page 1 / 3 sonel.com
Professional Clamp Meter
CMP-3000
index: WMGBCMP3000
Robust design
With the help of the latest tech-
nologies, a compact instrument
for working in the toughest con-
ditions has been created. The rub-
ber housing protects the device
against accidental damage.
Visibility in any conditions
Darkness in the workplace is not
a problem thanks to the built-in
flashlight.
Multifunctional
The device is versatile due to many
measurement options. In addition
to the basic measurements, the
instrument has special functions,
including inrush current (INRUSH),
MAX / MIN values, relative value
(REL) and peak value (PEAK).
Improved clamp
The innovative shape means eas-
ier access in hard to reach and
tight places. The clamp edging is
equipped with a contactless volt-
age indicator sensor.
Attachable flexible clamp
Enables AC current measurement
up to 3000 A. Designed for easy
installation on power busbars
upto 160 mm diameter.
Wireless communication
Transfer measurement data via
Bluetooth, in „live” mode, to the
Sonel Multimeter Mobile appli-
cation. This allows to record and
store the results and include addi-
tional description or photos. You
can also share measurement data
as an e-mail attachment.
page 2 / 3 sonel.com
m.v. - measured value
Technical specications
Measurement functions Range Resolution Accuracy
±(% m.v. + digits)
AC current
flexible clamp up to 3000 A
0.1 A ±(2.8% m.v. + 8 digits)
built-in clamp up to 1000 A
DC current up to 1000.0 A 0.1 A ±(2.5% m.v. + 5 digits)
AC voltage up to 1000.0 V from 0.01 mV ±(1.0% m.v. + 9 digits)
DC voltage up to 1000.0 V from 0.01 mV from ±(0.1% m.v. + 4 digits)
Resistance up to 40.000 MΩ from 0.01 Ω from ±(1.0% m.v. + 4 digits)
Frequency up to 50.000 MHz ±(0.3% m.v. + 2 digits)from 0.001 Hz
Capacitance up to 5.0000 mF from 0.01 nF from ±(3.5% m.v. + 9 digits)
Duty cycle (%) 5.0…95.0% 0.1% ±(1.0% m.v. + 2 digits)
Temperature measurement -100.0…+1000ºC
-148.0…+1832ºF
0.1ºC
0.1ºF
±(1.0% m.v. + 2ºC)
±(1.0% m.v. + 3.6ºF)
Continuity / Diode test ✓ ✓ /
Basic features
Counting 50.000 digits
HOLD ✓
Automatic range selection ✓
Advanced features
Inrush current ✓
Non-contact voltage detector ✓
MIN / MAX ✓ ✓ /
PEAK HOLD ✓
Relative measurement REL ✓
TRMS measurement ✓
Memory in mobile application
Bluetooth communication ✓
Other features
Auto-off ✓
Empty battery indication ✓
Integrated flashlight ✓
Beeper ✓
Display
Type segment-based LCD, 5 digits
Display backlight manual
Safety and conditions for use
Measuring category (EN 61010) CAT IV 600 V
CAT III 1000 V
Ingress protection IP40
Dimensions 230 x 76 x 40 mm 9.0” x 3.0” x 1.6” |
Operating temperature 5...40°C 41...104°F |
Storage temperature -20…+60°C -4...140°F |
page 3 / 3 sonel.com
6LR61 9 V battery
Standard accessories
Flexible clamp F-16
WACEGF16
Carrying case
Set of test leads
CAT IV, M
WAPRZCMM2
AC-16 line splitter
(facilitates current
measurements)
WAADAAC16
Temperature
measurement
probe (K-type, bayonet)
WASONTEMP
probe (K-type, metal)
WASONTEMK2
Crocodile clip mini,
1 kV 10A (set)
WAKROKPL10MNI
Optional accessories
Set of test leads
CAT IV, S
WAPRZCMM1
Factory calibra-
tion certicate
Calibration cer-
ticate with
accreditation
M13 carrying case
WAFUTM13
Test lead with probe
for CMM/CMP (set)
WAPRZCMP1
Test lead 2 m
with 10 A fuse
CATIV 1000 V
black / blue / green
/ red / yellow
WAPRZ002BLBBF10
WAPRZ002BUBBF10
WAPRZ002GRBBF10
WAPRZ002REBBF10
WAPRZ002YEBBF10
Pin probe (banana
socket) red / blue
/ yellow / black
B1 / black B3
WASONREOGB1
WASONBUOGB1
WASONYEOGB1
WASONBLOGB1
WASONBLOGB3
Crocodile clip
red / blue / yel-
low / black
WAKRORE20K02
WAKROBU20K02
WAKROYE20K02
WAKROBL20K01
+
Temperature
measurement
Probe (K-type)
WASONTEMK
Adapter
WAADATEMK
