Contents

OPERATING INSTRUCTIONS

Personal Computer

Model No. FZ-G1 series

Introduction ....................................................13

Description of Parts .......................................15

First-time Operation .......................................17

Turning On / Turning Off ................................23

Useful Information

Handling and Maintenance ............................24

Installing Software .........................................28

Troubleshooting

Troubleshooting (Basic) .................................33

Appendix

LIMITED USE LICENSE AGREEMENT ........39

Specications ................................................41

Standard Limited Warranty ............................46

Please read these instructions carefully before using this product, and save this manual for future use.

Getting Started

Useful Information

Troubleshooting

Appendix Read Me First

Getting Started

Safety Precautions .......................................... 2

Regulatory Information .................................... 7

Read Me First

Safety Precautions

To reduce the risk of injury, loss of life, elec-

tric shock, re, malfunction, and damage to

equipment or property, always observe the

following safety precautions.

Explanation of symbol word panels

The following symbol word panels are used

to classify and describe the level of hazard,

injury, and property damage caused when the

denotation is disregarded and improper use is

performed.

DANGER

Denotes a potential hazard that will result in

serious injury or death.

WARNING

Denotes a potential hazard that could result

in serious injury or death.

CAUTION

Denotes a hazard that could result in minor

injury.

NOTICE

Denotes a hazard that could result in prop-

erty damage.

The following symbols are used to classify

and describe the type of instructions to be

observed.

These symbols are used to alert users

to a specic operating procedure that

must not be performed.

This symbol is used to alert users to

a specic operating procedure that

must be followed in order to operate

the unit safety.

DANGER

Precautions on the Battery Pack

Do Not Throw the Battery Pack into

a Fire or Expose It to Excessive Heat

Generation of heat, ignition or rupture

may result.

Do Not Insert Sharp Objects Into

the Battery Pack, Disassemble, or

Modify It

Electrolyte leakage, generation of heat,

ignition or rupture may result.

Do Not Short the Positive (+) and

Negative (-) Contacts

Generation of heat, ignition or rupture

may result.

• Do not place the battery pack to-

gether with articles such as neck-

laces or hairpins when carrying or

storing.

Avoid Extreme Heat (Near the Fire,

in Direct Sunlight, for Example)

Electrolyte leakage, generation of heat,

ignition or rupture may result.

Do Not Apply Shocks to the Prod-

uct by Dropping It, Applying Strong

Pressure to It, etc.

Electrolyte leakage, generation of heat,

ignition or rupture of the battery may

result.

• If this product is subjected to a

strong impact, damaged or de-

formed, stop using it immediately.

Do Not Charge the Battery Using

Methods Other Than Those Speci-

ed

If the battery is not charged using one

of the specied methods, electrolyte

leakage, generation of heat, ignition or

rupture may result.

When the Battery Pack Has Deterio-

rated, Replace It With a New One

Continued use of a damaged battery

pack may result in heat generation,

ignition or battery rupture.

Read Me First

DANGER

Precautions on the Battery Pack

Do Not Use with Any Other Product

The battery pack is rechargeable and

was intended for the specied product.

If it is used with a product other than

the one for which it was designed,

electrolyte leakage, generation of heat,

ignition or rupture may result.

Do Not Use This Product with a Bat-

tery Pack Other Than the One Speci-

ed

Use only the specied battery pack

( page 17) with your product.

Use of battery packs other than those

manufactured and supplied by Pana-

sonic may present a safety hazard

(generation of heat, ignition or rupture).

WARNING

If a Malfunction or Trouble Occurs,

Immediately Stop Use

If a Malfunction Occurs, Immediately

Unplug the AC Plug and the Battery

Pack

• This product is damaged

• Foreign object inside this product

• Smoke emitted

• Unusual smell emitted

• Unusually hot

Continuing to use this product while

any of the above conditions are pres-

ent may result in re or electric shock

• If a malfunction or trouble occurs,

immediately turn the power off and

unplug the AC plug, and then re-

move the battery pack. Then con-

tact your technical support ofce for

repair.

Do Not Touch This Product in a

Thunderstorm If Connected with the

AC Cable or Any Other Cables

Electric shock may result.

Do Not Connect the AC Adaptor to

a Power Source Other Than a Stan-

dard Household AC Outlet

Otherwise, a re due to overheating

may result. Connecting to a DC/AC

converter (inverter) may damage the

AC adaptor. On an airplane, only con-

nect the AC adaptor/charger to an AC

outlet specically approved for such

use.

Do Not Pull or Insert the AC Plug If

Your Hands Are Wet

Electric shock may result.

Clean Dust and Other Debris of the

AC Plug Regularly

If dust or other debris accumulates

on the plug, humidity, etc. may cause

a defect in the insulation, which may

result in a re.

• Pull the plug, and wipe it with a dry

cloth.

Pull the plug if the computer is not

being used for a long period of time.

Insert the AC Plug Completely

If the plug is not inserted completely,

re due to overheating or electric shock

may result.

•

Do not use a damaged plug or loose

AC outlet.

Close the Connector Cover Tightly

When Using This Product Where

Is a Lot of Water, Moisture, Steam,

Dust, Oily Vapors, etc.

The entry of foreign matter may cause

a re or electric shocks.

• If foreign matter has found its way

inside, immediately turn the power

off and unplug the AC cord, and

then remove the battery pack. Then

contact your technical support of-

ce.

Do Not Disassemble This Product

You may receive an electric shock, or

foreign matter may enter and result in

a re.
