Seite 1/28
EB RQT7997-1B
GNE
Table of contents
Dear customer
Thank you for purchasing this product.
Before connecting, operating or adjusting this product, please read
the instructions completely.
Please keep this manual for future reference.
Note:
“EB” on the packaging indicates the United Kingdom.
Before use
Caution for AC Mains Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
How to set up the Home Theater . . . . . . . . . . . . . . 3
Supplied accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connections
Home Theater connections
1. TV and DVD player . . . . . . . . . . . . . . . 4
• Basic connection. . . . . . . . . . . . . . . . . . . . . . . . 4
• High picture quality connection . . . . . . . . . . . . 5
• DVD ANALOG 6CH connection . . . . . . . . . . . . 5
2. Speakers . . . . . . . . . . . . . . . . . . . . . . . 6
• Bi-wiring connection . . . . . . . . . . . . . . . . . . . . 8
• Using speaker terminal B . . . . . . . . . . . . . . . . . 8
3. AC mains lead . . . . . . . . . . . . . . . . . . 8
Other connections
• DVD recorder . . . . . 9 • VCR . . . . . . . . . . . . 9
• Cable box or satellite receiver etc. . . . . . . . . . 10
• CD player . . . . . . . 10 • Tape deck . . . . . . 10
• Game player etc. . 10 • Antennas . . . . . . . 11
The remote control . . . . . . . . . . . 11
Settings
Receiver settings
-
Basic . . . . . . 12
Settings
-
Test . . . . . . . . . . . . . . . 13
Basic
Operations
Basic operations
Playback . . . . . . . . . . . . . . . . . . . . . . . . 14
Using Surround effects . . . . . . . . . . . . 15
Operations
Control guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound quality/Sound field/Convenient functions . . . . . . . . . . . . 18
Making a recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Receiver settings
-
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
The radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
RDS broadcasts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Remote control mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Multi control menus and factory settings . . . . . . . . . . . . . . . . . . 25
Reference
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . .Back cover
Model No. SA-XR55
Operating Instructions
AV Control Receiver
ENGLISH
2
RQT7997 Before use
Caution for AC Mains Lead Safety precautions
Set the unit up on an even surface away from direct sunlight, high
temperatures, high humidity, and excessive vibration. These conditions
can damage the cabinet and other components, thereby shortening the
unit’s service life.
Do not place heavy items on the unit.
Do not use high voltage power sources. This can overload the unit and
cause a fire.
Do not use a DC power source. Check the source carefully when
setting the unit up on a ship or other place where DC is used.
Ensure the AC mains lead is connected correctly and not damaged.
Poor connection and lead damage can cause fire or electric shock. Do not
pull, bend, or place heavy items on the lead.
Grasp the plug firmly when unplugging the lead. Pulling the AC mains
lead can cause electric shock.
Do not handle the plug with wet hands. This can cause electric shock.
Do not let metal objects fall inside the unit. This can cause electric
shock or malfunction.
Do not let liquids get into the unit. This can cause electric shock or
malfunction. If this occurs, immediately disconnect the unit from the power
supply and contact your dealer.
Do not spray insecticides onto or into the unit. They contain flammable
gases which can ignite if sprayed into the unit.
Do not attempt to repair this unit by yourself. If sound is interrupted,
indicators fail to light, smoke appears, or any other problem that is not
covered in these operating instructions occurs, disconnect the AC mains
lead and contact your dealer or an authorized service center. Electric
shock or damage to the unit can occur if the unit is repaired,
disassembled or reconstructed by unqualified persons.
Extend operating life by disconnecting the unit from the power source if
it is not to be used for a long time.
nSales and Support Information
(For the United Kingdom and Republic of Ireland)
Customer Care Centre
• For UK customers: 08705 357357
• For Republic of Ireland customers: 01 289 8333
• Visit our website for product information
• E-mail: customer.care@panasonic.co.uk
Direct Sales at Panasonic UK
• Order accessory and consumable items for your product with
ease and confidence by phoning our Customer Care Centre
Monday-Friday 9:00am-5:30pm. (Excluding public holidays)
• Or go on line through our Internet Accessory ordering
application at www.panasonic.co.uk
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution facilities are provided
directly by Panasonic UK Ltd.
• It couldn’t be simpler!
• Also available through our Internet is direct shopping for a wide
range of finished products, take a browse on our website for
further details.
(For United Kingdom)
(“EB” area code model only)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug for
your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5-ampere and that it is approved
by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it
is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR
THE SOCKET OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND THE PLUG CUT
OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK IF THE CUT OFF PLUG IS INSERTED INTO
ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring code as stated
below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the
following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be connected to the
terminal which is marked with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE
EARTH TERMINAL WHICH IS MARKED WITH THE
LETTER E, BY THE EARTH SYMBOL OR
COLOURED GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF–KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC mains
plug (figures A and B). Confirm the AC mains plug fitted and follow
the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
Fuse cover
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A Figure B
(For United Kingdom)
(“EB” area code model only)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug for
your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 5-ampere and that it is approved
by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it
is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR
THE SOCKET OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND THE PLUG CUT
OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL
SHOCK IF THE CUT OFF PLUG IS INSERTED INTO
ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring code as stated
below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the
following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be connected to the
terminal which is marked with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE
EARTH TERMINAL WHICH IS MARKED WITH THE
LETTER E, BY THE EARTH SYMBOL OR
COLOURED GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF–KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC mains
plug (figures A and B). Confirm the AC mains plug fitted and follow
the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach the fuse cover.
Fuse cover
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
Figure A Figure B
Placement
Voltage
AC mains lead protection
Foreign matter
Service
CAUTION!
Do not place anything on top of this unit or block the heat radiation
vents in any way. In particular, do not place tape decks or CD/DVD
players on this unit as heat radiated from it can damage your software.
3
RQT7997 Before use ENGLISH
How to set up the Home Theater
You can create your desired environment by connecting other peripheral equipment.
Connections Settings
These settings are necessary to
output the audio correctly.
Operations
7.1/6.1-channel
surround
TV, DVD player, etc.
+
Speakers
• 2 Front speakers
• 1 Center speaker
• 2 Surround speakers
• 2 Surround back speakers
(1 Surround back speaker)
• 1 Subwoofer
Speakers combination
settings
+
Surround back speaker
settings
• Output 5.1-channel sound
in 7.1/6.1-channel
• Output a stereo source in
7.1/6.1-channel
Dolby Pro Logic
DTS NEO:6
SFC
• Stereo playback
5.1-channel
surround
TV, DVD player, etc.
+
Speakers
• 2 Front speakers
• 1 Center speaker
• 2 Surround speakers
• 1 Subwoofer
Speakers combination
settings
• Output a stereo source in
5.1-channel
Dolby Pro Logic
DTS NEO:6
SFC
• Stereo playback
Listen to your television or CDs in surround sound
• Select Dolby Pro Logic , DTS NEO:6 or SFC to listen to stereo sound
from your television or CDs in surround. (Sound is output from all the
speakers.)
• Depending on the speaker settings and input signal (audio signal from
the disc being played), this may not be possible. (ápage 17)
Turn on.
or or
Supplied accessories
Please check and identify the supplied accessories.
Use the numbers indicated in parentheses when asking for replacement parts. (As of April 2005)
1 AC mains lead
1 FM indoor antenna
(RSA0007-L)
1 AM loop antenna
(RSA0037)
1 Antenna plug adapter
2 Batteries 1 Remote control
(EUR7722KN0)
Refer to the separate booklet,
“Remote Control Operation Guide”,
for remote control operation details.
For the United
Kingdom
(RJA0053-3X)
For Australia and
New Zealand
(K2CJ2DA00010)
For continental Europe
(K2CQ2CA00002)
For the United Kingdom
(K1YZ02000013)
For Australia and
New Zealand
(K2RC021B0002)

