QUEST series
Active PA Cabinets
Order ref: 178.510UK, 178.512UK, 178. 515UK
User Manual
VERSION 2.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
QUEST Series Active Cabinets User Manual
Introduction
Thank you for choosing QUEST series active PA cabinet. This speaker unit is designed to a
provide a flexible solution for sound amplification in public places and live sound venues with
the added convenience of portability.
Package Contents
Please check the contents to ensure that the product has been received in good condition.
If you find any accessory is missing or the product has arrived with any problems, please
contact your retailer at once.
• QUEST ries active cabinet se
• I.R. remote control handset
• IEC power lead
This product contains no user-serviceable parts so make no attempt to try to fix or modify this
item yourself as this will invalidate the warranty. We recommend you keep the original
packaging and proof of purchase for any possible replacement or returned demand.
Warning
To prevent the risk of fire or electric shock, do not expose this appliance to rain or moisture.
To prevent electric shock do not remove the cover. No user serviceable parts inside. Refer
servicing to qualified service personnel.
Safety
Prior to connecting mains, check the supply voltage is correct and the IEC mains lead is OK.
Avoid ingress of water or particles into the enclosure.
If the internal IEC fuse blows, refer the unit to qualified service personnel.
Placement
Keep the unit out of direct sunlight and away from heat sources.
Place the unit in an upright position during use and storage.
Keep the unit away from moisture or dusty environments.
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls.
To avoid damage, do not use solvents to clean this equipment.
QUEST Series Active Cabinets User Manual
Control panel
NOTE: QUEST-10A connections and controls are arranged differently.
Connectio ns
If a microphone is to be used directly with the QUEST acti cabinet, this may be connected to ve
either the 6.3mm jack or XLR input (5, 6) on the rear panel. (6.3mm jack only for QUEST- 10A)
For line level input, this may be connected by RCA (14) XLR (18) a or
QUEST-12A and QUEST-15A also have this input via 3.5mm mini jack (3).
Each QUEST active cabinet is capable of sharing its output with a passive cabinet for a 2-
speaker system. Ensure that the passive speaker is can handle the stated output 8Ω and (W).
Connect the passive cabinet with a Speakon lead from the rear panel speaker output (7).
If additional active cabinets are to be used, the signal from the QUEST active cabinet n be ca
linked from the Line Out XLR, which carries a mix of all inputs (Mic, Line In Media player & ).
With power switched off (8), use the IEC lead provided to connect to the 230Vac supply (20).
1
I.R. remote control receiver
2
Media player controls
3
3.5mm AUX input
4
Microphone input volume control
5
Microphone input 6.3mm jack
6
Microphone input XLR
7
Optional 8 speaker output Ω
8
Power on/off switch
9
Media player display
10
SD card slot
11
USB port
12
Line/Aux input volume control
13
High EQ control
14
Line input 2 x RCA
15
L EQ control ow
16
Power on and Clip LED indicators
17
Media player volume control
18
Line input XLR
19
Line output XLR (mix of all inputs)
20
IEC power inlet & fuse holder
