Seite 1/16
SB-5548BNC
8x8 Composite Video Matrix Routing Switcher w/ Stereo Audio (BNC)
INSTRUCTION MANUAL
SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of îżre, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit from AC current before making connections.
11. Never hold a power switch in the âONâ position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
îow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically âblown freeâ of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualiîżed service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports îżrst, then remove the power cable; îżnally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualiîżed service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain.
D. The equipment does not appear to operate normally, or exhibits a marked change in performance.
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL.
CONTENTS
INTRODUCTION ..............................................................1
FEATURES & SPECIFICATIONS .....................................2
FRONT PANEL ................................................................3
BACK PANEL ..................................................................6
REMOTE CONTROL .......................................................7
REMOTE PROTOCOL COMMANDS .............................8
IR EXTENDER ...............................................................9
RS-232 SERIAL INTERFACE .........................................10
TYPICAL APPLICATION ..............................................11
INTRODUCTION
Congratulations on your purchase of one of the most innovative 8x8
AV (Composite Video-BNC/Audio) with adjust audio volume & balance
matrix switching products on the market today. The SB-5548BNC is a true
matrix routing switcher for AV (Composite & Stereo Audio) signals. Full
support for NTSC or PAL Composite Video & Stereo Audio TV systems.
The SB-5548BNC has (8) individual Composite Video (BNC connector)
and Stereo Audio inputs with (8) individual Composite Video (BNC
connector) and Stereo Audio outputs. Audio outputs control and adjust
volume and AR/AL balance. Because it is a matrix router, any input may
be routed to any output; or the same input may be routed to all outputs
or any combination. It completely eliminates the need to constantly move
around video audio input and output cables. The switcher is useful for
matrix signals from composite video and stereo audio source devices
(such as: VCRs, Camcorders, Video Game Consoles, Video CDs, DVDs,
Satellite Receivers, CAT5 Set Top Boxes, etc.) to composite video/
audio destination devices (such as: LCD TV, HDTV, Plasma displays,
Projectors, etc.). Selection of inputs can be made via the front panel push
buttons or an infrared remote control or RS-232 control with a computer.
A RS-232 Windows GUI interface is provided for matrix routing control
(Windows only).
PACKAGE CONTENTS
Check that you have the following components;
⢠SB-5548BNC 8x8 Matrix Switcher
⢠RS-232 V2.0 Protocol Instructions
⢠IR Remote Control (SW-5548BNC)
⢠19 inch ear mount bracket (Part # 1U-440L)
⢠SB-100 IR Extender Receiver Set
⢠CD Contents: This manual, Windows GUI, ISP V1.0 Windows driver
⢠RS-232 Cable 6 feet (2M)
⢠Users Guide
⢠Power Supply Input: DC12V, 2A, (Worldwide Universal 100~230
VAC, AC 50/60Hz)
â˘î Optional:îSB-100CîIRîExtenderîReceiverîCableî(6.5ftî(2M))
1
Composite Video-Stereo Audio Matrix Switcher Series
ThankîyouîforîpurchasingîtheîSB-5548BNCî8x8îCompositeîVideo-AudioîMatrixîSwitcher.îYouîwillîîżndîthisîunitîeasyîtoîinstallî
andîhighlyîreliableîbutîitîisîessentialîthatîyouîreadîthisîmanualîthoroughlyîbeforeîattemptingîtoîuseîthisîswitcher.
TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
⢠Always follow basic safety precautions to reduce the risk of îżre,
electrical shock and injury to persons.
⢠To prevent îżre or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
⢠Never spill liquid of any kind on or into this product.
⢠Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
⢠Do not attach the power supply cabling to building surfaces.
⢠Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
⢠Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
⢠To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufîżcient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer îżle, in any form or by any means
â electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise â without express written permission and consent.
Š Copyright 2017. All Rights Reserved.
Version 2.4 SEPT 2017
Version No.: 5548BNC-20160222-003
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
