Seite 1/12
12014-09-24 #:203-9450-2 (2017-04-04)
42" - 80"
(107 - 203 cm)
150 lb
(68 kg)
MAX
ESF655P
Not wind rated ESF655P
ENG
22014-09-24 #:203-9450-2 (2017-04-04)
ENG - This product is designed to be installed on wood stud, solid concrete or cinder block walls. Hardware is
included for wood stud, solid concrete and cinder block installation. Before installing make sure the supporting
surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do
not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity.
Always use an assistant or mechanical lifting equipment to safely lift and position equipment. Be careful not to
pinch îš¿ngers when operating the mount. For support please call customer care at 1-800-865-2112.
WARNING
Symbols
ENG
WARNING
ENG
#
Skip to step.
ENG
x3
Screws must get at least
three full turns and îš¿t snug.
ENG
Tools Needed for Assembly.
ENG
1
2
ENG To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
+1/2
4
3
5/32"
(4mm)
5/16"
(8mm)
3/8"
(10mm)
Do not overtighten screws.
ENG
Display center.
ENG
32014-09-24 #:203-9450-2 (2017-04-04)
C (1)
allen wrench
Parts (Before beginning, make sure you have all parts shown below).
ENG
A (1)
wall plate
Parts List ESF655P
Part #Description Qty
Awall plate 1 201-T5946
Badapter bracket 2 200-T5946
C4mm allen wrench 1 560-1727
Dconcrete anchor 4 590-0320
E#14 x 2.5" wood screw 4 520-D1033
FM8 x 25mm 4 520-5027
Gwasher 4 540-D9406
Hspacer 4 540-1059
D (4)
8mm concrete anchor
E (4)
#14 x 2-1/2" wood screw
F (4)
M8 x 25mm
H (4)
spacer
G (4)
washer
B (2)
adapter bracket
1a
ENG - When installing Peerless wall mounts on a wood stud wall covered with gypsum board (drywall), verify that
the wood studs are a minimum of 2" x 4" nominal size. Do not install over gypsum board thicker than 5/8".
WARNING
1
1b
Wood stud wall. Concrete/Cinder block.
1a
ENGENG
