OWNER'S MANUAL
PT3215SH
LED TV
Please read this manual carefully before TV operation.
Retain it for future reference.
Dolby, Dolby Audio and the double-D symbol are trademarks
of Dolby Laboratories.
High Voltage
Do not open
Risk of electronic shock, do not open.Do not
attempt to service this product yourself as
opening or removing covers may expose you
to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
CAUTION
Important Safety Instructions and Maintenance
Important Safety Instructions
If the following problems occur:
Turn off the TV set and unplug the AC power
cord immediately if any of the following
problems occur. Ask your dealer or service
centre to have it checked by qualified service
personnel.
When:
- AC power cord is damaged.
- Poor fitting of AC power outlet.
- TV set is damaged by being dropped, hit or
having something thrown at it.
- Any liquid or solid object falls through
openings in the cabinet.
The screen and cabinet get warm when the
TV is in use. This is not a malfunction.In case
of smoke, strange noise or strange smell
from the unit:
· Turn off the power switch immediately;
· Disconnect the power plug from the power
outlet;
· Contact your dealer or service
centre. Never attempt to make
repairs yourself
because this could
be dangerous.
Do not overload wall outlets, extension cords or adaptors beyond their capacity,
this can result in fire or electrical shock.Power-supply cords should be
routed so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at plug
end, adaptors and the point where they exit from the appliance. The mains
plug is used as the disconnect device. It shall remain readily accessible and
should not be obstructed during intended use. Make sure to plug the power
cord in until it is firmly inserted. When removing the power cord, make sure to hold the power
plug when pulling the plug from the outlet, do not pull the plug out by the wire. NEVER touch the
plug or power cord with wet hands. To disconnect the apparatus from the mains power, the plug
must be pulled out from the mains socket, therefore make sure the mains plug is always easily
accessible.
To reduce the risk of fire or
electric shock, do not expose
this product to rain or moisture.
The apparatus shall not be
exposed to dripping or splashing and
no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short-circuit
parts that could result in a fire or electric
shock. Never spill liquid of any kind on the
set. Use special caution in households where
children are present. The apparatus is not
suitable for children under 3-year to operate.
1
To avoid the fire, no naked flame source, such as lighted candles, should be placed
on the apparatus.
Do not push or scratch the front filter, or place any objects on top of the TV set. The image may
be uneven or the screen may be damaged.
Important Safety Instructions and Maintenance
Important Safety Instructions
2
An outside antenna
system should not
be located in the
vicinity of overhead
power lines or other
electric light or power
circuits, or where it can
fall into such power
lines or circuits. When installing an outside
antenna system, extreme care should be
taken to keep from touching such power
lines or circuits as contact with them might
be fatal.Ensuring the television is not
overhanging the edge of the supporting
furniture.
When not in use
If you will not be using the TV set for several
days, the TV set should be disconnected from
the AC mains for environmental and safety
reasons. As the TV set is not disconnected from
the AC power when the TV is turned off at the
standby switch, pull the plug from the AC power
outlet to disconnect the TV completely. However,
some TV sets may have features that require the
TV set to be left in standby to function correctly.
In the case of lightning, unplug the TV set from
the outlet immediately. Never touch the antenna
wire during lightning.
Do not pull the plug out by the wire; Never
touch the plug with wet hands.
Excessive from earphones and volume
headphones can cause hearing loss.
Installation
The ventilation should not be impeded by covering the ventilation
opening with items, such as newspapers, tablecloths, curtains, etc.
At least 10 cm space should be left around the apparatus for sufficient
ventilation.
The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat. Place the apparatus in
such a position that the screen
is not exposed to direct sunlight. It is best to have soft indirect
lighting while watching and avoid completely dark environments
and reflection from the screen as these may cause eye fatigue.
Keep the TV set away from any equipment emitting
electromagnetic radiation.
Do not place the set on an unstable cart, stand, table or shelf. The
set may fall, causing serious personal injury as well as damage to
the product. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus. An
appliance and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
Do not place this apparatus near water, for example, near a bath
tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or
a swimming pool; and the like;
solvent
solvent
solvent
solventsolvent thinner
thinner
thinner
thinnerthinner
solvent thinner
Important Safety Instructions and Maintenance
3
Installation
Move
When the TV being moved in from cold place, it needs some right time for dew
inside unit evaporating fully before turn on the unit;
To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
LED Screen
Although the LED screen is made with high precision technology and 99.99% or more of the
pixels are effective, black dots may appear or bright points of light (red, blue or green) may
appear constantly on the LED screen. This is a structural property of the LED screen and is not
a malfunction.If the surface of the LED panel cracks, do not touch it until you have unplugged
the AC power cord. Otherwise electric shock may result. Do not throw anything at the TV set.
