Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
About the Delta 44 Digital Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Product Features & Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Break-Out Box Front Panel: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Break-Out Box Back Panel: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PCI Host Adapter Card: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Quick Guide to Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Delta Driver & Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Windows 98 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Windows 95 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Windows NT 4.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Windows NT 3.51 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Macintosh Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Verifying Windows Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Verifying Delta Control Panel Software Installation . . . . . . . . . . . . . . . . .10
Delta System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Delta’s Analog Input/Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
The Digital Monitor Mixer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
The Patchbay / Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the Delta 44 with your Software Application . . . . . . . . . . . . . . . . . .12
Delta 44 Control Panel Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Monitor Mixer Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Patchbay/Router Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
S/PDIF Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
About Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Save, Delete, Load Buttons; H/W Installed . . . . . . . . . . . . . . . . . . . .22
Delta 44 Recording Tutorials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Typical Setup #1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Typical Setup #2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Troubleshooting Tips for Frequently Asked Questions . . . . . . . . . . . .35
Appendix A - Technical Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Appendix B -If You Use An External Mixer... . . . . . . . . . . . . . . . . . . . . . .37
Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Delta 44 Manual
version: D44-110801
Introduction
Congratulations on your purchase of the Delta 44 Digital Recording Interface
designed and built by M Audio. Even if you are experienced in digital recording,
please take the time to read this manual. It will give you valuable information on
installing your new card and the supporting software, plus help you to fully
understand the function and use of the Delta 44. Once you’re up and running, you
will quickly discover the power and brilliance, both in sound and design, of your
Delta 44 Digital Recording Interface.
What’s in the Box?
Your Delta 44 box contains:
• This instruction manual.
• The Delta 44 PCI host adapter card.
• The Delta 44 break-out box.
• 15-pin D-sub to 15-pin D-sub cable.
• CD containing drivers & Delta Control Panel software for Windows 98/95/NT
and Macintosh OS 8.5.1 or higher.
• M Audio Warranty Registration card.
About the Delta 44 Digital Recording
Interface
The Delta 44 is a 4-input, 4-output digital recording interface. Its four analog inputs
and outputs give you the highest quality digital audio available — all up to 24-bit
data width and any sampling rate from 8kHz to 96kHz. Connect a line-level signal
from your instrument, mixer, or pre-amp to the Delta 44’s TRS jacks on the break-
out box. Match the operating levels of your input and output signals using the +4,
‘Consumer,’ or -10 signal level software switches. Control all routing and hardware
settings with the Delta’s comprehensive control panel software.
Within the Delta 44’s PCI chip is a hardware digital mixer. Controlled by the
included Delta Control Panel software, it may handle all of your routing and
monitoring needs, giving you extra control of all left, right, and stereo levels, in
addition to control of pans, solos, and mutes.
2
3
Product Features & Specifications
• 4x4 24-bit/96khz full-duplex recording interface.
• PCI host card with external break-out box.
• 4x4 analog I/O accepts balanced or unbalanced connections on 1/4” TRS jacks.
• Analog I/O configurable for +4dBu, Consumer (approximately -4dBV), and
-10dBV signal levels.
• Analog dynamic range exceeding 103dB.
• All data paths support up to 24bit/96kHz performance, no upgrades necessary.
• Comprehensive digital mixing, routing, and monitoring capabilities controlled
by included Delta Control Panel software.
• Windows 95/98 multi-card drivers with ASIO1 and ASIO2 multi-card, GSIF and
EASI drivers included; Windows NT multi-card and Mac OS drivers with ASIO
1&2 also included.
Minimum System Requirements
• Windows 95 or Windows 98.
• Pentium II 266MHz for 96kHz operation. Pentium 200 MMX for 48kHz or less.
• 128 MB of PC100 RAM for 96kHz operation. 64MB SDRAM for 48kHz or less.
• Mac G3 or G3 accelerator with 64 MB of RAM, 128 recommended. Some faster
Power PCs will perform adequately.
• UDMA EIDE or SCSI HDD recommended.
