WARRANTY
DR Distribution guarantees that any part*, which we find to be defective in
materials or workmanship will be repaired or replaced free of charge for the
parts and any service labour for a period of 24 months for residential use and 12
months for commercial use from the date of purchase, as the original purchaser
of a Pureheat product, provided that all service be pre authorised by DR
Distribution.
• *The heater warranty does not cover service calls related to over- temperature
safety devices activating and shutting the heater down.
• *This Warranty does not cover failure due to accidental damage, misuse or
negligence, nor does it cover any consequential damages.
Important: If you are experiencing difficulties with the operation
or believe that your Pureheat heater is faulty in any way,
contact D R Distribution on
02 9618 3842
For the purpose of this warranty, it is a condition that the “wired in” models must
be installed by a registered electrical contractor and must be wired in
accordance with our wiring instructions. Similarly, this warranty becomes void if
the heater is serviced, repaired or altered by anyone other than D.R. Distribution
or its authorised Service Agents or if parts, other than approved parts, have been
used.
Record the date of purchase below and retain this card, together with your
purchase invoice for your own future reference.
The benefits conferred by this warranty are in addition to all other rights and
remedies which the consumer has under the Trade Practices Act and other
legislation.
OE – Series 2.4kW, 3.5Kw, 4.5kw
INSTALLATION INSTRUCTIONS
IMPORTANT:
All Odyssey-Eco heaters are designed for wall mounting only and must not be used
for any portable application.
• Wiring must be carried out by an authorised electrician in accordance with all
relevant Australian and local wiring standards.
• Before obtaining access to terminals, all supply circuits must be disconnected.
OE24 MODELS – c/w Flex & Plug:
1. Refer Odyssey Template & Installation Instructions enclosed separately with the heater.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
3. The heater must not be located in front of a socket-outlet
OE35 MODELS and OE45 – Hardwired:
1. Remove both plastic side vents by unscrewing the two recessed screws on each side.
2. Remove front panel by undoing the 2 screws on either side of the heater.
3. Bring all electrical supply wiring through the cable entry at the top left hand side of
the rear face.
4. The heater should be mounted a minimum of 50mm (2”) above the top of the floor or
î‹Šoor covering.
Notes:
• The heater must not be recessed and should have a clearance on either side
and above the heater of at least 200mm to allow for unobstructed airflow.
• When selecting a position for the heater care must be taken not to position
the heater close to curtains and other combustible materials.
• The heater must not be located immediately below a socket- outlet.
5. For the quietest operation, firmly screw the unit onto the wall at all four mounting pad
points located in the corners at the back of the heater.
6. Care must be taken when mounting heater on the wall that no twisting of the unit
occurs. It may be necessary to pack the rear panel with washers to overcome this.
7. The heater must be connected to a fixed, single phase 240 volts a.c. supply, through
an isolating switch and in accordance with the relevant local regulations.
Notes:
• All connections must be tight.
• Do not use this heater with an external programmer, timer or any other
device that switches the heater on automatically, since a fire risk exists if the
heater is covered or positioned incorrectly.
• The heater must not be located in front of a socket-outlet
8. Replace front cover and tighten screws.
9. Fit the two side panels supplied loose with the heater. (Do not over tighten and distort
front panel).
10. Test heater, ensuring all facets of the unit’s operation are fully functional.
NAME:
ADDRESS:
PURCHASED FROM:
DATE OF PURCHASE:
MODEL NO:
SERIAL
NO:
INSTALLED BY: DATE:
PUREHEAT
D R Distribution Pty Ltd
Unit 9 No 3 Lancaster St Ingleburn NSW 2565
Ph 02 9618 3842
www.drdistribution.com.au
OPERATING INSTRUCTIONS
The PUREHEAT “Odyssey” is a fan assisted heater.
FAN- ASSISTED HEATING
The heater is fitted with a thermostat which controls the fan. The internal thermostat
senses the temperature of the air in the room and automatically switches the internal
heating elements and fan from high to off depending on the room temperature.
