Seite 1/56
GB
1
Contents
Installation, 2-3-4-5
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Instructions for the fitter
Care and maintenance, 6
Cutting off the water or electricity supply
Cleaning the washing machine
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Precautions and tips, 7
General safety
Disposal
Opening the porthole door manually
Description of the washing machine, 8-9
Control panel
Display
Running a wash cycle, 10
Wash cycles and functions, 11
Table of wash cycles
Wash functions
Detergents and laundry, 12
Detergent dispenser drawer
Preparing the laundry
Special wash cycles
Load balancing system
Troubleshooting, 13
Service, 14
SMLE 129
Instructions for use
WASHING MACHINE
English,1
GB ES
Español,29Français,15
F
Italiano,43
I
2
GB
Installation
! This instruction manual should be kept in a safe
place for future reference. If the washer dryer is
sold, transferred or moved, make sure that the
instruction manual remains with the machine so
that the new owner is able to familiarise himself/
herself with its operation and features.
! Read these instructions carefully: they contain
vital information relating to the safe installation
and operation of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washer dryer from its packaging.
2. Make sure that the washer dryer has not been
damaged during the transportation process. If it
has been damaged, contact the retailer and do not
proceed any further with the installation process.
3. Remove the pro-4
tective screws (used
during transportation)
and the rubber washer
with the corresponding
spacer, located on the
rear part of the applian-
ce ( ).see figure
4. Close off the holes using the plastic plugs
provided.
5. Keep all the parts in a safe place: you will
need them again if the washer dryer needs to
be moved to another location.
! Packaging materials should not be used as
toys for children.
Levelling
1. Install the washer dryer on a flat sturdy floor,
without resting it up against walls, furniture ca-
binets or anything else.
2. If the floor is not per-
fectly level, compensa-
te for any unevenness
by tightening or loo-
sening the adjustable
front feet ( ); see figure
the angle of inclination,
measured in relation to
the worktop, must not
exceed 2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive
noise and prevent it from shifting while it is ope-
rating. If it is placed on carpet or a rug, adjust
the feet in such a way as to allow a sufficient
ventilation space underneath the washer dryer.
Connecting the electricity and wa-
ter supplies
Connecting the water inlet hose
1. Connect the supply
pipe by screwing it to
a cold water tab using
a ¾ gas threaded con-
nection (see figure).
Before performing the
connection, allow the
water to run freely until
it is perfectly clear.
2. Connect the inlet
hose to the washer dr-
yer by screwing it onto
the corresponding wa-
ter inlet of the applian-
ce, which is situated on
the top right-hand side
of the rear part of the
appliance . (see figure)
3. Make sure that the hose is not folded over
or bent.
! The water pressure at the tap must fall within
the values indicated in the Technical details table
(see next page).
! If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
! Never use second-hand hoses.
! Use the ones supplied with the machine.
GB
3
65 - 100 cm
Connecting the drain hose
Connect the drain
hose, without bending
it, to a drainage duct or
a wall drain located at a
height between 65 and
100 cm from the floor;
alternatively, rest it on
the side of a washba-
sin or bathtub, faste-
ning the duct supplied
to the tap (see figure).
The free end of the
hose should not be
underwater.
! We advise against the use of hose extensions;
if it is absolutely necessary, the extension must
have the same diameter as the original hose and
must not exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
• the socket is earthed and complies with all
applicable laws;
• the socket is able to withstand the maximum
power load of the appliance as indicated in the
Technical data table (see opposite);
• the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
• the socket is compatible with the plug of the
washer dryer. If this is not the case, replace the
socket or the plug.
! The washer dryer must not be installed ou-
tdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to
rain, storms and other weather conditions.
! When the washer dryer has been installed, the
electricity socket must be within easy reach.
! Do not use extension cords or multiple sockets.
! The cable should not be bent or compressed.
! The power supply cable must only be replaced
by authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle .
Technical details
Model SMLE 129
Dimensions
59,5 cm wide
81,5 cm high
54,5 cm deep
Capacity from 1 to 7 kg
Electric
connections
Please refer to the technical
data plate fixed to the ma-
chine.
Water
connections
maximum pressure 1 MPa
(10 bar) minimum pressure
0.05 MPa (0.5 bar) drum
capacity 52 litres
Spin speed up to 1200 rpm
Test wash
cycles in
accordan-
ce with
directives
1061/2010
and
1015/2010
Programme (1° press of
the button): Standard Cotton
60°C;
Programme (2° press of
the button): Standard Cotton
40°C.
This appliance is compliant
with the following European
Community Directives:
- 2004/108/CE (Electroma-
gnetic Compatibility)
- 2006/95/CE (Low Voltage)
- 2002/96/CE
