WSWM SONOS® SPEAKER MOUNT INSTRUCTION MANUAL
2
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ENTIRE MANUAL PRIOR TO USE SAVE THESE INSTRUCTIONS CAUTION: — —
Do you own a Sonos® PLAY:1 or PLAY:3 speaker? ™ ™
This speaker mount is designed to support PLAY:1 and PLAY:3 speakers.
Weight Limit: 10 lb (4.5 kg)
Ready to begin?
Check your speaker owners manual to see if there are any special requirements for mounting your speaker.
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Do not use this product for any purpose not explicitly specifi ed by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
The wall must be capable of supporting fi ve times the weight of the speaker and mount combined.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact
Customer Service at 1-800-359-5520 (UK: 0800-056-2853).
Do you have all the tools needed?
Before getting started, let’s make sure this product is perfect for you!
1
2
3
Wood Stud Install
Concrete Install
Wallboard Install
Pencil Level Screw
driver Electric
Drill Stud
Finder Awl Wood
Drill Bit Masonry
Drill Bit Hammer
Wallboard
Drill Bit
1/4 in.
(6.4 mm)
1/4 in.
(6.4 mm)
1/8 in.
(3 mm)
3
SPEAKER INTERFACE
WALL PLATE
SIDE VIEW - NO SPEAKER
TOP VIEW - SONOS PLAY:1
TOP VIEW - SONOS PLAY:3
SIDE VIEW - SONOS PLAY:1
SIDE VIEW - SONOS PLAY:3
3-D
2xø0.26 in.
[6.6mm]
ø0.20 in.
[5.1mm]
THRU ø3.00 in.
[76.3mm]
PLAY:3 BRACKET
(INCLUDED)
8.81 in.
[223.9mm]
TRUE ø0.20 in.
[5.1mm]
2.78 in.
[70.5mm]
3.98 in.
[101.2mm]
0.45 in.
[11.5mm]
2.21 in.
[53.3mm]
3.83 in.
[97.3mm]
1.99 in.
[50.6mm]
35º
70º
132º
27º
30º
9.05º
9.05º
66º
Dimensions
