Operating Instructions

CD Stereo System

Model No. SC-AKX16

Thank you for purchasing this product.

For optimum performance and safety, please read these instructions carefully.

Please keep this manual for future reference.

Panasonic Corporation

Web Site: http://panasonic.net

RQT9791-B

L1212HH0

Pursuant to the applicable EU legislation

Panasonic Marketing Europe GmbH

Panasonic Testing Centre

Winsbergring 15, 22525 Hamburg, Germany

Do the procedures with the remote control. You can

also use the buttons on the main unit if they are the

same.

Your system and the illustrations can look differently.

These operating instructions are applicable to the following

system.

Back of product

Safety precautions

WARNING!

Unit

• To reduce the risk of fire, electric shock or product

damage,

– Do not expose this unit to rain, moisture, dripping or

splashing.

– Do not place objects filled with liquids, such as vases,

on this unit.

– Use only the recommended accessories.

– Do not remove covers.

– Do not repair this unit by yourself. Refer servicing to

qualified service personnel.

• Do not let metal objects fall inside this unit.

CAUTION!

Unit

• To reduce the risk of fire, electric shock or product

damage,

– Do not install or place this unit in a bookcase, built-in

cabinet or in another confined space. Ensure this unit

is well ventilated.

– Do not obstruct this unit’s ventilation openings with

newspapers, tablecloths, curtains, and similar items.

– Do not place sources of naked flames, such as lighted

candles, on this unit.

• Set the unit up on an even surface away from direct

sunlight, high temperatures, high humidity, and excessive

vibration.

• This unit is intended for use in moderate climates.

• The mains plug is the disconnecting device. Install this

unit so that the mains plug can be unplugged from the

socket outlet immediately.

• This unit may receive radio interference caused by

mobile telephones during use. If such interference

occurs, please increase separation between this unit and

the mobile telephone.

• This unit utilizes a laser. Use of controls or adjustments

or performance of procedures other than those specified

herein may result in hazardous radiation exposure.

Battery

• Danger of explosion if battery is incorrectly replaced.

Replace only with the type recommended by the

manufacturer.

• When disposing the batteries, please contact your local

authorities or dealer and ask for the correct method of

disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct

sunlight for a long period of time with doors and windows

closed.

• Do not break open or short-circuit the battery.

• Do not charge the alkaline or manganese battery.

• Do not use the battery if the cover has peeled off.

• Remove the battery if you do not use the remote control

for a long period of time. Keep in a cool, dark area.

System SC-AKX16

Main unit SA-AKX16

Speakers SB-AKX16

Caution for AC mains lead

For the United Kingdom

For your safety, please read the following text carefully.

This appliance is supplied with a moulded three pin mains

plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure that the

replacement fuse has a rating of 5-ampere and that it is

approved by ASTA or BSI to BS1362.

Check for the ASTA mark or the BSI mark on the body

of the fuse.

If the plug contains a removable fuse cover you must

ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used until a

replacement cover is obtained.

A replacement fuse cover can be purchased from your local

dealer.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of AC

mains plug (figures A and B). Confirm the AC mains plug

fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

2. Replace the fuse and close or attach the fuse cover.

Sales and Support Information

For the United Kingdom and Ireland

Customer Communications Centre

• For customers within the U.K.: 0844 844 3899

• For customers within Ireland: 01289 8333

• Monday – Friday 9:00am – 5:00pm (Excluding public

holidays).

• For further support on your product, please visit our

website: www.panasonic.co.uk

Direct Sales at Panasonic U.K.

• Order accessory and consumable items for your

product with ease and confidence by phoning our

Customer Communications Centre Monday – Friday

9:00am – 5:00pm (Excluding public holidays).

• Or go on line through our Internet Accessory ordering

application at www.pas-europe.com.

• Most major credit and debit cards accepted.

• All enquiries transactions and distribution facilities are

provided directly by Panasonic U.K.

• It couldn’t be simpler!

• Also available through our Internet is direct shopping for

a wide range of finished products. Take a browse on our

website for further details.

Supplied accessories

Check and identify the supplied accessories.

Use numbers indicated in parentheses when asking for

replacement parts. (Product numbers correct as of

December 2012. These may be subject to change.)

2 x AC mains lead

For the United Kingdom

(K2CT2YY00097)

For others

(K2CQ2YY00119)

1 x AM loop antenna

(N1DYYYY00011)

1 x FM indoor antenna

(RSAX0002)

1 x Remote control battery

1 x Remote control

(N2QAYB000900)

 For the United Kingdom

1 x Antenna plug adaptor

(K1YZ02000013)

Figure A Figure B

Fuse cover

Figure A Figure B

Fuse (5 ampere)

Placement of speakers

The left and right speakers are the same.

