You can access the User Guide on Samsung’s on-line customer support
center by scanning the QR code on the left.
To see the manual on your PC or mobile device, download the manual in
document format from Samsung’s website.
(http://www.samsung.com/support)
Simple User Guide
HW-S81*D / HW-S71*D
ENG - 2
English
SAFETY INFORMATION
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols
which may be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK. DO
NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any
kind of contact with any internal part of
this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates
that a safety connection to electrical earth
(ground) is not required.
If this symbol is not present on a product
with a power cord, the product MUST have
a reliable connection to protective earth
(ground).
AC voltage : Rated voltage marked with
this symbol is AC voltage.
DC voltage : Rated voltage marked with
this symbol is DC voltage.
Caution. Consult Instructions for use :
This symbol instructs the user to consult
the user manual for further safety related
information.
WARNING
• To reduce the risk of re or electric shock, do not
expose this appliance to rain or moisture.
CAUTION
• TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• This apparatus shall always be connected to a AC
outlet with a protective grounding connection.
• To disconnect the apparatus from the mains, the plug
must be pulled out from the mains socket, therefore
the mains plug shall be readily operable.
• Do not expose this apparatus to dripping or
splashing. Do not put objects î©Łlled with liquids, such
as vases, on the apparatus.
• To turn this apparatus off completely, you must pull
the power plug out of the wall socket. Consequently,
the power plug must be easily and readily accessible
at all times
PRECAUTIONS
1. Ensure that the AC power supply in your house
complies with the power requirements listed on
the identiî©Łcation sticker located on the bottom of
your product. Install your product horizontally, on a
suitable base (furniture), with enough space around
it for ventilation (7~10 cm). Make sure the ventilation
slots are not covered. Do not place the unit on
ampliî©Łers or other equipment which may become
hot. This unit is designed for continuous use.
To fully turn off the unit, disconnect the AC plug from
the wall outlet. Unplug the unit if you intend to leave
it unused for a long period of time.
2. During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the unit.
3. Do not expose the unit to direct sunlight or other
heat sources. This could lead to overheating and
cause the unit to malfunction.
4. Protect the product from moisture (i.e. vases),
and excess heat (e.g. a î©Łreplace) or equipment
creating strong magnetic or electric î©Łelds. Unplug
the power cable from the AC wall socket if the
unit malfunctions. Your product is not intended
for industrial use. It is for personal use only.
Condensation may occur if your product has been
stored in cold temperatures. If transporting the unit
during the winter, wait approximately 2 hours until
the unit has reached room temperature before using.
5. Fire or explosion may occur, resulting in damage to
the remote control or personal injury.
• Do not apply shock to the remote control.
• Be careful not to let foreign substances such as
metal, liquid, or dust come in contact with the
charging terminal of the remote control.
• When the remote control is damaged or you
smell smoke or burning fumes, immediately
stop operation and then repair it at the Samsung
service centre.
• Do not arbitrarily disassemble the remote control.
• Be careful not to let infants or pets suck or bite
the remote control. Fire or explosion may occur,
resulting in damage to the remote control or
personal injury.
ENG - 3
01 CHECKING THE
COMPONENTS
• Soundbar Main Unit
• Soundbar Remote
Control
• Subwoofer
• Power Cord X
2 (Subwoofer,
Soundbar)
• AC/DC Adapter
• HDMI to Micro HDMI
Cable
• Wall Mount Guide
• Holder-Screw X 2
• Screw (M5 X L55) X 4
• Screw Anchor X 4
• Bracket-Wall Mount
X 2
NOTE
• For more information about the power supply and
power consumption, refer to the label attached to the
product. (Label: Bottom of the Soundbar Main Unit)
• To purchase additional components or optional
cables, contact a Samsung Service Center or Samsung
Customer Care.
02 PRODUCT OVERVIEW
Top Panel of the Soundbar
Volume
1
HW-S81*D
HW-S71*D
(Multi Function) Button
In standby mode, press the (Multi Function)
button to turn on the Soundbar.
Press the (Multi Function) button to change
the mode.
(Mic On/Off) Button
Press the button to turn the microphone on or
off.
When the microphone is off, the LED indicator
will light red.
1 LED indicator
The LED Indicator ashes, glows, or changes
color depending on the Soundbar’s current mode
or status.
(Power) Button
Turns the power on and off.
(Source) Button
Press the (Source) button to change the
input source.
• To switch to Bluetooth Pairing state in “Bluetooth”
mode, press and hold the or (Mic On/Off)
(Source) button on the top of the Soundbar for
more than 5 seconds.
Rear Panel of the Soundbar
SERVICE
HDMI
(eARC)
DC 19V
SERVICE
HDMI
(eARC)
DC 19V
3
1
2
1SERVICE
Connect a USB storage device to upgrade the
product’s software.
2HDMI (eARC)
Connect to the HDMI jack on a TV.
3DC 19V
Connect the AC/DC power adapter.
(Power Supply In)
03 CONNECTING THE
SOUNDBAR
Connecting the power and units
Rear of Subwoofer
Blue Blinks
POWER
POWER
HW-S71*D HW-S81*D
DC 19V DC 19V
Rear of the Soundbar
Main Unit
• The LINK LED indicator stops blinking and glows a
solid blue when a connection is established between
the Soundbar and the Wireless Subwoofer.
