Air conditioner
Installation manual
AR**TSEC*** / AR**TVFC*** / AR**TSHZ***/ AR**TVHZ***/
AR**TSFC*** / AR**TSHZ***
Thank you for purchasing this Samsung air conditioner.
Before operating this unit, please read this installation manual carefully and retain it for
future reference.
DB68-08814A-00
2
English
Contents
Safety Information 3
Safety Information 3
Installation 4
Preparation 4
Step 1.1 Viewing the typical installation 4
Step 1.2 Choosing the installation location 5
Step 1.3 Packing and Unpacking 8
Step 1.4 Preparing materials and tools 9
Indoor Unit Installation 11
Step 2.1 Attaching the mounting bracket to the wall 11
Step 2.2 Drilling the wall penetration 11
Step 2.3 Connecting the refrigerant pipes 12
Step 2.4 Connecting the power and communication cables 13
Step 2.5 Optional: Extending the power cable 15
Step 2.6 Connecting the drain hose 16
Step 2.7 Taping the pipes, cables, and drain hose 17
Outdoor Unit Installation 18
Step 3.1 Mounting the outdoor unit 18
Step 3.2 Connecting the cables and the pipes 19
Installation Inspection and Testing 21
Step 4.1 Performing a drain leak test 21
Step 4.2 Performing the gas leak tests 21
Step 4.3 Evacuating the system 22
Step 4.4 Adding refrigerant (if needed) 23
Step 4.5 Preparing the system for commissioning 23
Step 4.6 Commissioning the unit 23
Step 4.7 Performing final checks and trial operation 24
3
English
Safety Information
Safety Information
WARNING: Read This Manual
Read and follow all safety information and instructions
before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance
of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this
appliance. This manual is subject to change. For the
latest version,
visit www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted
information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
The user and installer guides
should be read carefully.
The user and installer guides
should be read carefully.
WARNING
The installation and testing of this appliance must be
performed by a qualified technician.
The instructions in this manual are not intended as a
substitute for proper training or adequate experience in
the safe installation of the appliance.
Always install the air conditioner in compliance with current
local, state, and federal safety standards.
General information
The air conditioner should be used only for the
applications for which it has been designed: the indoor
unit is not suitable to be installed in areas used for
laundry.
Installation of the product
Our units must be installed in compliance with the
spaces indicated in the installation manual to ensure
either accessibility from both sides or ability to perform
routine maintenance and repairs. The units’ components
must be accessible and that can be disassembled in
conditions of complete safety either for people or things.
For this reason, where it is not observed as indicated
into the Installation Manual, the cost necessary to reach
and repair the unit (in safety, as required by current
regulations in force) with slings, trucks, scaffolding or
any other means of elevation won’t be considered in-
warranty and will be charged to end user.
Power supply line, fuse, or circuit breaker
Be sure not to perform power cable modification,
extension wiring, and multiple wire connection.
It may cause electric shock or fire due to poor
connection, poor insulation, or current limit
override.
When extension wiring is required due to power
line damage, refer to "Step 2-5 Optional: Extending
the power cable" in the installation manual.