You cannot remove the net of the speakers.

Use only the supplied speakers.

You can cause damage to the system and decrease the

sound quality if you use other speakers.

Note:

• Keep your speakers more than 10 mm from the main unit

for ventilation.

• Put the speakers on a flat safe surface.

• These speakers do not have magnetic shielding. Do not

put them near TVs, PCs or other equipment easily

influenced by magnetism.

• When you play at high levels for a long period, it can

cause damage to the speakers and decrease the life of

the speakers.

• Decrease the volume in these conditions to prevent

damage:

– When the sound is distorted.

– When you adjust the sound quality.

Preparing the remote control

Use alkaline or manganese battery.

Install the battery so that the poles (+ and –) align with those

in the remote control.

Information for Users on Collection and Disposal of

Old Equipment and Used Batteries

These symbols on the products, packaging,

and/or accompanying documents mean that

used electrical and electronic products and

batteries should not be mixed with general

household waste.

For proper treatment, recovery and recycling of

old products and used batteries, please take

them to applicable collection points, in

accordance with your national legislation and

the Directives 2002/96/EC and 2006/66/EC.

By disposing of these products and batteries

correctly, you will help to save valuable

resources and prevent any potential negative

effects on human health and the environment

which could otherwise arise from inappropriate

waste handling.

For more information about collection and

recycling of old products and batteries, please

contact your local municipality, your waste

disposal service or the point of sale where you

purchased the items.

Penalties may be applicable for incorrect

disposal of this waste, in accordance with

national legislation.

For business users in the European Union

If you wish to discard electrical and electronic

equipment, please contact your dealer or

supplier for further information.

[Information on Disposal in other Countries

outside the European Union]

These symbols are only valid in the European

Union. If you wish to discard these items,

please contact your local authorities or dealer

and ask for the correct method of disposal.

Note for the battery symbol (bottom two

symbol examples):

This symbol might be used in combination with

a chemical symbol. In this case it complies with

the requirement set by the Directive for the

chemical involved.

CAUTION!

•Use the speakers only with the recommended

system. If not, you can cause damage to the

amplifier and speakers and can cause a fire.

Consult an approved service personnel if damage

occurs or if there is a sudden apparent change in

performance.

•Do the procedures included in these instructions

when you attach the speakers.

Making the connections

Connect the AC mains lead only after all the other

connections have been made.

1Connect the AM loop antenna.

Stand the antenna up on its base until it clicks.

2Connect the FM indoor antenna.

Place the antenna where reception is best.

3Connect the speakers.

Connect the speaker cables to the terminals of the

same colour.

4Connect the AC mains lead.

Do not use an AC mains lead from other equipment.

Conserving power

The system consumes approximately 0.4 W when it is

in standby mode. Disconnect the power supply if you

do not use the system.

Some settings will be lost after you disconnect the

system. You have to set them again.

1234

For the United Kingdom

Connect the FM outdoor antenna

If the radio reception is poor, use an optional outdoor

antenna. This antenna should be installed by a

competent technician.

Note:

• Do not use the outdoor antenna during a lightning

storm.

• Disconnect the outdoor antenna when the unit is

not in use.

Tape

FM outdoor antenna

(not supplied)

75 coaxial cableȍ

(not supplied)

Use the antenna plug

adaptor (supplied).

Be careful not to cross

(short-circuit) or reverse the

polarity of the speaker wires

as doing so may damage the

speakers.

For the United Kingdom

READ THE CAUTION FOR AC MAINS LEAD

BEFORE CONNECTION.

Black

Red

To household

mains socket

Overview of controls

AStandby/on switch [ ]`], [1

Press to switch the unit from on to standby mode or vice

versa. In standby mode, the unit is still consuming a

small amount of power.

BNumeric buttons [1 to 9, 0, 10]

To select a 2-digit number

Example: 16: [ 10]= =[1] [6]

CDelete a programmed track

DSelect audio source

EBasic playback control

FSelect the sound effects

GAuto preset the radio station

HView content information

Decrease the brightness of the display panel

Press and hold the button to use this function.

To cancel, press and hold the button again.

ISet the clock and timer

JSet the program function

KAdjust the volume of the system

LMute the sound of the system

Press the button again to cancel.

“MUTE” is also cancelled when you adjust the volume

or when you switch off the system.

