Seite 1/30

Get product support at

www.philips.com/support SQM9232/05

User manual

Benutzerhandbuch

Kullanıcı el kitabı

Manuale utente

Manual del usuario

Gebruiksaanwijzing

Bruksanvisning

Brukerveiledning

Brugervejledning

Εγχειρίδιο χρήσης

Käyttöopas

Manual do utilizador

Instrukcja obsługi

Návod k obsluze

Návod na použitie

Felhasználói útmutató

Manual de utilizare

1 Important safety instructions

Caution

• R h n ru n for you n. you read t ese i st ctio s be e begi If a e un urs e of ny a

pa ocessr f h rt o t e p , co tact a pn rof n ntr r r n r essio al co acto o i stalle

for nce. I r r n n n r u n njur r e, assista mp ope i stallatio ca es lt i i y o damag

• The wall or mounting surface must be capable of supporting

the combined weight of the mount and the display, if not the

structure must be reinforced.

• Locate pipes, wires, or any other hazards in the wall where you

wish to install the mount before drilling.

• Three people are recommended for installation. Do not attempt

to lift a heavy display without assistance.

• This wall mount is intended for use only with the maximum

weight of 35 kg (77 lbs). Use with heavier than the maximum

weights indicated may result in instability causing possible injury

2 Full motion wall mount (for LCD, Plasma, and

LED displays)

What’s in the box

Full motion mount (×1) User manual (×1)

Adapter (×4) Hardware kit (×l)

Hardware kit

A Drywall screws (×3)

F M5×20 (×4)

B Concrete anchor (×3)

G M6x20 (×4)

C Washers (×7)

H M8x30 (×4)

Wrench (×1)

D M6×10 (×8)

I Spacer (×4)

E J M6 lock nut (×8)

Spirit bubble (×1)

Tools required

Preparation

• Phillips head screw driver

• Electric or portable drill

•

• 8 mm (5/16”) Masonry bit for concrete installation

•

Level

3 Installation

Mount to the drywall

Caution

For safety reasons, this mount must be secured to a wood stud of

supporting the combined weight of the mount and display Do not

mount to drywall alone.

install your mount. Mark both edges of each stud to help identify

the exact center.

2Place the mount against the wall over the marked stud. Make

sure it is level and right side up.

Prepare the mount for installation by

disassembling the display plate from

the mount. Do this by removing the

safety screws as shown .Place the

screws in a safe location.

3 Mark three Locations vertically at the center of the stud for

securing the mount to the wall (see Fig. 1) and set it aside.

4 Drill a 50 mm pilot hole at each marked location.

5 Place the mount back against the wall and attach it using the

drywall screws (A) and three of the washers (C) provided (see

Fig. 2). Do not over-tighten these screws . Ensure that the mount

remains level after all screws are secured.

Mount to the concrete wall

Caution

For safety reasons, the concrete wall must be capable of supporting

the combing weight of the mount and the display. The manufacturer

1Place the mount against the wall in the desired location and

make sure it is level and right side up.

2Mark three lotions vertically at the center of the stud for securing

the mount to the wall (see Fig.1) and set it aside.

3Drill 50mm pilot hole at each marked location.

Remove any excess dust from the holes.

with the concrete surface (see Fig. 2). A hammer can be used to

lightly tap the anchors into place if necessary.

Insert a concrete anchor (B) into each hole so that it is flush

Note

If the concrete wall is covered by a layer of plaster or dry wall, the

concrete anchor must pass completely through the layer to rest

5Place the mount back against the wall and attach it using the

drywall screws (A) and three of the washers (C) provided (see

Fig. 3). Do not over-tighten these screws . Ensure that the mount

remains level after both screws are secured.

Attaching the display plate to the display

Caution

Use extra care during this part of the installation. If possible, avoid

facing down your display as it may damage the viewing surface.

Note

This mount comes with a selection of different screws to

accommodate a wide variety of display models. Not all of the

screw size in the kit provided, consult the manufacturer of your

display for more information.

1Examine the mounting holes on the back of your display:

• If th ne mounti g holes are spaced 75 mm 75 mm o× r 100 mm ×

100 mm apart, skip t is sectio d ph n n a roceed w h .it step 3

• If the mounting holes are spaced 100 mm × 200 mm or

200 mm × 200 mm or 300 mm × 300 mm or 400 mm × 400

mm apart you will need to use the adapters included with

your mount Attach t mo rhese to the unt acco din g to the

ill atioustr n (see Fig. . Use the M6 × 10 screws ( , M6 lock 4) D)

nuts (E) and wrench (J) from the hardware kit.
