Remote Control

for Evolution

Series Inverter/

Charger

Model: EVO-RC

Please read this

manual BEFORE

operating.

Firmware:

Rev 028

Owner's

Manual

APPENDIX A

EVO™ INVERTER/CHARGER MANUAL | Index

SECTION 1

Introduction and Layout ....................................................... 3

SECTION 2

Installation .......................................................................... 5

SECTION 3

Operation .......................................................................... 7

SECTION 4

Parameter Setup 19 ................................................................

SECTION 5

SD Card 73 ........................................................................

SECTION 6

Monitoring of Operation Using LED and Buzzer 79 ................

SECTION 7

Fault Messages and Troubleshooting Guide 80 .......................

SECTION 8

Specications ..................................................................... 85

SECTION 9

Warranty ........................................................................ 86

Disclaimer of Liability

UNLESS SPECIFICALLY AGREED TO IN WRITING, SAMLEX AMERICA INC.:

1. MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR

OTHER DOCUMENTATION.

2. ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR

INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USERS RISK.

Samlex America reserves the right to revise this document and to periodically make changes to the content hereof without obligation or

organization of such revisions or changes.

express written permission by Samlex America Inc.

2 | SAMLEX AMERICA INC.

SAMLEX AMERICA INC. | 3

APPENDIX A

SECTION 1 | Introduction and Layout

1.0 INTRODUCTION AND LAYOUT

EVO-RC Remote Control allows you to monitor and customize the operating parameters of Samlex Evolution™

Series Inverter/Charger Models EVO-2212, 2224, 3012 and 4024.

It has its own internal Real Time Clock (RTC) and Super Capacitor type of battery for clock operation.

1.1 LAYOUT AND DIMENSIONS

1. LCD Screen - 2 rows of 16

characters each

2. ON/OFF Key

3. Green LED “Status”

4. Red LED “Fault"

5. Navigation Key “Back”

6. Navigation Key “Up”

7. Navigation Key “Down”

8. Navigation Key “Enter”

9. SD Card Slot - FAT16/32

format; Up to 16GB

10. RJ-45 Jack (At the back-not

shown). See pinout below:

Fig 1.1 Optional Remote Control EVO-RC - Layout & Dimensions

Pin # Signal

1 12V

2 12V

3 ON/OFF

4 D+

5 D-

6 NC

7 GND

8 GND

12345678

(View - Looking into the Jack)

Fault

132 mm

114 mm102 mm

144 mm

Produktspezifikationen

Marke:	Samlex
Kategorie:	Fernbedienung
Modell:	EVO-RC
Breite:	144 mm
Tiefe:	114 mm
Gewicht:	200 g
Produktfarbe:	Schwarz
Höhe:	35.5 mm
Eingebautes Display:	Ja
Betriebstemperatur:	-20 - 60 °C
Display:	LCD
Kompatible Produkte:	EVO-2212, EVO-3012, EVO-2224, EVO-4024\nEVO-2212E, EVO-3012E, EVO-2224E, EVO-4024E
Markenkompatibilität:	Samlex
Maximale Reichweite:	10 m
Beleuchtete Tasten:	Ja
Eingangssignal:	Drucktasten