MSet the play menu item

NSet the radio menu item

OSelect the option

PAutomatically switch off the system

When you are in disc, USB or AUX source, the auto off

function switches off the system if you do not use the

system for 30 minutes.

To cancel, press the button again.

QRemote control sensor

Distance: Within approximately 7 m

Angle: Approximately 20° up and down, 30° left and

right

RSelect bass, mid or treble effect

SUSB port ( )

TDisplay panel

UOpen or close the disc tray

VDisc tray

RADIO

EXT-IN

SOUND

PRESET EQ

D.BASS

DISPLAY

DIMMER

SLEEP

PLAY

AUTO OFF

MANUAL EQ

D.BA SS

TUNE MODE

USB

RADIO/

EXT-IN

–

VOLUME

OPE N

PR ESET EQ

Disc

Playing disc

1Press [x OPEN/CLOSE] on the main unit to open

the disc tray.

Put in a disc with the label facing up.

Press [x OPEN/CLOSE] again to close the disc tray.

2Press [CD] and then press [ ] to start playback.4 9/

Viewing available information

You can view the available information on the display panel.

Press [DISPLAY].

Note:

• Maximum characters that can be shown:

approximately 16

• This system supports ver. 1.0 and 1.1 ID3 tags.

• Text data that the system does not support can show

differently.

Play menu

1Press [PLAY MENU] to select “PLAYMODE” or

“REPEAT”.

2Press [Y U, ] and then press [OK] to select the

desired mode.

Note:

The setting returns to the default “OFF PLAYMODE” when

you open the disc tray.

Program playback

This function allows you to program up to 24 tracks.

1Press [PROGRAM] in the stop mode.

“PGM” is shown.

Press the numeric buttons to select the desired

track.

Do this step again to program other tracks.

1. Press [R T, ] to select the desired album.

2. Press [6] and then press the numeric buttons

to select the desired track.

3. Press [OK].

Do these steps again to program other tracks.

3Press [4 9/ ] to start playback.

Note:

• You cannot use program playback together with

“PLAYMODE” function.

• The program memory is cleared when you open the disc

tray.

Stop playback Press [8].

Pause playback Press [4 9/ ].

Press again to continue playback.

Skip album Press [R T, ].

Skip track Press [2] or [6]

(main unit: [2 3/ ] or [5 6/ ]).

Search through

track

Press and hold [3 5] or [ ]

(main unit: [2 3/ ] or [5 6/ ]).

PLAYMODE

OFF

PLAYMODE

Play all tracks.

1-TRACK

1TR

Play one selected track on the disc.

Press the numeric buttons to select the

track.

1-ALBUM

1ALBUM

Play one selected album on the disc.

Press [R T, ] to select the album.

RANDOM

RND

Play a disc randomly.

1-ALBUM

RANDOM

1ALBUM RND

Play all tracks in one selected album

randomly.

Press [R T, ] to select the album.

REPEAT

ON REPEAT Repeat playback.

OFF REPEAT Cancel repeat playback.

Cancel program

mode

Press [PROGRAM] in the stop mode.

Check program

contents

Press [2] or [6] when “PGM” is

shown in the stop mode.

Clear the last

track

Press [DEL] in the stop mode.

Clear all

programmed

tracks

Press [8] in the stop mode.

“CLR ALL” is shown. Within 5 seconds,

press [8] again.

Clock and timers

Setting the clock

This is a 24-hour clock.

1Press [CLOCK/TIMER] to select “CLOCK”.

2Within 10 seconds, press [R T, ] to set the time.

3Press [OK].

Press [CLOCK/TIMER] to show the clock for a few seconds.

Note:

Reset the clock regularly to maintain accuracy.

Sleep timer

The sleep timer switches off the system after the set time.

Press [SLEEP] to select the setting (in minutes).

To cancel, select “OFF”.

To show the remaining time

Press [SLEEP].

Note:

• The sleep timer can be used together with the play timer.

• The sleep timer always comes first. Be sure not to set an

overlap of timers.

Play timer

You can set the timer to come on at a certain time to wake

you up.

Preparation

Set the clock.

1Press [CLOCK/TIMER] to select “#PLAY”.

2Within 10 seconds, press [R T, ] to set the start

time.

3Press [OK].

4Do steps 2 and 3 again to set the end time.

To start the timer

1Prepare the audio source you want to listen to

(disc, radio, USB or AUX) and set the volume.

2Press [PLAY #].

“#” is shown.

