Seite 1/28
A Quantum Rehab Provider or a qualiļ¬ed technician
must perform the initial setup of this power chair and
must perform all of the procedures in this manual.
The symbols below are used throughout this ownerās manual
and on the power chair to identify warnings and important
information. It is very important for you to read them and
understand them completely.
Indicates a potentially hazardous condition/situation.
Failure to follow designated procedures can cause either
personal injury, component damage, or malfunction. On
the product, this icon is represented as a black symbol
on a yellow triangle with a black border.
These actions should be performed as speciļ¬ed. Failure
to perform mandatory actions can cause personal injury
and/or equipment damage. On the product, this icon is
represented as a white symbol on a blue dot with a white
border.
These actions are prohibited. These actions should
not be performed at any time or in any circumstances.
Performing a prohibited action can cause personal
injury and/or equipment damage. On the product, this
icon is represented as a black symbol with a red circle
and red slash.
Copyright 2020Ā©
INFMANU4800/Rev F/June 2020
SAFETY GUIDELINES
MANDATORY!
PROHIBITED!
WARNING!
WARNING!
WARNING!
Intended Use
A wheelchair component is a device intended for medical
purposes that is generally sold as an integral part of
a wheelchair, but may also be sold separately as a
replacement part.
Regarding Devices for Prescription Use
CAUTION! Federal law restricts this device to sale by or
on the order of a physician or other certiļ¬ed personnel
licensed by the law of the State (US only) or region in
which this personnel practices to use or order the use
of the device.
NOTE: These instructions are compiled from the latest
speciļ¬cations and product information available at
the time of publication. We reserve the right to make
changes as they become necessary. Any changes to
our products may cause slight variations between the
illustrations and explanations in this manual and the
product you have purchased. The latest/current version
of this manual is available on our website.
NOTE: This product is compliant with WEEE, RoHS, and
REACH directives and requirements.
NOTE: This product meets IPX4 classiļ¬cation
(IEC 60529).
NOTE: This product and its components are not made
with natural rubber latex. Consult with the manufacturer
regarding any after-market accessories.
3BASIC OPERATION INSTRUCTIONS
Table of Contents
Product Safety Symbols .........................................4
TRU-BalanceĀ® 3 Power Positioning System .........4
Precautionary Guidelines .......................................4
Operating the TRU-BalanceĀ® 3 Power Positioning
System ...................................................................... 6
Range of Motion ........................................................ 6
iLevelĀ® Feature ......................................................... 7
Flip-forward Back ....................................................... 9
Armrest Options ......................................................10
Optional Toggle Operation .......................................15
Transfers .................................................................. 16
Controller Position ................................................16
Seatback .................................................................18
TRU-Comfort .......................................................... 18
Installation and Use .................................................18
Cleaning ..................................................................19
Lateral Adjustment ...................................................20
Headrest Adjustment ............................................... 22
Storage ...................................................................22
Care and Maintenance ..........................................22
Warranty .................................................................23
Language Usage
This ownerās manual is intended for distribution in all English-
speaking countries where our Power Chairs are sold. We
have chosen to compose this manual using language and
spellings common to the USA. Since we recognize that not all
English-speaking countries use the same words or spellings,
please refer to the following chart for some common word
variations that may be encountered throughout this manual.
USA Variation
asphalt tarmac
authorized authorised
backward(s) rearward(s)
caster castor
center centre
color colour
cord lead
counterclockwise anticlockwise
curb kerb
elevator lift
labor labour
meter metre
path bridleway; footpath
pocketbook handbag
provider dealer; agent
sidewalk pavement
tire tyre
trunk boot
turn signal turn indicator
wrench spanner
yard grounds