The LED panel may break from the impact and cause serious injury.
Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen.
Do not display still images and partially still images on the LED panel for more than 2 hours as it
can cause screen image retention. This image retention is also known as "screen burn". To
avoid such image retention, reduce the degree of brightness and contrast of the screen when
displaying a still image.
Watching the LED TV in 4:3 format for a long period of time may leave traces of borders
displayed on the left, right and centre of the screen caused by the difference of light emission on
the screen. Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
Displaying still images from Video games and PC for longer than a certain period of time may
produce partial after-images. To prevent this effect, reduce the 'brightness' and 'contrast' when
displaying still images.
Cleaning
Cleaning and handling the screen surface
and cabinet. Disconnect the unit from the AC
outlet before cleaning. To remove dust, wipe
gently with a soft, lint free cloth. If required
use a slightly damp cloth.
MAINS PLUG
Wipe the mains plug with a dry cloth at
regular intervals. Moisture and dust may lead
to fire or electrical shock.
Use care not to subject the TV's surfaces to detergent. (A liquid inside
the TV could lead to product failure, fire or electrical shock.)
Use care not to subject surfaces to bug repellent, solvent, thinner, or
other volatile substances as this may deteriorate the surface and finish
of the cabinet.
4
Important Information
If a television is not positioned in a sufficiently stable location, it can be potentially hazardous
due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions
such as:
• Using cabinets or stands recommended by the manufacturer os the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge os the supporting furniture.
• Not placing the television on tall furniture (for example, cupboards or bookcases) without anchoring
both the furniture and the television to a suitable support.
• Not standing the televisions on cloth or other materials placed between the television and supporting
furniture.
• Educating children about the dangers of climbing on furniture to reach the television or its controls.
• Keep small accessories out of reach of children so they are not mistakenly swallowed.
Accessories
Please make sure the following items are included with your LED TV. If any items are missing,
contact your dealer.
Remote Control
Owner’s
Instructions
5
HOME
0
789
4 5 6
1 2 3
Q.MEN U
MENU
VOL
RECA LL
BACK/
GUIDE
CH
TEXT
SUBT I TLE
INFO
INDE X HOLD MIX
SIZE T IME
REVEAL C ANC EL
SUBCODE
Pg Dn
ENTER
/LIST
6
Input terminals used for external equipment connection
l TV adopts 32" TFT LED display screen
l Zero X radiation complies to green environment protection requirement
l Connect to computer directly to realize TV/monitor combo.
l USB 2.0
l 16:9 wide screen
l Auto tuning and fine tuning
l HDMI input
l Component Compatible (480i; 480P; 576i; 576P; 720P; 1080i; 1080P)
l Programmable sleep timer
l Wide range voltage input
l No-signal automatic power off
Introduction
Features
Basic Functions
1 x Antenna jack
1 x Computer PC-RGB input
1 x AV input ( The multiplexing of AV and COMPONENT)
1 x COMPONENT input
1 x SPDIF output
1 x RJ-45 NET Input
1 x Headphone output
1 x USB input
2 x HDMI inputs
7
Digital: DVB-T
Analog: PAL: BG, I, DK,
SECAM: BG, D/K
PAL/NTSC/SECAM
NOTES:
• Design and specifications are subject to change without notice.
• Weight and Dimension shown are approximate.
1366x768
TV receive system
TV with stand
TV without stand
TV with stand
TV without stand
≤1W
Standby comsumption
Weight
(Net weight)
Dimensions
(LxWxH)
Model
LED panel resolution
≥5 X2W
Speaker output power
110-240V~, 50/60HzPower supply
Frequency range
Video in
Power consumption
DC 3V
(Two AAA size batteries)
Controller power
o o
0 C-40 C
Work temperature
Display size
Antenna input 75 ohms, unbalanced
32" Diagonal (max.)
PT3215SH
65W
Analog: Antenna: 46.25MHz-855.25MHz
Digital DVB-T:5-12,21-69：
Introduction
Specifications
4.3kg
4.23kg
731.8×184.5×475.2mm
731.8×87.3×435.1mm
9
You can connect the TV with video devices such as DVD/VCD player, VCR and video camera to enjoy the high
quality picture.
Note: The product and illustrations in this user's manual is only for explanation purposes
and may vary depending on model.