To cancel, press [PLAY #] again.

The system must be switched off for the timer to

operate.

To check the settings

Press [CLOCK/TIMER] to select “#PLAY”.

Note:

• The timer starts at a low volume and increases gradually

to the preset level.

• The timer comes on at the set time every day if the timer

is on.

• If you switch off the system and switch on again while a

timer is in operation, the timer will not stop at the end

time.

External equipment

You can connect a VCR, DVD player etc. and listen to the

audio through this system.

Preparation

• Disconnect the AC mains lead.

• Switch off all equipment and read the appropriate

operating instructions.

1Connect the external equipment.

2Press [RADIO, EXT-IN] (main unit:

[RADIO/EXT-IN]) to select “AUX”.

3Play the external equipment.

Note:

• Components and cables are sold separately.

• If you want to connect equipment other than those

described, refer to the audio dealer.

• Sound distortion can occur when you use an adaptor.

FFONIM03 ĺ120

MINĺĺ 60

MIN

DVD player (not supplied)

Rear panel of

this main unit

Audio cable

(not supplied)

Troubleshooting

Before requesting service, make the following checks. If

you are in doubt about some of the check points, or if the

solutions indicated do not solve the problem, consult your

dealer for instructions.

Common problems

The display panel lights up and changes continuously

in standby mode.

• Press and hold [8] on the main unit to select

“DEMO OFF”.

No operations can be done with the remote control.

• Examine that the battery is installed correctly.

Sound is distorted or no sound.

• Adjust the volume of the system.

• Switch off the system, determine and correct the cause,

then switch the system on again. It can be caused by

straining of the speakers through excessive volume or

power, and when using the system in a hot environment.

A humming sound can be heard during playback.

• An AC mains lead or fluorescent light is near the cables.

Keep other appliances and cords away from the cables of

this system.

Disc

Display not shown correctly.

Playback does not start.

• You have not put in the disc correctly. Put it in correctly.

• Disc is dirty. Clean the disc.

• Replace the disc if it is scratched, warped, or

non-standard.

• There is condensation. Let the system dry for 1 to 2

hours.

The total number of tracks displayed is incorrect.

The disc cannot be read.

Distorted sound is heard.

• You put in a disc that the system cannot play. Change to

a playable disc.

• You put in a disc that has not been finalised.

Radio

Sound is distorted.

• Use an optional FM outdoor antenna. The antenna

should be installed by a competent technician.

A beat sound is heard.

• Switch off the TV or move it away from the system.

A low hum is heard during AM broadcasts.

• Move the antenna away from other cables and cords.

USB

The USB device or the contents in it cannot be read.

• The format of the USB device or the contents in it is/are

not compatible with the system.

• USB devices with storage capacity of more than 32 GB

cannot work in some conditions.

Slow operation of the USB device.

• Large content size or large memory USB device takes

longer time to read.

Main unit displays

“ERROR”

• An incorrect operation was done. Read the instructions

and try again.

“F61”

• Examine and correct the speaker cords connection.

• Disconnect the USB device. Switch off the system and

then switch it on again.

“NODEVICE”

• The USB device is not connected. Examine the

connection.

“NO PLAY”

“UNSUPPORT”

• Examine the content. You can only play supported

format.

• The files in the USB device can be corrupted. Format the

USB device and try again.

“NOT MP3 = ERROR”

• You played an unsupported MP3 file. The system will skip

that track and play the next one.

“PLAYERROR”

• You played an unsupported MP3 file. The system will skip

that track and play the next one.

“REMOTE 1” or “REMOTE 2”

• The remote control and the main unit are using different

codes. Change the code of the remote control.

– When “REMOTE 1” is shown, press and hold [OK] and

[1] for a minimum of 4 seconds.

– When “REMOTE 2” is shown, press and hold [OK] and

[2] for a minimum of 4 seconds.

“VBR–”

• The system cannot show the remaining play time for

variable bit rate (VBR) tracks.

Remote control code

When other Panasonic equipment responds to the remote

control of this system, change the remote control code for

this system.

Preparation

Press [RADIO, EXT-IN] (main unit: [RADIO/EXT-IN]) to

select “AUX”.

To set the code to “REMOTE 2”

1Press and hold [RADIO/EXT-IN] on the main unit

and [2] on the remote control until “REMOTE 2” is

shown.

2Press and hold [OK] and [2] for a minimum of

4 seconds.

To set the code to “REMOTE 1”

1Press and hold [RADIO/EXT-IN] on the main unit

and [1] on the remote control until “REMOTE 1” is

shown.

