Air to Water Heat Pump
Installation manual
EHS Mono Outdoor Unit AE***CXYD**
• Thank you for purchasing this Samsung product.
• Before operating this unit, please read this manual carefully and retain it for future reference.
2English
Contents
Safety Information 4
Handling the box 7
Unpacking the outdoor unit 7
Product line-up and accessories 7
Unit installation 8
Preparing the installation of the outdoor unit 8
Choosing the installation location 8
Safety Zone 9
Moving the outdoor unit 12
Mounting the outdoor unit 12
Outdoor unit drain work 13
Piping installation 14
About the piping work 14
Connecting the water pipes 14
Water Charging 14
Setting capacity and pre-pressure of the expansion vessel 15
Protection of the water circuit freezing 15
Outdoor water piping insulation 17
Minimum active water volume 17
Electrical installation 18
Precautions when connecting the electrical wiring 18
Electrical wiring diagram 18
Outdoor wiring 19
Power and communication cable configuration 19
To connect the power supply 20
To connect the communication cable 20
System configuration 21
Setting the outdoor options via K-button tactile switches 21
Testing operations 22
3
English
Charging refrigerant 23
Important information: regulation regarding the refrigerant used 23
Troubleshooting 24
Troubleshooting of error code 24
Technical data 25
Refrigerant circuit diagram 25
Piping & Wiring diagram 27
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from
other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for
details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH, visit:
https://www.samsung.com/uk/sustainability/environment/environment-data/
※ Please refer to the reference guide for details.