General Description
Overview of back panel
Blu-ray disc player
PC (HDMI-output)
DVD player
Camcorder
DVD player
VGA
USB
10
General Description
Overview of front panel
The buttons on the lower-left panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
↓
→
←
Centre
1
2
3
4
5
6
↑
Press this button on the control panel one time as CONFIRM at any menu.
Press and hold this button to display FUNCTION menu at any menu.
Press and hold this button to turn on TV when it is in standby mode.
Up Push one time: Use to select menu item if menu on TV. Use to go to last channel
when watching TV.
Down Push one time: Use to select the next menu item if menu on TV. Use to go to next
channel when watching TV. Push and hold this button to return to the last page.
Left Push one time: Use to select the left menu item if menu on TV. Use to decrease
volume when watching TV.
Right Push one time: Use to select the right menu item if menu on TV. Use to increase
volume when watching TV.
Joystick
2
3
1
Directly in front the TV operation
schematic diagram：
4 5
Remote control sensor / Power indicator
11
Loading batteries:
1) Remove the lid of the battery compartment.
2) Insert 2 size AAA batteries with polarities as indicated inside the compartment.
3) Replace the lid.
Note:
1) A loading of batteries should be last one year under normal use.
2) If you don't intend to use the remote control for a long period of time, remove batteries
to avoid damage due to leakage.
3) Do not mix old and new batteries or different types.
4) Do not throw batteries into fire or water.
5) The batteries (battery pack or batteries installed) should not be exposed to excessive
heat such as sunshine, fire or the like.
General Description
Overview of Remote Control
HOME
0
789
4 5 6
1 2 3
Q.MENU
MENU
VOL
RECALL
BACK/
GUIDE
CH
TEXT
SUBTITLE
INFO
INDEX HOLD MIX
SIZE TIME
REVEAL CANCEL
SUBCODE
Pg Dn
ENTER
/LIS T
Ž
’
“ ”
•
Œ
‘
12
General Description
Overview of Remote Control
1. : Turn the TV on and off.POWER
2. : This button is used to switch among different INPUT
sources, Select a source and press ENTER button to
confirm.
3. : Directly select channel with digital Digital Buttons(0-9)
buttons.
4. Switch to the previous program. RECALL:
5. YouTube: If network connects, press this key to view
YouTube directly.
6. : Display the program information. INFO
7. In DTV source, the button is used for subtitleSUBTITLE:
language.
In USB source, the button is used to change subtitle.
8. Press it to go to App home page. HOME:
9. : If network connects, press this key to view NETFLIX
NETFLIX directly.
10. : Display the main menu or exit the current menu.MENU
11. : Press this key to go to quick menu. Q.MENU
12. ENTER/LIST: Press to show channel list and favorite list
on screen.
13. : Use to select on-screen menu Arrow buttons pqtu
items and change menu values.
14. / I Display menu GUIDE in DTV mode. BACK GU DE:
Return function in app.
15. : Exit the menu. EXIT
16. It's used as it's show the EPG COLOR BUTTONS:
or Program Edit menu.
17. : Press this button to cut off the sound of the TV MUTE
set temporarily, press again to resume.
18. button In ATV source, the button is /AUDIO LANG :
used to set NICAM sound system. In DTV source, the
button is used to set the audio language.
19. - Press these buttons to adjust the volume. VOL+/ :
20. Press these buttons to change channel CH˄/˅:
upward or downward.
HOME
0
789
4 5 6
1 2 3
Q.MENU
MENU
VOL
RECALL
BACK/
GUIDE
CH
TEXT
SUBTITLE
INFO
INDEX HOLD MIX
SIZE TIME
REVEAL CANCEL
SUBCODE
Pg Dn
ENTER
/LIS T
Ž
’
“ ”
•
Œ
‘
13
General Description
Overview of Remote Control
21. DIGITAL MEDIA PLAYER CONTROL BUTTON:
Include play/pause, stop, previous, next, backward,
forward is used in USB mode .
Please refer to relevnat instructions in the section of
multimed player.
22. Press INDEX button, then index page displays.INDEX:
23. Teletext buttons for mix function, please referMIX ( ):
to TTX description page. It is also used for recording
function when TV is on DTV mode, please refer to PVR
page.
24. Press HOLD button to toggle Hold function on HOLD:
or off. When Hold is switched on, the page acquisition
is stopped. When Hold is switched off, the page
acquisition is started.
25. TEXT: Press TEXT button to enter or exit teletext mode.
26. SIZE: Press SIZE button one time to display the upper
half of the screen in double height, press the SIZE button
two times to display the lower half of the screen in double
height, press three times to display the full screen in
normal size.