The heater may also incorporate a 24-hour programmable timer (OE24TW & OE35TW
Models), which enables the Fan Heater to be preset to operate at given time/s.
Turn the heater on at the main switch located in the middle of the top panel (fig. 1).
Once on, the switch is illuminated. Note: Ensure timer is placed in the “ON” position. (See
Timer section below – fig. 3).
(fig. 1 – Main Control Switch) (fig. 2 – Heat Control
Knob)
Adjustment of the thermostat:
To achieve the lowest possible running costs the following method of adjusting the
thermostat (fig. 2) should be followed. Turn the Heat Control Knob to the position marked
“Hi”.
When the room reaches the desired temperature rotate the Heat Control Knob anti-
clockwise until you hear the thermostat click. Leaving the thermostat at this setting will
ensure that the heater will continue to maintain this temperature as a minimum setting,
assuming the heater has been sized correctly for the room, .i.e. approximately 1 kW of
electric heating for every 10 square metres of floor area, assuming standard ceiling height
& insulation. The heater will heat with full element, then cut off depending upon the heat
requirements of the room at this particular thermostat setting.
Operating the 24hr timer.
To set the correct time on the Timer (fig. 3), turn the outer ring of tags until the clock face
reads the correct time. Note: this is a 24 hour clock so ensure the small white arrow head
on the outer clock face is pointing to the correct hour of the 24 hour time period around
the outer perimeter of the timer face.
(fig. 3 – Timer)
Push the sliding switch this now activates – on the face of the timer to the central position
the timer ready to accept your timed period/s. Note: with this switch pushed to the OFF
position “O”, the heater will not operate but the timer will continue to keep the correct
time.
With the switch pushed to the ON position “I”, the heater will run under normal
thermostatically controlled conditions but with no timing facility.
To set your required “Turn on/Turn off” time periods, push the total quantity of tabs
outwards from the centre of the timer face for the period you want the heater to operate.
Each tab is 15 minutes.
Over the 24-hour period the heater will operate for the time periods with the tabs pushed
outwards and not operate when the tabs are pushed inwards.
IMPORTANT NOTES
• The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Young children should be supervised to ensure that they do not interfere with the
appliance.
• The motor in your heater may -be slightly noisy during the running in period. Any
undue noise usually disappears within the first ten to fourteen days of operation.
Should motor noise persist, consult the electrician who installed your heater.
• Warning in order to avoid overheating do not cover the heater
• Never place articles such as clothing, curtains or furniture etc. directly in front of the
heater, over the side corners of the heater, or stand immediately in front of the heater
when it is operating
• In accordance with current Approval Regulations, this heater is fitted with an
automatic, r- -resettable ove temperature cut out, which will shut the heater off if the
air î‹Šow is impeded.
If this occurs, ensure the grills are clear of any obstruction, turn the heater off and wait
5 minutes to allow the cut- out to reset.
After waiting 5 minutes, turn the heater on and the thermostat knob to the “High”
position.
If the heater still does not operate or blows cold air, the secondary Thermal-fuse has
activated and you will require a Service call to replace this device. Note: Such service
calls are not covered by .warranty
• The heater is not suitable for installation in a bathroom
CLEANING
Note: Before any cleaning is carried out on the heater be sure to turn the power off at the
isolating switch and turn all heater top console switches to the off position.
• External surfaces: The heater can be wiped over with a cloth or sponge dampened
with warm water or any spray on, non-abrasive, liquid cleaner.
Warning: Do not pour liquids directly onto the heater surfaces.
• Air outlet: The air outlet surfaces can be wiped clean using a cloth or sponge
dampened with warm water or any spray on, non- abrasive, liquid cleaner.
Important: The mesh air outlet grill should be vacuumed regularly using a brush type
nozzle to remove all dust and lint from the grill / air outlet area.
Arrow head
Sliding Switch
On
Timer
Off
Tabs
