DISHWASHER
REPAIR Guide
DISHWASHER
Basic Model : DW60R7070 Series
DW60R7050 Series
DW60R7040 Series
Model Name : DW60A8070 Series
DW60A8060 Series
DW60A8050 Series
DW60A8040 Series
Model Code : DW60A8070BB, DW60A8070US,
DW60A8060BB, DW60A8060IB,
DW60A8060FS, DW60A8060FW,
DW60A8050BB, DW60A8050US,
DW60A8050FS, DW60A8040BB
DW60A8040IB
* For End User.
IMPORTANT SAFETY NOTICE
Following the repair by a non-authorized service provider self-repair or
non-professional repair of the product Samsung is not liable for any
damage to the product any injury or any other product safety issue caused
by any attempt to repair the product which does not carefully follow these
repair and maintenance instructions. Any damage to the product caused by
an attempt to repair the product by any person other than a Samsung
certified service provider will not be covered by the warranty.
All rights reserved.
This service guide may not be reproduced in whole or
as a part in any form whatsoever without the written permission of
the SAMSUNG ELECTRONICS Company.
WARNING
Note
1. You can check where to buy replacement parts at http://samsung.com
2. Visit the part purchase site and enter the model code of your product to check the parts available
for purchase. The model code is labelled on the edge of the tub. When you open the dishwasherās
door, you can check the model code and version on the barcode label at the left side of the tub.
3. For replacement parts make sure the part name matches that of the illustration in this manual.
- User-serviceable parts are limited to door hinge and seals other seals spray arms drain īlters
interior racks and plastic peripherals such as baskets and lids.
Caution
1. The part name listed on the site may differ from that in this manual. Please make sure you choose
the right part name.
2. Be sure to wear safety gloves while making repairs.
3. Must working more than 2 people to handling heavy weight.
Disassembly and Reassembly _ 3
1. TOOLS FOR REMOVAL AND REASSEMBLY
Tool image
No. Tool Type Remarks
ā Adjustable Wrench
ā”Open-end Wrench 1-7/16ā
ā¢Vice Pliers
ā£Others
(screwdriver, nipper, long nose pliers)
Common tools for servicing
Screwdriver ā Phillip, Flat, Torx T15
ā¤Ear clamping tool In reassembling of the clamp-bend(ear clamp) using our
SVC part, this tool is needed.
NOTE :
Preparation for parts replacement
1. Remove the residual water inside the product. (Drain the water by operating the drain pump)
2. Close the water supply valve.
3. Turn off the power & disconnect the power cable.
You must turn off the circuit breaker connected to the product.
4. Pull out the unit from the sink and lay it on the īoor.
Be careful of the drain hose when pulling out the unit.