27. Pressing this button will reveal any hidden REVEAL:
data (answers to quizzes for example). Press the
REVEAL button again to return to normal screen.
28. : This button is used to show the time of the teletext. TIME
29 Subcode mode gives the possibility to select . : SUBCODE
certain subcode pages of a Teletext page. Entry of digits
within the range 0...9 for current subcode entry. If the
digit completes the entry, a page request is started.
Press CH and CH buttons to change the ˄ ˅
subcode pages.
CANCEL: 30. The CANCEL button will exit from any Teletext
on the display. Press CANCEL button again to exit Teletext
and return to live TV broadcast.
HOME
0
789
4 5 6
1 2 3
Q.MENU
MENU
VOL
RECALL
BACK/
GUIDE
CH
TEXT
SUBTITLE
INFO
INDEX HOLD MIX
SIZE TIME
REVEAL CANCEL
SUBCODE
Pg Dn
ENTER
/LIS T
Ž
’
“ ”
•
Œ
‘
14
General Description
Installing Batteries in the Remote Control
Installing Batteries
External Connection
Antenna connection
Antenna input impedance of this unit is 75ohm. VHF/UHF 75ohm coaxial cable can be connected
to the antenna jack directly, if the antenna cable is 300ohm parallel flat feeder cable, you need to
use the 300ohm/75ohm converter to connect the antenna cable to the antenna jack. For details
Please refer to the following drawing.
75ohm coaxial cable
Antenna cable
Antennas with 300 flat twins LeadsWAntennas with 75 Round LeadsW
Use a 75ohm - 300ohm converter
300ohm coaxial cable
Antenna feeder
1Open the battery compartment
cover on the back side.
2
Insert two 1.5V AAA size batteries
in correct polarity. Don´t mix old or
used batteries with new ones.
3Point the remote towards the remote control
sensor of the TV and use it within 8 meters.
Put the used batteries into the recycling bin
since they can negatively affect the
environment.
Closed the cover.
1 2 3
15
These instructions assume that you have already connected your TV to an antenna or a cable TV
system. Skip step 1 if you have not yet connected to an antenna or a cable system.
Follow the instructions in Viewing a VCR or Camcorder Tape to view your VCR tape.
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
1. Unplug the cable or antenna from the back of the TV.
2. Connect the cable or antenna to the ANT IN terminal on the back of the VCR.
3. Connect an RF Cable between the ANT OUT terminal on the VCR and the ANT IN terminal on the
TV.
4. Connect a Component Cable between the COMPONENT [Y, Pb, Pr] jacks on the DVD player and
YPbPr jack on the TV.
5. Connect Audio Cables between the AUDIO OUT jacks on the VCR and the AUDIO L and
AUDIO R jacks on the TV.
Note:
1. Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2. When connecting an external device, match the color of the connection terminal to the
cable.
External Connection
Connecting VCR
VCR Rear Panel
TV Rear Panel
White
Red
Red
White
ANT ANT OUT S-VIDEO AUDIO OUT
Red
Blue
Green
VIDEO OUT
2
1
3Audio Cable (Not supplied)
YPbPr cable( supplied) Not
RF Cable (Not supplied)
1 2 3
Green
Blue
Red
VGA
16
The rear panel jacks on your TV make it easy to connect a camcorder to your TV. They allow you
to view the camcorder tapes without using a VCR.
Each Camcorder has a different back panel configuration.
When connecting a Camcorder or DVD, match the color of the connection terminal to the cable.
1. Connect a Video Cable between the AV VIDEO in jacks on the TV and the VIDEO OUT jack
on the camcorder.
2. Connect Audio Cables between the AUDIO L and AUDIO R jacks on the TV and the AUDIO
OUT jacks on the camcorder.
3. Connect a Video Cable between the AV VIDEO IN jacks on the TV and the VIDEO OUT jack
on the DVD.
4. Connect Audio Cables between the component IN AUDIO L and R jacks on the TV and the
AUDIO OUT jack on the DVD.
Notes:
1. Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2. When connecting an external device, match the color of the connection terminal to the
cable.
External Connection
Connecting a Camcorder
Video Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Camcorder
Green
Red
White
Red
White
Green
17
This connection can only be made if there is a HDMI Output connector on the external device.
HDMI Cable (Not supplied)
What is HDMI?
HDMI, or high-definition multimedia interface, is a next-generation interface that enables the
transmission of digital audio and video signals using a single cable without compression.
