Seite 1/3

Technical Support

If you need technical support with your Planet Audio product or have

quesons about its use, please contact us:

805.751.4853

www.PlanetAudioUSA.com

*Due to ongoing product development, specicaons are subject to change without noce.

2015 © 0515_2

Congratulaons on your purchase of the Planet Audio Anarchy Subwoofer.

Planet Audio takes great pride in producing products that sound and look great and stand up

to the daily rigors applied by audio enthusiasts around the world.

AC8D 8” Subwoofer

Dual 4 Ω Voice Coils

1200 W Peak Power Handling

Customizable Trim Ring

Operates in a compact enclosure

Enclosure

The AC8D is designed to work in a sealed or ported enclosure. Since the

woofer has pole vent, it needs a minimum clearance from the rear wall -

of the enclosure of 0.75” (19 mm).

Below you will nd the dimensions to make the enclosure to suit the

subwoofer, it has been designed for maximum output while retaining

great sound quality.

The dimensions have already accounted for the volume displacement of

the subwoofer, and using 3/4” (19mm) MDF.

All dimensions are external.

Sealed

SealedSealed Dimen

Dimen

Dimen Dimensions:

sions:

sions:sions:

Length (L) : 18 1/2” (470 mm)-

Width (W) : 5 1/2” (133 mm)-

Height (H) : 11 1/2” (292 mm)-

Cutout Diameter: 7 1/4” (185 mm)-

Dimensions

Porte

PortePorted Dimensi

d Dimensi

d Dimensid Dimensions:

ons:

ons:ons:

Length (L) : 14” (356 mm)

Width (W) : 12” (305 mm)

Height (H) : 14” (356mm)

Cutout Diameter: 7 1/4” (185 mm)-

Port: (Dia. X Length): 3” x 11”

Port Tuning: 40 Hz

8 Ω 2 Ω

Parallel Series

Wiring Opons

Series

4 Ω

Parallel

1 Ω

Mulple Subwoofers

Parameters

Impedance Dual 4 Ω

Resonant Frequency 39 Hz

Qts 0.633

Qms 2.399

Qes 0.859

Vas 1.035  (29.3 liters)³

Xmax 10 mm

Sensivity (1 W/ 1 m) 85 dB

Peak Power Handling 1200 W

- Mounng Depth 3 15/16” (100 mm)

- Cutout Diameter 7 1/4” (185 mm)

Produktspezifikationen

Marke:	Planet Audio
Kategorie:	Autofreisprechanlage
Modell:	AC8D
Form:	Rund
Breite:	- mm
Tiefe:	101.6 mm
Produkttyp:	Subwoofer-Treiber
Impedanz:	4 Ohm
Höhe:	- mm
Anzahl des Antriebs:	1
Durchmesser:	184.15 mm
Subwoofer-Treiberdurchmesser (imperial):	8 "
Empfindlichkeit:	85 dB
Subwoofer-Typ:	Aktiver Subwoofer
Subwoofer Effektivwert Energie:	600 W
Subwoofer Frequenzbereich:	- Hz
Subwoofer Empfindlichkeit:	85 dB
Bemessungsleistung:	600 W
Tieftönerdurchmesser:	203.2 mm
Gesamtleistung des Subwoofers:	1200 W
Subwoofer Widerstand:	4 Ohm
Stimmenmagnetspuele Typ:	Dual
Spitzenstrom:	1200 W
Montagetiefe:	102 mm
Resonanz Frequenz (Fs):	39 Hz
