Seite 1/72
Redbox
User Handbook No 2
Matching Converters, Distribution
Ampliers & Headphone Ampliers
RB-UL1 Single stereo unbalanced to balanced converter
RB-UL2 Dual stereo unbalanced to balanced converter
RB-UL4 Quad stereo unbalanced to balanced converter
RB-LU4 Quad stereo balanced to unbalanced converter
RB-BL2 Single stereo bi-directional matching converter
RB-BL4 Dual stereo bi-directional matching converter
RB-PA2 Dual stereo RIAA phono amplier
RB-LI2 Stereo line isolation unit
RB-PLI6 6 way mono passive line isolation unit
RB-DA6 6 way stereo distribution amplier
RB-DA6G 6 way stereo distribution amplier with output
gain control
RB-DA4x5 4 input, 4 x 5 output distribution amplier/mixer
RB-DDA6A 6 way stereo AES/EBU digital distribution amplier
RB-DDA6S 6 way stereo S/PDIF digital distribution amplier
RB-DDA6W 6 way word clock digital distribution amplier
RB-HD1 Stereo headphone amplier
RB-HD2 Dual stereo headphone amplier
RB-HD6 6 way stereo headphone distribution amplier
RB-DHD6 Digital 6 way stereo headphone distribution amplier
Redbox User Handbook No 2
Revision 2.05 July, 2009
©Sonifex Ltd, 2000-9
All Rights Reserved
Sonifex Ltd, 61, Station Road, Irthlingborough,
Northants, NN9 5QE, England.
Tel : +44 (0)1933 650 700
Fax : +44 (0)1933 650 726
Email : sales@sonifex.co.uk or technical.support@sonifex.co.uk
Web : http://www.sonifex.co.uk
Information in this document is subject to change without notice and does not represent
a commitment on the part of Sonifex Ltd. Sonifex Ltd shall not be liable for any loss or
damage whatsoever arising form the use of information or any error contained in this
manual.
No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and
retrieval systems, for any purpose other than the purchaser’s personal use, without the
express written permission of Sonifex Ltd.
Unless otherwise noted, all names of companies, products and persons contained herein are
part of a completely ctitious adaptation and are designed solely to document the use of
Sonifex products.
Redbox User Handbook No 2
CONTEN TS
CONTEN TS
Warranty i
Warranty and Liability - important the purchaser is advised to read this clause i
Unpacking the Redbox ii
Returning the Warranty Card iii
Safety Information iii
Safety of Mains Operated Equipment iii
Voltage Setting Checks iii
Fuse Rating iii
Power Cable and Connection iv
Ordering the Correct Mains Lead iv
Installation Information iv
Atmosphere iv
Electromagnetic Radiation iv
Fitting Redboxes iv
WEEE & RoHS Directives - Sonifex Statement vi
MATCHING CONVERTERS
1 RB-UL1 Single, RB-UL2 Dual & RB-UL4 Quad Stereo Unbalanced
To Balanced Converters 1
Introduction 1
System Block Diagram 1
Rear Panel Connections and Operation 2
RCA Phono Inputs (Left and Right) 3
Outputs (Left and Right) 3
Output Level Adjustment 3
Technical Specications 4
2 RB-LU4 Quad Stereo Balanced To Unbalanced Converter 5
Introduction 5
System Block Diagram 6
Rear Panel Connections and Operation 7
Inputs 1-4 (Left and Right) 7
RCA Phono Outputs 1-4 (Left and Right) 7
Output Level Adjustment 7
Technical Specications 8
3 RB-BL2 Single & RB-BL4 Dual Bi-Directional Matching Converter 9
Introduction 9
System Block Diagram 10
Rear Panel Connections and Operation 10
Balanced to Unbalanced Connections 11
Inputs 1 (& 3) (Left & Right) 11
RCA Phono Outputs 1 (&3) (Left & Right) 11
Output Level Adjustment 11
Unbalanced to Balanced Connections 11
RCA Phono Inputs 2 (& 4) (Left & Right) 11
Outputs 2 (& 4) (Left & Right) 11
Technical Specications 12