Multimedia interface is a more accurate name for it especially because it allows multiple channels
of digital audio (5.1 channels).
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP
(High Bandwidth Digital Copy Protection) coding feature installed, and supports multi-channel digital
audio.
Each DVD player/STB has a different back panel configuration.
Connect an HDMI Cable between the HDMI1, HDMI2 connector on the TV and the HDMI connector
on the DVD player/Set-Top Box.
Notes:
1.Whenever you connect an external device to your TV, make sure that power on the unit
is turned off.
2.When connecting an external device, match the color of the connection terminal to the
cable.
External Connection
Connecting DVD Player/Set-Top Box via HDMI
VGA
18
External Connection
Connecting Digital Audio System
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
5.1 CH audio is possible when the TV is connected to an external device supporting 5.1 CH.
Connect an SPDIF Cable between the SPDIF jacks on the TV and the Digital Audio Input jacks
on the Digital Audio System. When a Digital Audio System is connected to the SPDIF terminal:
Decrease the gain (volume) of the TV, and adjust the volume level with the Digital Audio System's
volume control.
Digital Audio System
(Black)
TV Rear Panel
SPDIF
VGA
19
Resolution
Input
Component
60Hz
60Hz
50Hz/60Hz
480i
480p
720p
50Hz/60Hz1080i
HDMI 50Hz/60Hz
50Hz/60Hz
480p
720p
60Hz
1080i
Vertical
Frequency
50Hz/60Hz1080p
50Hz/60Hz1080p
External Connection
Connecting PC
Supporing Signals
PC Video Cable (Not supplied)
PC
Each PC has a different back panel configuration.
Connect a PC Video Cable between PC Video IN jack on the TV and the Video Out jack on your
computer.
You should set PC software before you connect a PC to your TV (please refer to "PC Display''
settings)
Notes:
1. Whenever you connect an external device to your TV, make sure that power on the unit is
turned off.
2. When connecting an external device, match the color of the connection terminal to the
cable.
VGA
Input Mode
Digital
Analog
DVB-T
CVBS
PAL BG I DK, SECAM BG DK
Resolution
Input
VGA 60Hz640x480
PC/VGA
SVGA
XGA
60Hz
60Hz
800X600
1024X768
Vertical
Frequency
SXGA 60Hz1280X1024
60Hz1360X768
1 Input Setup
Press key on the remote control to enter "INPUT SOURCE" menu. INPUT
Use / key to select a input source and press key to confirm.t u ENTER
2 Channels Selection
There are four ways to select channel:
1) Using number keys and “ ” keys on the remote control to select channel directly., ENTER
To select channel 90, press .
When you use the number buttons, you can directly select channels that were either erased or
not memorized.
2) Using key on the remote control or on your TV to select channel.CH ˄ / ˅
When you press the key, the TV changes channels in sequence. You will see all the CH ˄ / ˅
channels that the TV has memorized.
You will not see channels that were either erased or not memorized.
3) Press key to return to previous channel, press it again to return to current channel.RECALL
To quickly switch between two channels that are far apart, tune to one channel, then use the
number keys to select the second channel. Then use the RECALL button to quickly alternate
between them.
is not activated if no channel has been changed after TV turning on.RECALL
4 Select channels from "Channels List" or "Favorite List".)
Press ” key to choose from "Channel List" menu.“ENTER
3 Volume Adjustment and Mute Setup
Volume adjustment
Press key on the remote control or the TV to display "Volume" menu, adjust the volume -VOL+ /
of TV between 0 to 100 by using key: -VOL+ /
9 0 ENTE R
20
Basic Operation
Menu Operation
Input Source
Input Source
21
4 Current Channel Information
Press “INFO” key on the remote control to view current channel information, the indications of channel
information are listed in the following table.
Press “EXIT” key on the remote control to exit this OSD.
5 EPG Menu
Press BACK/GUIDE key to enter "EPG" menu, the first line displays current channel number, channel
name, event title and current time.
The following line displays all programs which will be displayed in this channel, press ▲/ key to select q
the program you desired, then press “ENTER” key to enter this program to watch.
Reminder use “Reminder”(ENTER) button to reserve programs. If the TV is in DTV mode, it will
automatically turn to the reserved program at the scheduled time. Use “Schedule” (BLUE) button to
look up the reminder list.
Press EXIT key on the remote control to exit this OSD.
00:00 01/01/1970
( To increase the volume, press key;VOL +
( To decrease the volume, press key;VOL -
Mute
Press “ and the sound cuts off. The MUTE icon will appear in the lower-left corner of the MUTE”
screen.
