ii. the Goods have only been operated under normal operating

conditions and have only been subject to normal use (and in

particular the Goods must have been correctly connected and

must not have been subject to high voltage or to ionising

radiation and must not have been used contrary to the

Company’s technical recommendations);

iii. the Goods are returned to the Company’s premises at the

Purchaser’s expense;

iv. any Goods or parts of Goods replaced shall become the property

of the Company;

v. no work whatsoever (other than normal and proper

maintenance) has been carried out to the Goods or any part of

the Goods without the Company’s prior written consent;

vi. the defect has not arisen from a design made, furnished or

specified by the Purchaser;

vii. the Goods have been assembled or incorporated into other

goods only in accordance with any instructions issued by the

Company;

viii. the defect has not arisen from a design modified by the

Purchaser;

ix. the defect has not arisen from an item manufactured by a person

other than the Company. In respect of any item manufactured by

a person other than the Company, the Purchaser shall only be

entitled to the benefit of any warranty or guarantee provided by

such manufacturer to the Company.

b. In respect of computer software supplied by the Company the

Company does not warrant that the use of the software will be

uninterrupted or error free.

c. The Company accepts liability:

(i) for death or personal injury to the extent that it results from

the negligence of the Company, its employees (whilst in the

course of their employment) or its agents (in the course of the

agency);

(ii) for any breach by the Company of any statutory undertaking

as to title, quiet possession and freedom from encumbrance.

d. Subject to conditions (a) and (c) from the time of despatch of the

Goods from the Company’s premises the Purchaser shall be

responsible for any defect in the Goods or loss, damage, nuisance or

interference whatsoever consequential economic or otherwise or

wastage of material resulting from or caused by or to the Goods. In

particular the Company shall not be liable for any loss of profits or

other economic losses. The Company accordingly excludes all liability

for the same.

e. At the request and expense of the Purchaser the Company will test the

Goods to ascertain performance levels and provide a report of the

results of that test. The report will be accurate at the time of the test,

to the best of the belief and knowledge of the Company, and the

Company accepts no liability in respect of its accuracy beyond that set

out in Condition (a).

f. Subject to Condition (e) no representation, condition, warranty or

other term, express or implied (by statute or otherwise) is given by the

Company that the Goods are of any particular quality or standard or

will enable the Purchaser to attain any particular performance or

result, or will be suitable for any particular purpose or use under

specific conditions or will provide any particular capacity,

notwithstanding that the requirement for such performance, result or

capacity or that such particular purpose or conditions may have been

known (or ought to have been known) to the Company, its employees

or agents.

Product Warranty - 2 Year Extended

As standard, Sonifex products are supplied with a 1 year back to base

warranty. In order to register the date of purchase and so that we can keep

you informed of any product design improvements or modifications, it is

important to complete the warranty registration online. Additionally, if you

warranty to 2 years. Go to the Sonifex website at: www.sonifex.co.uk/register

to apply for your 2 year warranty.

Sonifex Warranty & Liability Terms & Conditions

1. Definitions

‘the Company’ means Sonifex Ltd and where relevant includes companies

within the same group of companies as Sonifex Limited.

‘the Goods’ means the goods or any part thereof supplied by the Company

and where relevant includes: work carried out by the Company on items

supplied by the Purchaser; services supplied by the Company; and software

supplied by the Company.

‘the Purchaser’ means the person or organisation who buys or has agreed to

buy the Goods.

‘the Price’ means the Price of the Goods and any other charges incurred by

the Company in the supply of the Goods.

‘the Warranty Term’ is the length of the product warranty which is usually 12

months from the date of despatch; except when the product has been

registered at the Sonifex website when the Warranty Term is 24 months from

the date of despatch.

‘the Contract’ means the quotation, these Conditions of Sale and any other

document incorporated in a contract between the Company and the

Purchaser.

This is the entire Contract between the parties relating to the subject matter

hereof and may not be changed or terminated except in writing in

accordance with the provisions of this Contract. A reference to the consent,

acknowledgement, authority or agreement of the Company means in writing

and only by a director of the Company.