Produktspezifikationen

Marke: Panasonic
Kategorie: Empfänger
Modell: SA-XR55

Brauchst du Hilfe?

Wenn Sie Hilfe mit Panasonic SA-XR55 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Empfänger Panasonic

Panasonic

Panasonic SA-EX120 Bedienungsanleitung

27 Juni 2023
Panasonic

Panasonic SA-XR55 Bedienungsanleitung

8 Oktober 2022

Bedienungsanleitung Empfänger

Neueste Bedienungsanleitung für -Kategorien-

Rotel

Rotel RA‑1592MKII Bedienungsanleitung

16 Oktober 2024
Denon

Denon AVR-S900W Bedienungsanleitung

16 Oktober 2024
Pro-Ject

Pro-Ject Amp Box DS2 Bedienungsanleitung

15 Oktober 2024
AKG

AKG HP12U Bedienungsanleitung

15 Oktober 2024
Sennheiser

Sennheiser EM 9046 SU Bedienungsanleitung

14 Oktober 2024
Yamaha

Yamaha MusicCast RX-V481 Bedienungsanleitung

14 Oktober 2024
JL Audio

JL Audio VX600/6i Bedienungsanleitung

12 Oktober 2024
Pioneer

Pioneer SX-303RDS Bedienungsanleitung

10 Oktober 2024
Technics

Technics SA-160L Bedienungsanleitung

8 Oktober 2024
Avantree

Avantree Audiplex Bedienungsanleitung

7 Oktober 2024
