Part 1
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend n automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告
警告
警告
警告警告
為避免電磁干擾，本產品不應安裝或使用於住宅環境。
SAFETY INSTRUCTIONS
This equipment is not suitable for use in locations where children are likely to be present.
CONSIGNES DE SÉ CURITÉ
Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants.
LM 6207-6307-6407-6507- –6607
7” USB LCD Monitor
User ’s Manual
Rev. : A0
Part 2
Power Setup Notice
This device is particularly designed for use with a Posiex system. In
such application, it can utilize power support from the Posiex system.
BRIEF INTRODUCTION
THE PRODUCT
The LM-6x product series are typical of small-sized 07 7” USB LCD monitor
LCD peripheral. The -6x07 can be irreplaceable for a conventional LM LM
(not required for AP modication). The - is a stand alone pole LM 6207
customer display designed for discrete POS applications, The - is a LM 6307
back cover mount customer display option designed for series POS KS
terminals he - is a pole mount type for Gen.5 base stand . T LM 6407 .
The LM- /6607 is a back cover mount monitor each for HS and XT series. 6507
FEATURES
Light weight and high luminance 7 LCD monitor for industrial ”
a commercial use nd
Supports display resolution up to 0 x 480 pixels 80
Tilt and swivel adjustable construction
Spill proof and easy maintenance structure allowing easy cleaning
Stand alone Pole Display ( - ), back cover mount ( - LM 6207 LM
6307) pole mount ( - for POS application, back cover , LM 6407)
mount (LM- and (LM-6607) each for HS and XT series 6507)
Powered by USB interface
INSTALLATION GUIDES
PACKAGE CONTENTS
Following are items you may nd when you carefully unpack the
carton that delivers 6207/6307/6407/6507/6607 series customer LM
display. ere is any discrepancy or problem, contact your dealer If th
immediately.
Be sure to save the packing materials in case the printer needs to
be shipped at some point in the future.
1) The with base or x bracket 7” LCD monitor ed
2 USB cable A-type signal cable )
3) A Posiex CD included with USB driver
Part 3
PHYSICAL INSTALLATION
LM-6207/6307/6407/6507/6607 model:
Find a at surface to site the base of the 6207/6 /6407/6507/6607 LM 307
display For application operation, nd in the bottom of the base the .
connectors as in the drawing below:
USB Interface Connection
To enable connection, install USB interface driver rstly from Posiex CD
with USB driver. Click the le: DisplayLink_7.2M0 for further installation
then restart. For driver upgrade, please go to http://www.posiex.com.tw for
detailed information of the USB driver installation if required. For immediate
PnP function, connect the attached USB 2.0 type A signal cable the USB to
port in the host system.
LM-6207 Front View:
The - is a stand alone pole customer display as illustrated below. LM 6207
LM-6307 Installation:
The - can be attached to the POS upper rear base. Fasten the 4 screws LM 6307
on the upper rear base of KS series machine as illustrated in No1. picture .
Then also fasten the 2 screws on the arrowed holes of LM-6307 as illustrated
in No.2 picture. Finally attach this base wall mount upgrade 2
nd customer
display to attached to the upper rear base as illustrated on No.3.
(1) (2)
USB interface