2. Warranty

a. The Company agrees to repair or (at its discretion) replace Goods

which are found to be defective (fair wear and tear excepted) and

which are returned to the Company within the Warranty Term provided

that each of the following are satisfied:

i. notification of any defect is given to the Company immediately

upon its becoming apparent to the Purchaser;

g. (i) To the extent that the Company is held legally liable to the

Purchaser for any single breach of contract, tort, representation

or other act or default, the Company’s liability for the same shall

not exceed the price of the Goods.

(ii) The restriction of liability in Condition (g)(i) shall not apply to any

liability accepted by the Seller in Condition (c).

h. Where the Goods are sold under a consumer transaction (as defined by

the Consumer Transactions (Restrictions on Statements) Order 1976)

the statutory rights of the Purchaser are not affected by these

Conditions of Sale.

Unpacking Your Product

Each product is shipped in protective packaging and should be inspected for

damage before use. If there is any transit damage take pictures of the

product packaging and notify the carrier immediately with all the relevant

details of the shipment. Packing materials should be kept for inspection and

also for if the product needs to be returned.

The product is shipped with the following equipment so please check to

ensure that you have all of the items below. If anything is missing, please

contact the supplier of your equipment immediately.

Item Quantity

Product unit 1

A3 Folded Handbook 1

Repairs & Returns

Please contact Sonifex or your supplier if you have any problems with your

Sonifex product. Email technical.support@sonifex.co.uk for the repair/

upgrade/returns procedure, or for support & questions regarding the product

operation.

Conformity

The products in this manual comply with the essential requirements of the

relevant European health, safety and environmental protection legislation.

The technical justification file for this product is available at Sonifex Ltd.

The declaration of conformity can be found at:

https://www.sonifex.co.uk/declarations

WEEE Directive

The Waste Electrical and Electronic Equipment (WEEE) Directive

was agreed on 13 February 2003, along with the related

Directive 2002/95/EC on Restrictions of the use of certain

Hazardous Substances in electrical and electronic equipment

(RoHS). The Waste Electrical and Electronic Equipment Directive (WEEE) aims

to minimise the impacts of electrical and electronic equipment on the

environment during their life times and when they become waste. All

products manufactured by Sonifex Ltd have the WEEE directive label placed

on the case. Sonifex Ltd will be happy to give you information about local

organisations that can reprocess the product when it reaches its “end of use”,

or alternatively all products that have reached “end of use” can be returned

to Sonifex and will be reprocessed correctly free of charge.

Atmosphere/Environment

This apparatus should be installed in an area that is not subject to excessive

temperature variation (<0°C, >50°C), moisture, dust or vibration.

This apparatus shall not be exposed to dripping or splashing, and no objects

filled with water, such as vases shall be placed on the apparatus.

Manufacturers of Audio Products for AV,

Installed Sound, Broadcast Radio & Broadcast TV

This handbook is for use with the following product:

AVN-HA1 Headphone Amplifier

AVN-HD1 Headphone Amplifier

Stock Code: 30-300

Artwork: AW010922A

©Sonifex Ltd, 2021

Revision 1.01, August 2021

Sonifex Ltd, 61, Station Road, Irthlingborough,

Northants, NN9 5QE, England.

Tel: +44 (0)1933 650 700

Fax: +44 (0)1933 650 726

Email: sales@sonifex.co.uk

Website: https://www.sonifex.co.uk

Made in the UK by

Product:

Serial No:

Extended 2 Year Warranty

For the latest Sonifex handbook information please visit the

Sonifex website at www.sonifex.co.uk

Information in this document is subject to change without notice and does not represent a

commitment on the part of the vendor. Sonifex Ltd shall not be liable for any loss or damage

whatsoever arising from the use of information or any error contained in this manual.

No part of this manual may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, recording, information storage and retrieval systems, for any

purpose other than the purchaser’s personal use, without the express written permission of Sonifex

Ltd. Unless otherwise noted, all names of companies, products and persons contained herein are part

of a completely fictitious adaptation and are designed solely to document the use of Sonifex product.

AVN-Portal

Satellite Boxes

AVN-HA1 Headphone Amplifier

AVN-HD1 Headphone Amplifier

HANDBOOK

www.sonifex.co.uk/register

1 2 3 4

▲

Sonifex AVN-Portal Satellite Boxes

1. Introduction

Fig 1-1: AVN-HA1 Front and Rear Panel

Fig 1-2: AVN-HD1 Front and Rear Panel

The AVN-HA1 and AVN-HD1 are headphone amplifiers which can be

combined with AVN-Portal units to provide a headphone distribution system.