To resume sound, press the “ ” button again, or simply press the VOL key.MUTE +
ENTER
Reminder
Basic Operation
Menu Operation
Picture Mode
Comtrast 70
Brightness
Color
Sharpness
Tint
Backlight
Color Temperature
50
70
0
100
20
22
1. Press key to display the main menu on the screen.MENU
2. Press / key to select "Picture" option. p q
3. Press key to enter "Picture" submenu. u
Picture Mode
Your TV has four picture settings (Sports, Normal, Mild, Save, User)
that are preset at the factory. Only "User" mode can be set to your
preference by adjusting particular items such as Contrast, Brightness,
Color, Sharpness.
1. Press / key to select "Picture Mode" option. p q
2. Press / key to select one picture mode.p q
User settings for PICTURE
(Contrast, Brightness, Color, Sharpness, Tint)
Your set has several settings which allow you to control picture quality.
1. Press / key to select a particular item. ▲ ▼
2. Press / key to decrease or increase the value of a particulart u
item.
Note: The adjusted values are stored according to the selected
particular item.
Backlight
You can Change the brightness of the entire screen according to your preference.
1. Press / key to select "Backlight" option. p q
2. Press / key to increace or decreace the backlight value.t u
Color Temperature
You can change the color of the entire screen according to your preference.
1. Press / key to select "Color Temperature" option. p q
2. Press / key to select one color temp.p q
Contrast: Adjusts the lightness and darkness between objects and the background.
Brightness: Adjusts the brightness of the picture.
Color: Adjusts the colors, making them lighter or darker.
Sharpness: Adjusts the outline of objects to either sharpen them or make them
more dull.
Tint: Adjusts the Tint of the picture.
Backlight: Adjusts the brightness of the whole screen.
Cool: Makes whites bluish.
Standard: Makes whites nature
Warm: Makes whites reddish.
Sound
Function
Time
Option
Lock
Channel
Menu system instruction
Sound Mode
Balance
AVL
Surround Sound
AD Swich
Digital Audio Output
Audio Language
0
1. Press key to display the main menu on the screen.MENU
2. Press / key to select "Sound" option.p q
3. Press key to enter "Sound" submenu. u
Sound Mode
You can select the type of the special sound effect to
be used when watching a given broadcast.
Your TV has five sound settings (“Standard”, “Music”,
“Movie”, “Sports”, “User”) that are preset at the factory.
1. Press / key to select "Sound Mode" option. p q
2. Press / key to select one sound mode.p q
23
Equalizer
Set sound equalizer mode.
Balance
If the volumes of the left speaker and the right speaker are not the same, you can adjust the
"Balance" to suit your personal preference.
1. Press / key to select "Balance" option.p q
2. Press / key to decrease or increase the value of the item. t u
AVL
Each broadcasting station has its own signal conditions, and it is inconvenient to adjust the volume
every time the channel is changed. “AVL” automatically adjusts the volume of the desired channel
by lowering the sound output when the modulation signal is high or by raising the sound output
when the modulation signal is low.
1. Press / key to select “AVL” option. p q
2. Press / key to select “On” or “Off”.p q
Surround sound
This is used to turn on surround sound to gain better sound effect.
1. Press / key to select "Surround sound” option. p q
2. Press / key to select “Surround” or “Off”.p q
AD Switch
p q uPress / button to select AD Switch, then press Enter or button to enter sub-menu.
In it you can turn the AD Switch on or off and set the volume ratio in DTV mode.
Digital Audio Output
This is used to . set digital audio output
1. Press / key to select "Digital Audio Output” option. p q
2. Press / key to select “Auto” or “PCM” in DTV or HDMI mode. .p q
Audio Language
You can set the first and secondary language for audio in DTV mode.
l Standard: Selects the normal sound mode.
l Music: Provides clear and live sound for music.
l Movie: Provides live and full sound for movies.
l Sports: Emphasizes bass over other sounds.
l User: Selects your custom sound settings.
Menu system instruction
Sound
DAP
HDMI-ARC
Audio Type
Equalizer
24
1. Press MENU key to display the main menu on the screen.
2. Press key to select “Function” option. p q/
3. Press key to enter “Function” submenu. u
Noise Reduction
Press key to select the Noise Reduction mode. p q/
You can select the right mode to match the pictures.
MPEG Noise Reduction
Press key to select the mode: off / low / middle / high. t u/
The picture will be better when it is in “high” mode.
Aspect Ratio
p q1. Press / key to select “Aspect Ratio” option.
2. Press key to change the size of the picture on the size of the p q/
picture on the screen.
