Seite 1/16
NH-EH90JD1WA(NZ)
NH-EH10JD1WA(NZ)
NH-EH05JD1BV
NH-EH95JD1BV
NH-EH90JD1WM
NH-EH10JD1WM
NH-EH10JD1WS
NH-EH90JD1WM
NH-EH90JD1WA
NH-EH95JD1BV
NH-EH10JD1WM
NH-EH10JD1WS
NH-EH10JD1WA
NH-EH05JD1BV
User Manual
Heat Pump Tumble Dryer
(Household)
Model
Thank you very much for purchasing our products!
Specications
Rated voltage
Rated frequency
Rated input power
Refrigerant
Dimensions
Net weight
Rated drying
capacity
220 V- 240 V
50 Hz
598×654×841 (mm)
750 W
R134a(310g)
50 kg
10.0 kg 10.5 kg 9.0 kg 9.5 kg
Please read this manual carefully before using the product so that it can be used
correctly.
Please make sure to read the “Safety information” (pages 2~7) before using to
ensure safe use.
This manual is subject to technical changes without notice.
Please keep this manual properly.
This dryer contains reusable materials, so please provide support for proper
disposal or recycling upon end of life, so as to protect the environment.
Contents
Instructions for use
Maintenance and service
Use method
Safety information……………………………………………………………… 2
Name of parts…………………………………………………………………… 8
Accessories
Installation placement ………………………………………………………… 9
Handling/Stacking installation/Installation placement and product dimensions
Installation ……………………………………………………………………… 11
Drain hose connection
Post-installation inspection ………………………………………………… 12
Level adjustment/Installation conrmation/Post-installation test run
Description of the operation panel ………………………………………… 13
Pre-operation inspection …………………………………………………… 15
First-time use/Sorting clothes/Preparing clothes/Tips on clothes care/
If clothes shrink
If necessary
When the clothes drying eect is not good … …………………………… 26
Trouble shooting ……………………………………………………………… 28
Error codes…………………………30
Operation method…………………… 17
Instructions for use …………………………………………………………… 18
Drying rack
Program overview ……………………………………………… 19
Safety information
Warning Attention
May cause serious personal injury May cause personal injury and damage to articles
This symbol indicates prohibited
operations.
This symbol indicates operations
that must be observed.
Be sure to remove the power plug from the socket when not in
use!
This dryer may be damaged by a lightning strike in case of violation of the
requirement.
Keep away from sources of ignition such as lit candles, incense
and cigarette!
It may cause re or deformation.
During use
Please stop use immediately when the following situations occur.
Remove the power plug and contact Panasonic for inspection
and repair!
This dryer does not start up even after the power is turned on.
There is an abnormal noise when this dryer is running.
There is a burning smell.
Smoke, re and electric shock may occur.
No re
Maintenance and service …………………………………………………… 21
Condensed water box/Dryer case/Humidity sensor/
Dryer door gasket/Cooling air inlet cleaning/Upper lter screen/
Lower lter screen and heat exchanger
In order to prevent problems before they occur and ensure no injury or property damage
to users and others, the issues that must be observed in terms of safety are described as
follows:
Ignoring instructions with the below symbols may cause the following consequences.
The instructions required to be observed and understood as per the following symbols.
Warning
1 2
Please do not place this dryer in humid places such as
bathroom or position exposed to wind and rain!
Violation of the requirement may cause electric shock, re, failure and
deformation, etc.
Do not put clothes containing chemicals such as kerosene,
gasoline, light gasoline, thinner and alcohol or stained by such
chemicals!
Violation of the requirement may cause explosion or re.
Do not accumulate lint or cotton ock around this dryer.
Violation of the requirement may cause a re.
Do not spray water directly on parts of the dryer during
cleaning and maintenance!
Violation of the requirement may lead to short circuit and electric
leakage.
Prohibited Prohibited
Prohibited
Prohibited
Do not use
the product
in positions
subject to
water spray
During use Power supply · Electrical cord
To prevent injuries
Power supply · Electrical cord
Sprinkling is
prohibited
Do not disassemble, repair or modify
the dryer
body without
permission!
Violation of the requirement may lead tore, abnormal operation, then
injury.
Please consult Panasonic for repair.
Disassembly
is prohibited
Prevent kids from entering the drum, please absolutely
prohibit kids from climbing or peering inside the drum. It is
strictly forbidden to put living things into this dryer.
Dust and so on should be removed from the power plug regularly.
If dust and water scale accumulate on the plug, this will lead to the
degradation of the moisture-proof insulation function and may therefore
cause a re.
Please wipe with a dry cloth after removing the power plug.
Please separately use a single-phase two-pole grounded power
socket rated at a voltage of AC 220-240V and a current of 10A
or more!
If the power socket is shared with other electrical appliances, a re may
be caused due to heat.
The power plug must be completely inserted!
If the insertion is not complete, electric shock or heat may be caused.
Do not use damaged power cords or a loose socket.
Please avoid actions that may damage the power cord and
power plug (Do not cause damage; do not process; keep away from
thermal appliances; do not bend, twist, stretch, press with weight or
bundle excessively)
Continued use in a damaged state may result in electric shock, short
circuit, or re.
Please consult Panasonic for repair of power cord or plug.
Do not touch the power plug with wet hands!
Violation of the requirement may cause electric shock.
Always remove the power plug from the socket when
maintaining, cleaning or moving this dryer!
Violation of the requirement may cause electric shock or injury.
Wet hands
prohibited
The plug
must be
removed
WarningWarning
3 4