The units can be powered via their connection to an AVN-Portal or

alternatively via a DC power connector located on the rear panel of the unit.

On the front panel a 6.35 mm (1/4”) headphone socket is available along

with a volume control knob. A ‘Mute’ button is also provided that controls a

GPO which can trigger an AVN-Portal to perform functions such as muting an

input stream or an output stream. A power status indicator LED is located on

the front panel of the device. This will illuminate red when power is available.

On both units, a loop through audio output is available. This allows the

headphone amplifiers to be daisy chained, or to be quickly and easily

inserted in-line between two other pieces of equipment, allowing monitoring

of the audio feed.

The AVN-HA1 is compatible with the AVN-PA8/D and the AVN-PM8/D Portals.

The AVN-HD1 is compatible with the AVN-PD8/D Portal.

2. Application Example

Fig 2-1: AVN-HA1 Use Case Diagram Example

5 6 7 8

3. Front Panel

Power Status LED

The power status LED illuminates red when a power source is available.

Power can be supplied via the input ethernet connection located on the rear

panel of the unit by connecting the unit to an AVN-Portal or by the 12V DC

(Max 2W) connection on the rear panel of the unit.

Mute/GPO Button

The mute/GPO button is a push switch that controls a general-purpose

output which is connected to an AVN-Portal via the portal RJ45 connection

on the rear panel of the unit. The mute/GPO button can be set as a

momentary or latching switch by inserting/removing an internal pin (set as

momentary by default. Contact Sonifex for more information). The action can

then be set up via the AVN-Portals web server in order to provide

functionality such as muting/unmuting I/O, controlling LEDs, and controlling

relays. See the relevant AVN Portal handbook for more information.

Headphone Socket

The 6.35 mm (1/4”) headphone socket can be used to connect headphones

to the unit. The high-quality output can be used to drive 150 mW of power

into headphones with an impedance from 32Ω to 600Ω. The headphone

socket has the following pinout;

Tip: Headphone Left

Ring: Headphone Right

Sleeve: Ground

Volume Control Knob

The volume control knob can be used to control the level of audio supplied to

the user headphones from -60dB to +6dB.

4. Rear Panel

AVN-HA1

Fig 4-1: AVN-HA1 Back Panel

Stereo Line Input

The stereo line input provides connections for stereo analogue audio, power,

and the general-purpose output. It is an RJ45 port with the following pinout;

Pin 1: Input Left + (Phase)

Pin 2: Input Left – (Non-phase)

Pin 3: Input Right + (Phase)

Pin 4: Ground

Pin 5: Cough/Mute (Active low)

Pin 6: Input Right – (Non-phase)

Pin 7: No connection

Pin 8: +12V

Loop Through Output

The loop through output is used to pass on the stereo audio being routed to

the unit. It is an RJ45 type port with the following pinout;

Pin 1: Output Left + (Phase)

Pin 2: Output Left – (Non-phase)

Pin 3: Output Right + (Phase)

Pin 4: Ground

Pin 5: No connection

Pin 6: Output Right – (Non-phase)

Pin 7: No connection

Pin 8: No connection

The audio connections are compatible with any other analogue products

using the StudioHub+ TM pinout.

12V DC Input Max 2W

It can either be used as a second power supply (for redundancy) or used to

power the AVN-HA1 if not being used in conjunction with an AVN-PA8 IO.

AVN-HD1

Fig 4-2: AVN-HD1 Back Panel

Stereo Digital Input

The stereo digital input provides connections for stereo digital audio, power,

and the general-purpose output. It is an RJ45 port with the following pinout;

Pin 1: Input AES + (Phase)

Pin 2: Input AES – (Non-phase)

Pin 3: No connection

Pin 4: Ground

Pin 5: Cough/Mute (Active low)

Pin 6: No connection

Pin 7: No connection

Pin 8: +12V

Stereo Digital Output

The stereo digital output is used to pass on the stereo audio being routed to

the unit. It is an RJ45 port with the following pinout;

Pin 1: Output AES + (Phase)

Pin 2: Output – (Non-phase)

Pin 3: No connection

Pin 4: Ground

Pin 5: No connection

Pin 6: No connection

Pin 7: No connection

Pin 8: No connection

The audio connections are compatible with any other digital products using

the StudioHub+TM pinout.