2Press and hold [OK] and [1] for a minimum of

4 seconds.

Memory reset (initialisation)

Reset the memory when the following situations occur:

• There is no response when buttons are pressed.

• You want to clear and reset the memory contents.

1Disconnect the AC mains lead.

2While you press and hold [1] on the main unit,

connect the AC mains lead again.

Continue to press and hold the button (approximately

10 seconds) until “– – – – – – – –” is shown.

3Release [1].

All the settings are set back to the factory preset.

It is necessary to set the memory items again.

Maintenance

To clean this system, wipe with a soft, dry cloth.

• Never use alcohol, paint thinner or benzine to clean this

system.

• Before using chemically treated cloth, read the

instructions that came with the cloth carefully.

Specifications

Amplifier section

RMS output power stereo mode

Front Ch (both ch driven)

175 W per channel (4 ȍ), 1 kHz, 30% THD

Total RMS stereo mode power 350 W (30% THD)

Tuner, terminals section

Preset memory FM 30 stations

AM 15 stations

Frequency modulation (FM)

Frequency range

87.50 MHz to 108.00 MHz (50 kHz step)

Antenna terminals 75 ȍ (unbalanced)

Amplitude modulation (AM)

Frequency range 522 kHz to 1629 kHz (9 kHz step)

520 kHz to 1630 kHz (10 kHz step)

AUX input RCA pin jack

Disc section

Disc played (8 cm or 12 cm)

CD, CD-R/RW (CD-DA, MP3 )

Pick up

Wavelength 790 nm (CD)

Laser power CLASS 1

Audio output (disc)

Number of channels 2 ch (FL, FR)

FL = Front left channel

FR = Front right channel

MPEG-1 Layer 3

USB section

USB port

USB standard USB 2.0 full speed

Media file format support MP3 (*.mp3)

USB device file system FAT12, FAT16, FAT32

USB port power 500 mA (max)

Bit rate 16 kbps to 320 kbps (playback)

Speaker section

Type 2 way, 2 speaker system (bass reflex)

Speaker unit(s)

Woofer 16 cm cone type

Tweeter 6 cm cone type

Impedance 4 ȍ

Output sound pressure 85 dB/W (1 m)

Frequency range 48 Hz to 22 kHz (–16 dB)

52 Hz to 20 kHz (–10 dB)

Dimensions (W x H x D) 200 mm x 334 mm x 193 mm

Mass 2.5 kg

General

Power supply AC 220 to 240 V, 50 Hz

Power consumption 58 W

Dimensions (W x H x D) 220 mm x 334 mm x 250 mm

Mass 2.8 kg

Operating temperature range 0°C to +40°C

Operating humidity range

35% to 80% RH (no condensation)

Note:

• Specifications are subject to change without notice.

Mass and dimensions are approximate.

• Total harmonic distortion is measured by the digital

spectrum analyzer.

Power consumption in standby mode

0.4 W (approximate)

Note on disc

• This system can play CD-R/RW with CD-DA or MP3

format content.

• Some CD-R/RW cannot be played because of the

condition of the recording.

• MP3 files are defined as tracks and folders are defined as

albums.

• This system can access up to:

– CD-DA: 99 tracks

– MP3: 999 tracks, 255 albums and 20 sessions

• Disc must conform to ISO9660 level 1 or 2 (except for

extended formats).

• Recordings will not necessarily be played in the order you

recorded them.

USB

You can connect and play music tracks from your USB

device.

Do not use a USB extension cable. The system cannot

recognise USB device connected through a cable.

1Decrease the volume and connect the USB device

to the USB port.

Hold the main unit when connecting or disconnecting

the USB device.

2Press [USB] and then press [4 9/ ] to start

playback.

For other operations, refer to “Disc”.

Compatible USB devices which are defined as mass

storage class:

• USB devices that support bulk-only transfer.

• USB devices that support USB 2.0 full speed.

Note:

• Files are defined as tracks and folders are defined as

albums.

• Track must have the extension “.mp3” or “.MP3”.

• This system can access up to:

– 800 albums (including root folder)

– 8000 tracks

– 999 tracks in one album

• CBI (Control/Bulk/Interrupt) is not supported.

• NTFS file system is not supported (only FAT 12/16/32 file

system is supported).

• Some files can fail to work because of the sector size.

Sound effects

MPEG Layer-3 audio coding technology licensed from

Fraunhofer IIS and Thomson.

Stop playback Press [8] during playback.

“RESUME” is shown.

