Assembly Instructions:
SEDONA L400CART
L500CART
& L600CART
Lynx Freestanding Cart
Model L400CART, L500CART &L600CART
Lynx Grills, Inc., 6023 E. Bandini Blvd. Commerce, CA 90040 Ph
Document 33807 Rev C 02/08/13
Step 1.
Step 2.
Step 3.
Step 1.
Aer opening and idenfying the components, select the back
panel assembly and either the right or leî…ł side panel assembly.
Orient the parts as shown in the illustraon for . step 1
Note that these parts are upside down with the shelves at the
î…®oor. Hook the right or leî…ł side to the back into the four keyways
located on the edge. When aached all four keyways should be
engaged and the back and side î…®ush to the top.
Repeat this step for the opposite side panel.
Step 2.
With the cart oriented upside down, locate the 4 - #8 screws and
nuts and mount the electrical transformer to the access plate
shown in the illustraon for this step. It may be done at the end of
the assembly but is somewhat easier to access at this stage.
Step 3.
Refer to the î…•gure for and insert the base assembly into the step 3
cavity at the back corners of the cabinet. Check that the tank hole
is posioned as shown and the magnet is located on the open side.
Splay the two sides out slightly and enclose them over the front of
the base. The sides and back have pockets that î…•t over the casters
for clearance. Use 4 of the ¼-20 x ½ screw at each corner to lock
the assembly in place.
Access
Plate
magnet
tank
hole
Screw
4 places
Introducon:
Your Freestanding Cart comes with all of the components necessary
to assemble a cart for the SEDONA Series of Lynx Grills.
The SEDONA CART series is comprised of 8 sub assemblies:
1. Back Panel Assembly
2. Right Side Panel Assembly with Shelf
3. Leî…ł Side Panel Assembly with Shelf
4. Base Assembly with Wheels
5. Inner Shelf Assembly
6. Cross Brace Assembly
7. Right Door
8. Leî…ł Door
In addion there are 14 screws (1/4 -20 x ½) to assemble the
cart and grill and 4 screws with nuts (#8-32 x 3/8) to aach the
transformer assembly supplied with the Grill.
Step 4.
Step 5.
To begin turn the cabinet upright to secure the step 4
Inner Shelf Assembly. The and shelf will only L400 L500
assemble as shown at the right with the electrical hole to
the rear and the screws mounng at the back and le
side. The shelf is not only useful but necessary for the
proper stability of the cart. omit the inner shelf DO NOT
or any part in these instrucons.
The inner shelf is secured by 4 of the ¼-20 x ½ screws.
Two through the back and two through the leî…¨ side.
The shelf as shown here assemble L600 will
the same as above.
Step 5 L400/L500 is the last assembly on the cart before
installing the Grill to the cart. The cross brace î…Šts into
recesses located at the front edge of the cart above the
hinge brackets. Orient the brace with the center magnet
facing forward and posioned such that the magnet is
higher than center rather than lower. Install the brace from
the backside of the î…Łanges and align the nutcerts each at
end with the holes provided for the screws. The brace is
secured by 2 of the ¼-20 x ½ screws.
The door frame is aached along with the cross brace . L600
Support the cross brace from the backside of the front
î…Łanges. Align the nutcerts each end with the holes at
provided for the screws. Posion the door frame over the
nutcerts and cross brace , and secure them both with the ÂĽ-
20 x ½ screws.
Step 4 .
L400
L500
Step 4 .
L600
Step 5.
L400
L500
Step 5.
L600
With assistance, remove all packing materials from the grill.
Also remove the grates and warming racks to lighten the
assembly. The grill will be placed onto the cart as
illustrated in this step. The back edge will engage î…Ťrst and
the front will slide down into posion unl horizontal.
Using two people with gloves - grasp the front and side of –
the Grill at points A and B. Place the unit on the cart and
lower it slowly unl horizontal.
Do not grip grill by the
control knobs as damage
may occur
Step 6.
Four screws remain in the package for assembly.
To secure the grill to the cart locate 4 screws at the i
corners of the î…Ťrebox. Remove and discard the 4 scr
these locaons. Replace them one at a me with the
screws from the kit.
The leî…« and right hand doors now assemble to the c
shown.
Refer to the installaon manual provided with the gr
proper electrical and gas connecons.
B
A
Step 7.
2
4
1
3
Drop the door hinge
pins into the
corresponding door
hinge on the frame.
Step 6.
Step 5.
L600