12V DC Input Max 2W

The 12V DC Input (Max 2W) connection is located on the rear panel of the

unit. It can either be used as a second power supply (for redundancy) or used

to power the AVN-HD1 if not being used in conjunction with an AVN-PD8 IO.

5. Technical Specification

Parameter AVN-HA1 Specification AVN-HD1 Specification

Output Impedance: Drives 150mW into 32Ω to 600Ω headphones.

Max Input Level: +24dBu N/A

D to A Line-up: N/A -6dBFS = +18dBu

Max Output Level: +18dBu

Frequency

Response:

20Hz to 20kHz, +0/-0.2dB

THD+N: <-90dBu, -12dBu, 20Hz to

20kHz, unity gain, 20kHz

<-90dBu, -30dBFS,

20Hz to 20kHz, unity

gain, 20kHz BW

Noise: -92dBu, A weighted

Crosstalk: -90dB, 1kHz, +4dBu -90dB, 1kHz, +14dBFS

Common Mode: -40dB, 1kHz N/A

Cable: Cat5/Cat5e/Cat6, Maximum length of 20m between

Portal and AVN-HA1/AVN-HD1 if no external PSU

is used

Equipment Type

AVN-HA1: Analogue Headphone Amp for AVN-PA8/D &

AVN-PM8/D Portals

AVN-HD1: Digital Headphone Amp for AVN-PD8/D Portal

Physical Specification for AVN-HA1 & AVN-HD1

Dimensions: (Raw) 7.7cm (W) x 8.3cm (D) x 4.2cm (H)

3.0” (W) x 3.3” (D) x 1.7” (H)

Dimensions

(Boxed):

12.7cm (W) x 22.9cm (D) x 7.6cm (H)

5” (W) x 9” (D) x 3” (H)

Weight: Nett: 0.22kg Gross: 0.33kg

Nett: 0.49lbs Gross: 0.73lbs

Accessories

CM-MNTI Desk Mount Panel

Fig 3-1: AVN-HA1 Front Panel Fig 3-2: AVN-HD1 Front Panel

▲

w w w . s o n i f e x . c o . u k

t:+44 (0)1933 650 700

f:+44 (0)1933 650 726

sales@sonifex.co.uk

Produktspezifikationen

Marke:	Sonifex
Kategorie:	Empfänger
Modell:	AVN-HA1

Brauchst du Hilfe?

Wenn Sie Hilfe mit Sonifex AVN-HA1 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Empfänger Sonifex

Sonifex CM-TB8 Bedienungsanleitung

27 August 2024

Sonifex AVN-HD1 Bedienungsanleitung

27 August 2024

Sonifex Redbox RB-DDA6A Bedienungsanleitung

27 August 2024

Sonifex Redbox RB-DMA2 Bedienungsanleitung

27 August 2024

Sonifex CM-HPX1 Bedienungsanleitung

27 August 2024

Sonifex CM-BH4W Bedienungsanleitung

27 August 2024

Sonifex AVN-HA1 Bedienungsanleitung

27 August 2024

Sonifex CM-HPR1 Bedienungsanleitung

27 August 2024

Sonifex CM-BHA Bedienungsanleitung

14 November 2023

Bedienungsanleitung Empfänger

Neueste Bedienungsanleitung für -Kategorien-

Rotel RA‑1592MKII Bedienungsanleitung

16 Oktober 2024

Denon AVR-S900W Bedienungsanleitung

16 Oktober 2024

Pro-Ject Amp Box DS2 Bedienungsanleitung

15 Oktober 2024

AKG HP12U Bedienungsanleitung

15 Oktober 2024

Sennheiser EM 9046 SU Bedienungsanleitung

14 Oktober 2024

Yamaha MusicCast RX-V481 Bedienungsanleitung

14 Oktober 2024

JL Audio VX600/6i Bedienungsanleitung

12 Oktober 2024

Pioneer SX-303RDS Bedienungsanleitung

10 Oktober 2024

Technics SA-160L Bedienungsanleitung

8 Oktober 2024

Avantree Audiplex Bedienungsanleitung

7 Oktober 2024
