Seite 1/4
www.avsl.com 160.4 UK Manual 91
MoonCloud- 400
Compact LED Fog Machine with RGB Moonflower Effect
Order ref: 160.4 UK 91
User Manual
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty!
A compact and portable unit comprising a standard fog machine and 2 eye-popping light effects. The
400W fogger generates around 2500cu.ft/min, ample fog to easily fill smaller rooms and venues. The 9
bright RGB LEDs provide a traditional PAR wash effect and the additional central RGB moo ower then nfl
adds colourful patterns which both combine with the fog to provide a complete room filling solution.
Control using either the in-built sound to light mode or with the included remotes, this all- -one solution in
is ideal for mobile DJs, house parties, small events and more.
• Compact, portable unit comprising standard fog machine and 2 eye-popping light effects.
• 400W fog vaporizer with around 2500cu.ft/min output.
• Nine 1W LEDs and a 2W moonflower LED add a bright colourful light show to the smoke effect.
• Control using sound to light or with the included wired and RF remotes.
• Supplied with UK and EU IEC leads and mounting bracket.
www.avsl.com 160.4 UK Manual 91
I the box:n
Please check the contents to ensure that the product has been received in good condition.
• MoonClo - Fog Machine ud 400
• Wired control unit
• RF wireless remote
• UK Mains Leads /EU
• User guide
If you find any accessory is missing or the machine has arrived with damage, please contact your local
dealer at once. Do not try to fix this item yourself or you will invalidate e warranty. Please keep the th
original packaging and invoice for any possible replacement o return demands. r
Warnings:
1. To prevent risk of fire or electric shock, do not expose electrical parts to water or moisture.
2. If liquids are spilled on areas other than inside the fluid tanks, disconnect the mains, allow the
unit to dry out and have it checked by qualified personnel before use.
3. Avoid any impact, dropping or extreme pressure to the housing .
4. No user serviceable parts inside - do not open the cas e.
5. Allow the to acclimatise to room temperature before operating. unit
6. The MoonCloud- has a bui -in fluid container so should be operated in an upright position 400 lt .
7. Ensure that the is positioned on a stable, non-slip surface. unit
Safety d Cleaning: an
1. Check for correct mains voltage and condition of IEC lead before connecting to mains.
2. This unit must be earthed.
3. This unit uses a heating elemen be aware that parts of the housing may be hot during use! t –
4. Use a soft dry or slightly damp cloth to clean the casing.
5. Do not use strong solvents for cleaning the housing.
6. Clean the mechanism periodically by operating with distilled water. fog
7. It is also recommended to use fog machine cleaning fluid (160.670UK) periodically.
Recommended Fluids:
For the MoonCloud- machine, we strongly recommend the following fluids which have been 400 fog
specifically formulated to perform best with heater-based chines: fog ma
QTX ref code
Description
Size
160. 3UK 64
Standard fog fluid yellow
1 Litre
160.582UK
Standard fog fluid yel low
5 Litre
Setting Up:
1. Unpack the MoonCloud- 400 unit.
2. Unscrew the top cap of the tank and remove to fill with ui fog fl d.
3. Replace the bottle and screw the cap securely, making sure that the pipe is fed down to the
bottom of the bottle to ensure a consistent flow of fluid.
4. Connect the wired control unit to the sock marked Remote Control the re panel. et “ ” on ar
5. Connect the IEC mains plug and power the unit on.
6. The it will begin the warming up proce which normally takes around 3-5 nutes. un ss mi
www.avsl.com 160.4 UK Manual 91
R Panel: ear
1. Fluid level indicator
2. IEC power input
3. Earth screw (do not remove)
4. Power switch
5. Remote control input
Operation:
Wired Control Unit:
1. The wired control unit supplied with the MoonCloud-400 must be connected at all times during
use.
2. Once the unit is warm enough to produce , the red LED the bottom of the unit will light up. fog at
3. For simple fog on demand press and hold the red button on the panel release to stop the fog ,
supply.
Please note: The unit s default LED settin is sound to lig which will be enabled unless the R’g ht F
remote is used to control the specific LED functio . unit ns
RF Remote Control:
The small RF remote supplied can be used control both fog supply and the LED functions of the unit. to
Please no :te the receiver for the RF remote is located within the wired control unit so this must be
connected for it to function correctly. See below for details of functions using the RF remote:
1: Contin us fog start/stop uo
2: Auto LED Mode slow/fast
3: LED sound to light mode (default)
4: LED individual modes select