Menu system instruction
Sound
Function
HDMI ARC
Turn on or turn off the HDMI ARC function.
DAP
This is used to set DAP.
1. Press / key to select "DAP” option. p q
2. Press key to enter “DAP” submenu.u
Audio Type
This used to set audio type
1.Press / key to select "Audio Type" option.p q
2.Press key to select audio type.u
DAP
DAP Enable
DAP Mode
Surround Virtualizer
Dialog Enhancer
Auto Volume Control
On
User
Off
Off
Off
PVR File System
Select Disk
Time Shift Size
Format
Speed Check
PVR File System
1. Press / key to select “PVR File System” option. p q
2. Press or key to enter submenu in DTV mode.ENTER u
Connect the USB disk to the standard USB port before use PVR.
Select Disk: Press ” button to enter submenu and press choose the disk for PVR.ENTER “ “ ” to t u/
Select Disk
DISK 1
Noise Reduction
MPEG Noise Reduction
Aspect Ratio
PVR File Sytem
HDMI CEC
Netflix Deactive
Netflix ESN
Netflix Version
25
PVR File System: Press “ ” button to check if the disk is adapt to PVR.ENTER
USB: Display if the USB Disk is adapt to PVR.
Format Start: Press “ ” button to enter format submenu. ENTER
Speed Check: Display the disk writing/reading speed.
Time Shift Size: Display the buffer used for PVR.
It’s suggested use the disk that speed is up than 4500KB/S.
Warning:
1. The disk must be formatted when first used for PVR, so backup the original data in the disk.
It`s suggested use a special disk for PVR. Don’t modify the PVR file in PC.
2. All the time is not precise, just for reference.
Time Shift Size
Size 512MB
Menu system instruction
Function
PVR Menu
When the DTV channel has signal, press “ ”key to go to●
the PVR main menu.
1.P ress / key to select “Start Record”. If the storage ▲ ▼
device is ready, press “ ” key to start record. ENTER
The recording menus will disappear in 5 seconds, press “EXIT” key to recall them out.
When recording, press “ ” key again, then you can choose to stop recording or continue:●
2.Press / key to select "Recorded Files". If the storage device is ready, press “ ” key to ▲ ▼ ENTER
check the record list.
1) Press / key to select record file.p q
2) Press “ ” or key to play the selected record file.ENTER
3) Press "Red" key to delete the selected file.
4) When recorded files are playing, press button to to fast backward or forward.
Yes
Are you sure you want to Stop PVR?
No
CH 9 Nine Digital
00:04 0:00:45
PVR Options
Start Record
Recorded Files
Schedule Recording
26
3. Press / key to select "Schedule Recording".▲ ▼
In the Schedule Recording menu, you can see the record task list menu.
Press key to select one test.“ ”ENTER
1) Press "Red" key to delete the task.
2) Press "Yellow" key to Edit the task.
3) Press "Blue"key to add a new task directly.
Exit
Program Title Size Date
Delete
Recorded Files
Total:3GB HD 0h 31m
1h 45mSD
5.1_Globo_HD_201091_215035.st
01/09/2010
Globo HD
00:00
MENU
Menu system instruction
Function
Delete Edit New Return
Schedule Recording 21:00 Total:3GB
Sun Mon Tue Wed Thurs Fir Sat Date
Wed, 1 Sep. 2010
HD 0h 31m
1h 45mSD
22
29
05
12
24
31
07
14
27
03
10
17
23
30
06
13
26
02
09
16
25
01
08
15
28
04
11
18
MENU
When the Scheduled record, TV remains silent and black screen, then press the power button to
turn on the TV.
Note: The recording time can not overlap, otherwise the previous record programs will be overwritten.
4. In DTV channel, press “ ” key to pause, press it again to resume playback.
This is the “Time Shift”. During the suspension the image are temporarily stored in the disk, so
programs will not miss the suspension period, the length of time may be suspended by the size
of the disk buffer space constraints.
This feature supports fast forward and rewind function. Press “ ” key to go backward or for
ward.
CH 9 Nine Digital
00:04 0:00:45
CH 9 Nine Digital
00:04 0:00:45
27
5. In EPG menu, press "Red" key to go to manual record mode. Press Left/Right key to choose the
manual record mode, press / key to select the Start/End time of the manual record. ▲ ▼
Channel List Program List
5.1 Globo HD
Add Record
5.1 Globo HD
Minute 2
Hour 0
Month Jan.
Date 1
End Time
Minute 10
Hour 19
Month Aug.
