Seite 1/2
M.2 SATA external SSD enclosure
with USB 3.1 Gen 2
Support 2260 or 2280 form factors of B key M.2 SATA SSD
Premium all aluminum exterior with small, pocketable design
Latest USB 3.1 Gen 2 interface up to 10Gb/s super speed
transfer rate
Robust USB Type-A interface and no driver installation required
Retractable USB connector design
Model No.
Color
Material
Data transfer rate
Connector
Controller
LED indicator
Support type of M.2 SSD
Operating system support
Net weight
Dimension
MS09 x 1
Screwdriver x 1
Spare outer shell screws x 2
SST-MS09C
Charcoal
Aluminum unibody shell and plate
USB 3.1 Gen 2 up to 10Gbps
(Compatible with USB 3.1 Gen 1 / 3.0 / 2.0 / 1.1)
USB Type-A
VIA VL715
Solid Blue: Powered
Blinking Blue: Reading / writing
B Key SATA Type M.2 SSD x 1
Support 22mm x 60mm or 22mm x 80mm size
Microsoft Windows 10/8.1/8/7 (32bit/64bit)
or future release version
Mac 10.8.6 or future release versions
33g ± 5g
110mm (W) x 9mm (H) x 26mm (D)
4.33" (W) x 0.35" (H) x 1.02" (D)
www.silverstonetek.com
NO: G11231870
For North America (usasupport@silverstonetek.com)
SilverStone Technology in North America may repair or replace defective product with refurbished product that is not new but has been functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All power supplies should be sent back to the
place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology in USA by first
downloading the “USA RMA form for end-users” form from the below link and follow its instructions.
http://silverstonetek.com/contactus.php
For Australia only (support@silverstonetek.com)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure. Please refer to above “Warranty terms & conditions” for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C. + 886-2-8228-1238
(standard international call charges apply)
For Europe (support.eu@silverstonetek.de)
For all other regions (support@silverstonetek.com)
This product has a limited 1 year warranty in North America, Europe, and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
1. Product component defects or damages resulted from defective production is covered under warranty. Defects or damages with the following conditions will be fixed
or replaced under SilverStone Technology’s jurisdiction.
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for the product (depreciated value, excluding shipping, handling,
and other fees). SilverStone Technology is not responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no circumstances will SilverStone Technology be liable for
damages in connection with the sale, purchase, or use including but not limited to loss of data, loss of business, loss of profits, loss of use of the product or incidental
or consequential damage whether or not foreseeable and whether or not based on breach of warranty, contract or negligence, even if SilverStone Technology has been
advised of the possibility of such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand
purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone
. http://www.silverstonetek.com
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt; (ii) You shall bear the cost of shipping (or otherwise
transporting) the product to SilverStone authorized distributors. SilverStone authorized distributors will bear the cost of shipping (or otherwise transporting) the product
back to you after completing the warranty service; (iii) Before you send the product, you must be issued a Return Merchandise Authorization (“RMA”) number from
SilverStone. Updated warranty information will be posted on SilverStone’s official website. Please visit for the latest updates.http://www.silverstonetek.com
○：表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11364-2014标准规定的限量要求以下。
