Air conditioner
Installation manual
MCU-S6NEK2N / MCU-S4NEK3N / MCU-S2NEK2N / MCU-S1NEK1N /
MCU-S12NEK1N / MCU-S8NEK1N
Thank you for purchasing this Samsung air conditioner.
Before operating this unit, please read this installation manual carefully and retain it for future reference.
2
Safety precautions ..........................................................................................................................................................................................................................3
Mesures de sécurité .......................................................................................................................................................................................................................5
Preparing the installation ............................................................................................................................................................................................................7
Space requirements ....................................................................................................................................................................................................................10
Refrigerant piping ........................................................................................................................................................................................................................17
Wiring ................................................................................................................................................................................................................................................20
MCU Installation Checklist .......................................................................................................................................................................................................31
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from
other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government oce, for
details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and
its electronic accessories should not be mixed with other commercial wastes for disposal.
(For India only)
For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or contact our
Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864)
1800 5 SAMSUNG (1800 5 7267864).
For correct disposal of this product, please visit http://www.samsung.com/weee.pdf
Points de collecte sur www.quefairedemesdechets.fr
!
REPRISE
À LA LIVRAISON À DÉPOSER
EN MAGASIN À DÉPOSER
EN DÉCHÈTERIE
OU OU
FR
Cet appareil,
ses accessoires,
piles et cordons
se recyclent
3
The safety information and precautions below must be kept for the safety of users and installers.
Before installing an air conditioner, please read this manual thoroughly to ensure that you know how to safely and
eciently install a new appliance.
J This product uses R-410A refrigerant.
When using R-410A, moisture or foreign substances may aect the capacity and reliability of the product.
Safety precautions must be taken when installing the refrigerant pipe.
The designing pressure of the system is 4.1MPa. Select appropriate material and thickness according to the regulations.
R-410A is a quasi-azeotrope of two refrigerants.
Make sure to charge with liquid phase whenlling refrigerant.
If you charge gaseous refrigerant, it may aect the capacity and reliability of the product as a result of change formation of the refrigerant.
J Connect the indoor units for R-410A refrigerant. Check whether the indoor units can be connected with the product’s
catalogue. (When incorrect indoor units are connected, they cannot operate normally.)
J
After installation and trial operation, explain to the customer how to use the air conditioner and give the installation manual to the user.
J The manufacturer is not responsible for accidents due to incorrect installation. Any claims caused by failing to keep the safety
precautions are installer’s responsibility. (The installer is responsible for the service cost.)
J This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
J If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
WARNING
In case of not following the safety precautions, the service agent or the user may get the risk of
serious wound or death.
CAUTION
In case of not following the safety precautions, the service agent or the user may get the risk of
injury or loss of property.
FOR INSTALLATION
WARNING
Installation must be done by the installer or its service agent.
XInstallation by an unqualified person may cause a water leakage, electric shock orre and so on.
Install the unit correctly according to the installation manual.
XAn incorrect installation may cause a water leakage, electric shock or fire.
When installing the unit in a small place, take measures in order to keep the refrigerant concentration from exceeding allowable
safety limits in the event of a refrigerant leak.
XExcessive refrigerant concentration can lead to suffocation.
If any gas or impurities except R-410A refrigerant get into the refrigerant pipe, serious problems may occur and this may cause injury.
When installing the unit, only use the components and tools which are specied for the installation.
XUsing the uncertified components and tools may cause a unit fall, water leakage, electric shock, and are.
(Never use the components and pipe for R-22 refrigerant)
Install the unit safely on a place that can support its weight.
XIf the place cannot support its weight, the unit may fall down and cause injury.
Check out the safety precautions below before installing or xing the unit.
XBefore welding the unit, you must remove all the hazardous materials around the unit that may cause an explosion and are.
XWhen refrigerant is in the product or the pipe before welding the unit, you must remove the refrigerant.
If you weld the unit when there is refrigerant inside, the increased pressure of refrigerant may explode or break the leaking spot so that
causes serious injuries.
XWhen welding the unit, please use nitrogen gas to prevent oxide from generating in the pipe
Make sure to cut o all the power supply before installing, xing, and cleaning the unit.
When the electric wire is damaged, you must exchange it by the manufacturer or its service agent, or a person who has the
equivalent qualication.
When turning on the power, make sure to connect the power supply to the circuit breaker designated for indoor units. (ELCB, ELB, MCCB)
XIf you do not install the circuit breaker for MCU(ELCB, ELB, MCCB), excessive current or failure to blocking the power supply may cause
electric shock, a fire.
Safety precautions
