SK-R01
Shoulder
Support Rig
The SK-R01 Shoulder Support Video Stabilizer is a support that
features two-point Stabilization using a shoulder mount and a
hand grip.
Thank you for choosing Sevenoak and congratulations on your
Purchase of the Sevenoak SK-R01 Shoulder Support Rig.
The Sevenoak Shoulder Support Rig is a compact camera
stabilization rig that uses a comfortable foam padded shoulder
pad mount and a hand grip to help you support your camera
and keep it steady when shooting video.The SK-R01 reduces
muscle fatigue,while eliminating distracting camera move
-ment for smoother,more professional-looking movies.It can
support cameras weighing up to 5.5 pounds.
The SK-R01 is height-adjustable and can be used on the left
or the right shoulder,with a hand grip thatâs detachable and
can be used as a stand-alone support for lightweight cameras.
The SK-R01 weighs just 2.25 pounds.
4. Mount the hand grip to the shoulder mount frame by
screwing the end of the hand grip into the hole provided
at the end of the camera baseplate.Align the hand grip
correctly to the hole,which is angled slightly.Tighten the
hand grip securely.
7. Adjust the distance of the camera from your eye by loosening
the baeplate mounting screw slightly and sliding the camera
forward or back to the desired position.Tighten the screw
securely. Do not overtighten.
8. To adjust the vertical position of the camera,loosen the
shoulder mount frame mounting plate screw and slide the
shoulder mount frame up or down to the desired position.
Tighten the screw securely.Do not overtighten.
When youâre ïŹnished shooting,remove the camera from the
shoulder mount.
Slots on end of the shoulder pad may be used for additional
accessories such as counterweights and shoulder straps.
5. Screw the camera mounting screw into the camera baseplate
using one of the holes provided.
6. Attach the camera to the baseplate using the camera
mounting screw.Tighten securely.
1. Install the shoulder pad mounting plate on to the shoulder
pad using the two included Allen screws and the included
Allen wrench.If the Sk-R01 will be on the right shoulder,place
the plate so that the long part of the plate extends to the
right of the screws.If the left shoulder will be holding the
support,the long part of the plate should extend to the left
of the screws.
2. Attach the shoulder mount frame to the shoulder pad using
the shoulder mount frame mounting plate and the included
shoulder mount frame mounting plate screw.With the screw
in place,you can adjust the vertical height of the rig by
loosening the screw slightly and moving the shoulder mount
frame up or down until itâs at desired height.Then tighten the
mounting screw securely.Do not overtighten.
3. Attach the camera baseplate to the shoulder mount frame
using the baseplate mounting plate and the baseplate
mounting plate screw.After the baseplate is munted to the
shoulder mount frame,you can adjust the baseplate by
loosening the screw and sliding the baseplate forwards or
back.When the baseplate is in the correct position,tighten
the mounting screw securely.Do not overtighten.
Please read and follow these instructions,and keep this
manual in a safe place.
Handle the unit with care.
Clean the unit with a soft,dry cloth.
Use only parts provided by the manufacturer.
Make sure everything is secure before proceeding.
Make sure the item is intact and that there are no missing parts.
Do not exceed the maximum load capacity.
All photos are for illustrative purposes only.
Hand grip may be used as a
standalone grip for smaller
cameras.
Threaded holes in camera
baseplate may be used to
mount accesories with the
use of brackets.
Removable hand grip
Foam shoulder pad
Stainless steel shoulder mount frame
Camera baseplate
Camera mounting screw
Shoulder pad mounting plate with two
Allen screws (+1 spare)
Allen wrench
Mounting the camera
Components
Warnings
Shoulder mount frame mounting plate
with one screw
Baseplate mounting plate with one screw
Limited one-year Warranty
Sevenoak provides a limited warranty that this product is free
from defects in materials and workmanship to the original
purchaser under normal use for a period of one (1) year from
the original purchase date or thirty(30) days after replace-ment
(theâWarranty Periodâ),Whichever occurs later.Our responsibility
with respect to this limited warranty shall be limited solely to
repair or replacement,at its option,of any product which fails
during normal consumer use.
To obtain warranty coverage during the Warranty Period,
contact your place of purchase(âSellerâ) to obtain a return
merchandise authorization(âRMAâ) number,and return to
Seller the defective Product along with proof of purchase and
the RMA number.
This warranty does not extend to damage or failure which
results from misuse,neglect,accident,alteration,abuse,improper
installation or mainterance.EXCEPT AS PROVIDED HEREIN,
SEVENOAK MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES,INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.This warranty provides you with speciïŹc
legal rights,and you may also have additional rights which vary
from state to state.
2017 Sevenoak Inc.Visit us on the
web at www.sevenoak.biz
2017 Sevenoak Inc.Visit us on the
web at www.sevenoak.biz
