Seite 1/4
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Orion Mini Camera Geared Head (P ORGH MN)- -
A s s e m b l y M a n u a l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmiîž©ed by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permiîž©ed by the applicable copyright
statutes or in wring by the Publisher.
Tightening Knob Bag Packing
Proaim Orion Mini Geared Head
2
ï‚· Loosen the ratchet knob on the top plate of
the Geared Head and press the push buîž©on
on the other side.
ï‚· Secure the thread from the boîž©om with the
ghtening knob.
Orion Mini Geared Head Setup
ï‚· Slide out the top plate.
ï‚· Aîž©ach the plate to the camera base
(Not Included) -and ghten its bolt with a
screwdriver . Then, slide the (Not Included)-
plate on the top of the Geared Head.
NOTE: Orion Mini Gear Head works with most
of the DSLR Video Cameras with payload up to
15kg/33lb.
ï‚· Tighten the ratchet knob on the plate to
secure the camera setup.
ï‚· Insert the thread of the Orion Mini Geared
Head into the 100mm bowl tripod stand
(Not Included).-
3
ï‚· Orion Mini Geared Head Setup is ready to
use.
ï‚· There's a Backlash Control Knob present on
the geared head. Tightening the knob will
make the panning crank handles ght, and
the handles will move smoothly when the
knob is loosened.
YOUR PROAIM ORION MINI CAMERA GEARED HEAD
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
The Geared Head has sturdy cranks for NOTE:
Panning & Tilng. The lng crank oers
one axis movement and allows 45° lng on -
each side. The panning crank oers 360°
panning for accurate panoramic shots.
Sturdy Tilng
Crank
Panning
Tilng Crank
Produktspezifikationen
| Marke: | Proaim |
| Kategorie: | Stativ |
| Modell: | P-ORGH-MN |
