Note: Products with model numbers that end with “Q” or that have a round green “Q” sticker are RoHS compliant.
Extenders for HDMI
over Single Cat5e/6
Manual
Extend HDMI signals up to 230ft (70m) at 1080p over a single Cat5e/6 cable
Plug and play operation comes as a complete set –
Choose from either a tabletop model (MVE-AT -0 Q) or a double-11 1N gang
wall-plate model (MVE-AT11-W1N Q)
The tabletop and wall-plate models are compatible with each other. Mix
and match the transmitter from one model to the receiver of the other.
MVE-AT11-01NQ
Extender for HDMI over Cat5e/6
MVE-AT11-W1NQ
Wall-plate Extender for HDMI over Cat5e/6
MVE-AT11-01NQ
MVE-AT11-W1NQ
ENFORCER Enhanced Extenders for HDMI® over Single Cat5e/6
2 SECO-LARM U.S.A., Inc.
Introduction:
The ENFORCER Enhanced Extenders for HDMI over Single Cat5e/6 extend the range of HDMI
signals by using an active transmitter and receiver to send video and audio over a single Cat5e/6
cable. 1080p HDMI Signals can be transmitted up to ft (70m) between the two units with zero 230
signal loss. The extender supports IR signals using the included adapters, allowing the user to use
a remote control from one end of an installation to control a device such as a TV or media player at
the opposite end of the installation.
Features:
Signal Strength Active operation ensures that the signal strength will remain strong over –
the length of the cable.
Distance – The Enhanced Extenders for HDMI over Single Cat5/e6 can transmit a clear
HDMI signal up to 2 ft (70m). 30
Formats Supported The Enhanced Extenders for HDMI over Single Cat5e/6 support both –
progressive and interlaced formats: 1080p/1080i/720p/576p/576i/480p/480i.
Plug and Play The Enhanced Extenders for HDMI over Single Cat5e/6 come as a complete –
set consisting of a transmitter, receiver, power supplies, and IR adapters. No adjustments or
settings be made. The unit is ready to use right out of the box.need to
Zero Signal Loss Integrated circuits in the transmitter and receiver clean, buffer, and –
amplify the HDMI signal. This prevents signal loss and ensures a clear signal regardless of
the length of the cable up to the maximum range.
Connect Multiple Units – Repeat sets to extend HDMI range up to 918ft (280m).up to four
Mix and Match The tabletop and wall-plate models are compatible with each other. –
Connect a transmitter from one model to the receiver of another.
Specifications:
Input video sig nal
0.5~1.0 Vp-p
Input DDC signal
5Vp-p (TTL)
Maximum single link range
1920x1200, 1080p
Deep color
36-bit
Video formats supported
High-speed HDMI with 3D, HDCP 1.2
Audio formats supported
LPCM, Dolby-AC3, DTS 7.1, DSD
Output video
HDMI
Resolutions supported
1080p/1080i/720p/576p/576i/480p/480i
Range 1080p –
Cat6: Up to 230 70m) ’ (
Video amplifier bandwidth
10.2Gbps
Cat5e/6 Wiring standard
T568-B
Operating voltage
5VDC
Power supply
2A@5VDC (2 adapters) (2.1mm plug)
Current draw
Transmitter
450mA@5VDC
Receiver
900mA@5VDC
Operating temperature
5°~ ° F (-15°~55° C) 131
Operating humidity
5~90% RH (no condensation)
Dimensions
MVE-AT11-01NQ
45
/16 ”x215/16 ”x7/8” (110x75x23 mm)
MVE-AT11-W1NQ
41
/16”x41/2”x5/16” (116 34x115x mm)
Weight
MVE-AT11-01NQ
9.2-oz (260g)
MVE-AT11-W1NQ
9.3-oz (264g)
ENFORCER Enhanced HDMI® Extenders over Single Cat5e/6
SECO-LARM U.S.A., Inc. 3
Overview:
Back View
Front View
MVE-AT11-01NQ
Top View
Front View
MVE-AT11-W1NQ
Top View
Installation:
1. Determine where the transmitter and receiver will be wired as well as how much Cat5e/6 cable
will be necessary.
2. Connect the HDMI cable to both the transmitter and the source device.
3. Connect the HDMI cable to both the receiver and the display.
4. Connect the Cat5e/6 cable to both the receiver and transmitter units.
Note: For best results, use Cat6 cable.
5. Connect one 5VDC adapter to the transmitter and another to the receiver.
6. Determine which device, if any, will be controlled by the remote control. Install the IR
transmitter to the IR-TX port of the closest extender unit, pointing the IR transmitter at the
device. Install the IR receiver to the IR-RX port of the other extender unit. Point the remote
control at the IR receiver when in use.
7. gang box. MVE-AT11-W1NQ Only: Install the MVE-AT11-W1NQ using a standard double-
8. Switch on the HDMI source and display to verify that the system is functioning properly.
Steady ON
Flashing
OFF
Active
N/A
Unit is working
Unit is not
working/powered
Link
Connection OK
Check connection
Not connected
HDCP
Video has HDCP
Video does not have
HDCP
No video
Power
Power ON
Check power
Power OFF
45
/16”
7/8
”
Status LED Chart:
Status LEDs
Status LEDs
HDMI Port
HDMI Port
5VDC
Power input
RJ45 Port
5VDC
Power input
IR Adapter ports
IR Adapter
ports
Parts List
1 x Transmitter
1 x Receiver
2 x 5VDC Power adapters
1 x IR Transmitter
1 x IR Receiver
1 x Manual
41
/2” (114mm)
49/16”
(116mm)
15
/16”
(34mm)
Extender for HDMI over Cat5e/6
215/16
”
(75mm)
www.seco-larm.com
Please use T568-B wiring standard.
Extender for HDMI over Cat6e/6
HDMI In
Note: Only transmitters are shown above. The transmitters and receivers have the same dimensions and similar parts.
