Seite 1/13

Please check PTZOPTICS.com for the most up to date version of this document Rev 1.4 7 9 /1

PTZOptics USB (GEN- 12X 2)

User Manual

Model Nos: PT12X- -USB GY-G2 & PT12X- - - USB WH G2

V1.4

(English)

Page of i 58

Rev 1.4 7 9 /1

Preface

Thank you for using the USB 3.0 HD Video Conferencing Camera. This manual introduces the function, installation and

operation of the HD camera. Prior to installation and usage, please read the manual thoroughly.

Note: Minimum USB 3.0 System Requirements: i3 Quad-Core

( : i5 Quad Core or better)Recommended

Precautions

This product can only be used in the speciﬁed conditions in order to avoid any damage to the camera:

• Don’t subject the camera to rain or moisture.

• Don’t remove the cover. Removal of the cover may result in an electric shock in addition to voiding the warranty.

In case of abnormal operation, contact the manufacturer.

• Never opera outside of the speciﬁed operating temperature range, humidity, or with any other power supply te

than the one originally provided with the camera.

• Please use a soft dry cloth to clean the camera. If the camera is very dirty, clean it with diluted neutral detergent;

do not use any type of solvents, which may damage the surface.

Note

This is an FCC Class A Digital device. As such, unintentional electromagnetic radiation may affect the image quality of TV in a

home environment.

Page of ii 58

Rev 1.4 7 9 /1

Table of Contents

1 Supplied Accessories 1 ···································································································

2 Notes ······················································································································ 1

3 Quick Start 2 ···············································································································

4 Features ··················································································································· 4

5 Product Speciﬁcations ·································································································· 5

6 Main Unit················································································································· 7

7 IR Remote Controller··································································································· 8

8 10 Using the IR Remote Controller ·····················································································

9 13 Dimensional Drawings ································································································

10 14 RS-232 Interface ·······································································································

11 VISCA Commands ····································································································· 16

12 VISCA over IP Commands 25 ···························································································

13 Menu Setting············································································································ 32

14 Network Connection ··································································································· 36

15 53 Photobooth Functionality ·····························································································

16 Maintenance and Troubleshooting ··················································································· 55