×：表示该有毒有害物质在该部件材料中的含量超出SJ/T11364-2014标准规定的限量要求。
有毒有害物质/元素及其化学含量表
部件名称
风扇
电子卡
线材
螺丝
包材
机壳
（金属）
多溴二苯醚
(PBDE)
多溴联苯
(PBB)
六价铬
(Cr(VI))
镉
(Cd)
汞
(Hg)
铅
(Pb)
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○×
×
×
×
×
○
产品合格证
检验员：检01
生产日期：见产品条码
本表中有×的部件均符合欧盟RoHS法规，即欧盟第2011/65/EU号指令要求。
Remove 4 screws from the MS09 Открутите винта 4 с MS09
4 Schrauben vom MS09 entfernen 移除MS09的4顆螺絲
Retirez les 4 vis du MS09 移除MS09的4颗螺丝
Retire 4 tornillos de la MS09 MS09からネジ4本を外します
Rimuovere 4 viti da MS09 MS09에서 4개의 나사를 제거합니다
Remove screws on the MS09 PCB
and install M.2 SATA SSD
Schrauben an der MS09-Leiterplatte
entfernen und M.2-SATA-SSD installieren
Retirez les vis du circuit imprimé du MS09
et installez le SSD SATA M.2
Retire tornillos del PCB de la MS09 e
instale el SSD SATA M.2
Rimuovere le viti sulla PCB di MS09 e
installare l'SSD SATA M.2
Открутите винты на печатной плате MS09
PCB M.2 SATA SSDи установите
移除MS09電路板上的螺絲，安裝M.2 SATA SSD
移除MS09电路板上的螺丝，安装M.2 SATA SSD
MS09 PCB上のネジを外してからM.2 SATA SSD
をインストールします
MS09 PCB의 나사를 제거하고
M.2 SATA SSD를 설치합니다
Secure screws to suitable mounting hole
depending on the length of M.2 SATA SSD
used
Schrauben je nach Länge der verwendeten
M.2-SATA-SSD in einem geeigneten
Montageloch sichern
Fixez les vis dans les trous de montage
adaptés en fonction de la longueur du SSD
SATA M.2 utilisé
Fije los tornillos al agujero de montaje
adecuado dependiendo de la longitud del
SSD SATA M.2 usado
Fissare le viti ad un foro di montaggio
adeguato in base alla lunghezza dell'SSD
SATA M.2 utilizzato
Закрепите винты в соответствующем
монтажном отверстии в зависимости от
длины используемого M.2 SATA SSD
根據M.2 SATA SSD的長度，鎖固螺絲到合適的
安裝孔上
根据M.2 SATA SSD的长度，锁固螺丝到合适的
安装孔上
使用するM.2 SATA SSDの長さに応じて、適合
する穴にネジで固定します
사용된 M.2 SATA SSD의 길이에 따라 적합한
장착 구멍에 나사를 고정합니다
Place the assembled MS09 PCB back into the
enclosure with M.2 SATA SSD facing down as
shown in the photo
Montierte MS09-Leiterplatte wieder im Gehäuse
platzieren, wobei die M.2-SATA-SSD wie
abgebildet nach unten zeigt
Remettez le circuit imprimé du MS09 assemblé
dans le boîtier avec le SSD SATA M.2 orienté
vers le bas comme indiqué dans la photo
Coloque el PCB de la MS09 de nuevo en la
carcasa con el SSD SATA M.2 hacia abajo como
se ve en la foto
Riporre la PCB di MS09 montata nel box con
l'SSD SATA M.2 rivolto verso il basso, come
mostrato nella foto
Поместите собранную плату обратно в корпус
MS09 M.2 SATA SSD вместе с лицевой стороной
вниз, как это показано на фото
將MS09的電路板放置於上蓋如圖示，
此時M.2 SATA SSD在下方
将MS09的电路板放置于上盖如图示，
此时M.2 SATA SSD在下方
組み込まれたMS09 PCBを、写真のようにM.2 SATA
SSDを下向きにしてエンクロージャーに戻します
사진에 표시된 대로 M.2 SATA SSD가 아래를
향하게 하여 조립된 MS09 PCB를 인클로저에
도로 조립합니다
Place the push button on the corresponding
position as shown in the photo
Drucktaste wie abgebildet an der
entsprechenden Position platzieren
Placez le bouton poussoir dans la position
correspondante comme indiqué dans la photo
Coloque el botón en la posición
correspondiente como se muestra en la foto
Collocare il pulsante nella posizione
corrispondente, come mostrato nella foto
Разместите кнопку на соответствующей
позиции, как это показано на фото
將按鈕放置於正確位置如圖示
将按钮放置于正确位置如图标
写真のように押しボタンをお対応する位置に設置
します
사진에 표시된 대로 푸시 버튼을 해당 위치에
배치합니다
Secure bottom cover to the enclosure
with screws to finish installation
Zum Abschließen der Installation untere
Abdeckung mit Schrauben am Gehäuse
sichern
Fixez le couvercle inférieur sur le boîtier
avec les vis pour terminer l'installation
Fije la cubierta inferior a la carcasa con
tornillos para finalizar la instalación
Fissare la copertura inferiore al box con
viti per terminare l'installazione
Прикрепите нижнюю крышку к корпусу с
помощью винтов завершения для
установки
蓋上底蓋，鎖固螺絲完成安裝
盖上底盖，锁固螺丝完成安装
底面カバーをエンクロージャーにいネジ
止めすると、インストールは完了です
나사를 사용하여 하단 커버를 인클로저에
고정합니다
