switch panel for RB-OA3
Redbox User Handbook No 3
Revision 2.06 September, 2008
©Sonifex Ltd, 2000-8
All Rights Reserved
Sonifex Ltd, 61, Station Road, Irthlingborough,
Northants, NN9 5QE, England.
Tel : +44 (0)1933 650 700
Fax : +44 (0)1933 650 726
Email : sales@sonifex.co.uk or technical.support@sonifex.co.uk
Web : http://www.sonifex.co.uk
Information in this document is subject to change without notice and does not represent
a commitment on the part of Sonifex Ltd. Sonifex Ltd shall not be liable for any loss or
damage whatsoever arising form the use of information or any error contained in this
manual.
No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and
retrieval systems, for any purpose other than the purchaser’s personal use, without the
express written permission of Sonifex Ltd.
Unless otherwise noted, all names of companies, products and persons contained herein are
part of a completely ctitious adaptation and are designed solely to document the use of
Sonifex products.
Redbox User Handbook No 3
CONTEN TS
CONTEN TS
Warranty i
Warranty and Liability - important the purchaser is advised to read this clause i
Unpacking the Redbox ii
Returning the Warranty Card iii
Safety Information iii
Safety of Mains Operated Equipment iii
Voltage Setting Checks iii
Fuse Rating iii
Power Cable and Connection iv
Ordering the Correct Mains Lead iv
Installation Information iv
Atmosphere iv
Electromagnetic Radiation iv
Fitting Redboxes iv
WEEE & RoHS Directives - Sonifex Statement vi
1 RB-SS10 10 Way Stereo Analogue Source Selector/Mixer 1
Introduction 1
System Block Diagram 2
Front Panel Indicators & Controls 2
Illuminated Push Buttons 2
Front Panel Gain Controls 3
Headphone Output 3
Volume Control 3
Additional Modes 3
Conguring the Additional Modes 3
Rear Panel Connections and Operation 4
Inputs 4
Outputs 4
Altering the Master Output Level 4
RB-SS10 Additional Audio Input Connectors 5
RB-SS10 Remote Start I/O 6
Remote Select/Switch Inputs 7
Status Outputs 8
Technical Specications RB-SS10 9
2 RB-DSS10 10 Way Stereo Digital Source Selector 11
Introduction 11
System Block Diagram 12
Front Panel Indicators & Controls 12
Power Indicator 13
Illuminated Push Buttons 13
Headphone Output 13
Volume Control 13
Additional Modes 13
Conguring the Additional Modes 13
Rear Panel Connections and Operation 14
RB-DSS10 Inputs 14
RB-DSS10 Outputs 14
Digital Audio Inputs & S/PDIF Output 15
Remote Start I/O 16
Remote Select/Switch Inputs 17
Status Outputs 18
Technical Specications RB-DSS10 19
3 RB-PMX4 10 Input, 4 Output Analogue Preset Mixer 21
Introduction 21
System Block Diagram 22