Press [4 9/ ] to continue playback.

Press [8] two times to stop the playback

fully.

BASS

MID

TREBLE

1. Press [SOUND] to select “BASS”,

“MID” or “TREBLE”.

2. Press [Y U, ] to adjust the level

(-4 to +4).

By main unit only

1. Press [MANUAL EQ] to select

“BASS”, “MID” or “TREBLE”.

2. Press [2 3/ ] or [5 6/ ] to

adjust the level.

SURROUND 1. Press [SOUND] to select

“SURROUND”.

2. Press [Y U, ] to select

“ON SURROUND” or

“OFF SURROUND”.

INPUT LEVEL

(For AUX

source)

1. Press [SOUND] to select

“INPUT LEVEL”.

2. Press [Y, U] to select “NORMAL” or

“HIGH”.

Note:

Select “NORMAL” if the sound is

distorted during “HIGH” input level.

RE-MASTER 1. Press [SOUND] to select

“RE-MASTER”.

2. Press [Y U, ] to select

“ON RE-MASTER” or

“OFF RE-MASTER”.

PRESET EQ Press [PRESET EQ] to select “HEAVY”,

“SOFT”, “CLEAR”, “VOCAL” or “FLAT”.

D.BASS Press [D.BASS] to select “D.BASS”,

“AUTO D.BASS” or “OFF D.BASS”.

Radio

Manual tuning

1Press [RADIO, EXT-IN] to select “FM” or “AM”.

2Press [3] or [5] to select the frequency of the

required station.

To tune automatically, press and hold the button until

the frequency starts changing quickly.

Using the main unit

1Press [RADIO/EXT-IN] to select “FM” or “AM”.

2Press [TUNE MODE] to select “MANUAL”.

3Press [2 3/ ] or [5 6/ ] to select the

frequency of the required station.

Improving the sound quality

When “FM” is selected

1Press [RADIO MENU] to select “FM MODE”.

2Press [Y U, ] to select “MONO” and then press

[OK].

To cancel, select “STEREO”.

“MONO” is also cancelled when you change the

frequency.

Memory presetting

30 FM and 15 AM stations can be preset.

Automatic presetting

1Press [OK] to select “LOWEST” or “CURRENT”

frequency.

2Press [AUTO PRESET] to start presetting.

To cancel, press [8].

Manual presetting

1Press [3] or [5] to tune in to the station.

2Press [PROGRAM].

3Press the numeric buttons to select a preset

number.

Do steps 1 through 3 again to preset more stations.

The new station replaces any station that occupies the

same preset number.

Selecting a preset station

Press the numeric buttons, [2] or [6] to select the

preset station.

Using the main unit

1Press [TUNE MODE] to select “PRESET”.

2Press [2 3/ ] or [5 6/ ] to select the preset

station.

AM allocation setting

By main unit only

This system can also receive AM broadcasts allocated in

10 kHz steps.

1Press [RADIO/EXT-IN] to select “FM” or “AM”.

2Press and hold [RADIO/EXT-IN].

After a few seconds, the display panel shows the current

minimum radio frequency. Release the button when the

minimum frequency changes.

• To go back to the initial setting, do the above steps again.

• After you change the setting, preset frequencies are

erased.

RDS broadcasting

This system can show the text data transmitted by the radio

data system (RDS) available in some areas.

Press [DISPLAY].

Note:

RDS may not be available if reception is poor.

PS Station name

PTY Program type

FREQ Frequency

Produktspezifikationen

Marke:	Panasonic
Kategorie:	Nicht kategorisiert
Modell:	SC-VKX20

Brauchst du Hilfe?

Wenn Sie Hilfe mit Panasonic SC-VKX20 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Panasonic

Panasonic ER-CFC1 Bedienungsanleitung

27 September 2024

Panasonic RP-SDW48GE1K Bedienungsanleitung

15 September 2024

Panasonic Diagnostec EW-BU30 Bedienungsanleitung

10 September 2024

Panasonic DMW-XLR2 Bedienungsanleitung

5 September 2024

Panasonic C-D535AF Bedienungsanleitung

5 September 2024

Panasonic ES-WM31 Bedienungsanleitung

5 September 2024

Panasonic NC-30EP Bedienungsanleitung

5 September 2024

Panasonic NC-22HP Bedienungsanleitung

5 September 2024

Panasonic VariCam AU-VCVF20G Bedienungsanleitung

5 September 2024

Panasonic NH-EH90JD1WA Bedienungsanleitung

5 September 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
