Seite 1/25
Panasonic Corporation
Web Site: http://panasonic.net
© Panasonic Corporation 2012
Operating Instructions
ợ䒌存㕲
Portable Stereo CD System
㎞ⶊ䨯ặ⡔ 杗䱟乃 CD
Model No.
0 ⛯⍛
RX-D53
RX-D48
CnEn Ar
RQT9725-G
L0712HH0
GC GS
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
ゃ宆「岑㚐ḋ␥Ɂ
ᶞ䟒ὁ㙤ỗ⾋偡⏰⫭濇孛Ḹ个敩孟㚐存㕲Ɂ
孛ὁ䬅㚐存㕲ṉ⡫Ḯ⍲⌦佧Ɂ
2
2
2
22
2
RQT9725
ENGLISH
ENGLISH
ENGLISH
ENGLISHENGLISH
Safety precautions
WARNING!
Unit
• To reduce the risk of fire, electric shock or product damage,
– Do not expose this unit to rain, moisture, dripping or splashing.
– Do not place objects filled with liquids, such as vases, on this unit.
– Use only the recommended accessories.
– Do not remove covers.
– Do not repair this unit by yourself. Refer servicing to qualified service
personnel.
CAUTION!
Unit
• To reduce the risk of fire, electric shock or product damage,
– Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Ensure this unit is well ventilated.
– Do not obstruct this unit’s ventilation openings with newspapers, tablecloths,
curtains, and similar items.
– Do not place sources of naked flames, such as lighted candles, on this unit.
• This unit is intended for use in tropical climates.
• Install this unit so that the AC mains lead can be unplugged from the socket
outlet immediately if any problem occurs.
• This unit may receive radio interference caused by mobile telephones during
use. If such interference occurs, please increase separation between this unit
and the mobile telephone.
• This unit utilizes a laser. Use of controls or adjustments or performance of
procedures other than those specified herein may result in hazardous radiation
exposure.
• Avoid using or placing this unit near sources of heat. Do not leave it in an
automobile exposed to direct sunlight for a long time with the doors and
windows closed as this may deform the cabinet.
• Avoid cuts, scratches, or poor connections in the AC mains lead, as they may
result in possible fire or electric shock hazard. Also, excessive bending, pulling
or splicing of the lead should be avoided.
• Do not unplug the AC mains lead by pulling on the lead. To do so may cause
premature failure or shock hazard.
• Do not operate this unit in a bathroom, as a potential shock hazard may result.
• When not in use, disconnect the AC mains lead from the household mains
socket.
Batteries
• If this unit is not used for a long period of time or is used only from an AC power
source, remove all the batteries to prevent potential damage due to possible
battery leakage.
• Insert so the poles (+ and –) match those in the unit and the remote control.
• Do not mix old and new batteries.
• Do not use different types of batteries at the same time.
• Do not break open or short-circuit the battery.
• Do not charge the alkaline or manganese battery.
• Do not use the battery if the cover has peeled off.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period
of time with doors and windows closed.
• Remove the battery if you do not use the unit or the remote control for a long
period of time. Keep in a cool, dark area.
• Danger of explosion if battery is incorrectly replaced. Replace only with the type
recommended by the manufacturer.
• When disposing the batteries, please contact your local authorities or dealer and
ask for the correct method of disposal.
Note on AC mains lead ( RX-D53 only)
(For Saudi Arabia and Kuwait only)
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differs according to the type of AC mains plug (figures A
and B). Confirm the AC mains plug fitted and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
Figure A Figure B
Fuse cover
2. Replace the fuse and close or attach the fuse cover.
Figure A
Fuse (5 ampere)
Figure B
Fuse (5 ampere)
These operating instructions are applicable for models RX-D53 and
RX-D48.
RX-D53 : indicates features applicable to RX-D53 only.
RX-D48 : indicates features applicable to RX-D48 only.
Your unit may not look exactly the same as illustrated. Unless otherwise
indicated, illustrations in these operating instructions are of RX-D53.
– If you see this symbol –
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct method of
disposal.
Inside of product
3
3
3
33
3
RQT9725
ENGLISH
ENGLISH
ENGLISH
ENGLISHENGLISH
Table of contents
Safety precautions ........................................................ 2
Note on AC mains lead ( RX-D53 only) ............................. 2
Supplied accessories .................................................... 3
Power sources ............................................................... 3
Remote control .............................................................. 3
Overview of controls ..................................................... 4
Disc ................................................................................. 5
Radio ............................................................................... 6
USB ( RX-D53 only) ............................................................ 6
Cassette tape ................................................................. 7
Clock and timers............................................................ 7
Sound effects ................................................................. 8
Music port ...................................................................... 8
Troubleshooting ............................................................ 8
Specifications ................................................................ 9
Maintenance ................................................................... 9
Power sources
Using the household mains socket
Connect the AC mains lead firmly to the unit and the household mains
socket.
To household
mains socket
AC mains lead
(included)
Note:
• The included AC mains lead is for use with this unit only. Do not use it with other
equipment.
• The unit is in the standby condition when the AC power supply cord is
connected. The primary circuit is always “live” as long as the power cord is
connected to an electrical outlet.
Using batteries (not included)
5678
1243
Inner row
Outer row
Press towards while
inserting the battery.
• Use only alkaline batteries.
• The unit cannot be powered by batteries if the AC mains lead is connected.
Disconnect the AC mains lead from the unit to operate on battery power.
• The remote control cannot turn the unit on when batteries are used.
When to change the batteries
When the battery indicator begins flashing, replace
all 8 of the batteries. It is also a good idea to
replace all the batteries before recording.
Note:
Before any function starts, the battery indicator may flash although the batteries
are not drained. The indicator will display its current status when the unit is
powered from the household mains socket by using the AC mains lead.
Memory back-up
When the power supply is interrupted, the current time, timer settings and radio
stations you have set are saved if you have inserted back-up batteries (not
included).
• Use either alkaline or manganese batteries.
• These batteries do not power the unit.
When to change the batteries
Bottom view
21
3
4
Outer row
Inner row
The batteries last about a year.
Connect the unit to AC power before replacing
the batteries.
Before connecting or disconnecting the AC mains
lead, press [ / , STOP/EJECT] to stop the tape 8 x
and press [TAPE/OFF] to turn the unit off. The
back-up batteries wear out faster if the cord is
disconnected with the power still on.
Remote control
Insert the batteries (not included) observing
the correct polarities (+, –).
Aim at the remote control signal sensor,
avoiding obstacles, at a maximum range of
7 m directly in front of the unit.
R6/LR6, AA
Rear view
Bottom view
Supplied accessories
Check and identify the supplied accessories.
1 x AC mains lead
RX-D53
For Saudi Arabia and Kuwait
RX-D53 RX-D48
For others
1 x Remote control
RX-D53 (N2QAYA000008)
RX-D48 (N2QAYA000009)