Date 9
Mode Once
BACK OKENTER
BACK
01:05-02:10 Program do jo
Info Record
INFO
ReminderENTERSchedule
Menu system instruction
Function
HDMI CEC
Enable link
Auto Power On
Auto Standby
On
Off
Off
HDMI CEC
1. Press / key to select “HDMI CEC” option.p q
2. Press “ ” or key to enter “HDMI CEC” submenu.ENTER u
Enable Link: Press / to turn on/off the link setup.t u
Auto Power On: When this option is “On” and the TV is in
standby mode. To turn on the DVD can also turn the TV at
the same time.
Auto Standby: When this Option is “On” and the TV is on,
to turn off TV can also turn the DVD into standby mode.
Netflix Deactive
1. Press “ / " key to select “Netflix Deactive" option.p q
2. Press “ ” or “ " key to confirm.uENTER
3. Press "Yes" to confirm again, the Netflix will be activated.
Netflix ESN
Display the Netflix Esn information.
Netflix Version
Display the Netflix version.
Return
MENU
28
Menu system instruction
Off Time
On Time
Sleep Timer
Auto Sleep
Auto Sync
Clock --:--
Time Zone
1. Press key to display the main menu on the screen.MENU
2. Press / key to select "Time" option.p q
3. Press key to enter "Time" submenu. u
Off Time
In "Off Time” item, press button or button to enter the submenu, uENTER
set the day & time to turn off the TV set.
On Time
In "On Time” item, press button or button to enter the submenu, uENTER
set the time to turn on the TV set, when the TV set is in the standby
mode. You can also choose which day to control you TV set in a week.
Sleep Timer
1. Press / key to select "Sleep Timer" option.p q
2. Press / key repeatedly until the desired time appears (Off, 10mins, 20mins, 30mins, 60mins, p q
90mins, 120mins, 180mins, 240mins).
Notes: The sleep timer you have set will be cancelled when the TV turns off or if a power failure
occurs.
Notes: When the time is less than 60 seconds, remind information will be displayed on the screen.
Press any key button to cancel timer function.
Auto Sleep
Press / key to select whether to open the No signal Power off features. If this function is opened, p q
the TV will power off when there is no signal.
Auto Sync
You can modify the time of your TV set in Manual mode. In Auto mode, the “clock” is decided by the
DTV signal.
Clock --:--
When Auto Sync is on, the clock is got from DTV streams; Set the clock when Auto Sync is off.
Time Zone
You can choose it to modify your time zone in the TV set.
1. Press / key to select "Time Zone" option.p q
2. Press / key to select time zone.p q
Time
29
Menu system instruction
Option
1. Press key to display the main menu on the MENU
screen.
2. Press / key to select "Option" option. p q
3. Press key to enter “Option" submenu.u
OSD Language
OSD Language1. Press / key to select “ " option. p q
2. Press or key to select a proper language ENTER u
for OSD
OSD Time
Set the preferred amount of time for the OSD to be
displayed on the screen.
PC Adjust
This option is only used in VGA.
1. Press ▲/▼ key to select “PC Adjust” option.
2. Press ENTER key to enter the“PC Adjust”submenu.
Reset
1.Press “ / " key to select "Reset" option.p q
2.Press “ " or “ " key to confirm.uENTER
3.Press "Yes" to confirm again, TV will turn off auto maticly and change all setting to factory setting.
Network configuration
Please refer to "Network setting"behind.
Software Update
When the TV need to be updated, please copy the new software to a USB storage and inset the
USB storage to TV, then operating by following steps.
1.Press “ / " key to select "Software Update" option.p q
2.Press “ ” or “ " key to confirm.uENTER
3.Press "Yes" to confirm again, the TV will update by USB, Please wait a few minutes and don't
turn off the power, it will turn off auto maticly when updating is finish.
Internet Update Check
This can update TV through internet.
Info
Display the software information and lan mac address.
View End-User License
View End-User license information.
Network Update information
1.Press key to select "Network Update information". p q/
2.Press key to confirm u
3.Press "YES" to confirm again, the tv will start to update by network,
please wait a few minutes and don't turn off the power, it will turn off
automaticly when updating finish.
OSD Language
OSD Time
Reset
Network Configuration
Software Upadate
Internet Update Check
View End-User License
Network Update information
Subtitle
HBBTV
Info
PC Adjust
30
Menu system instruction
Option
Lock System
Set Password
Parental Guidance
The "Lock" feature automatically locks out programming that is deemed inappropriate for children.
The user must first enter a Password before any of the lock restrictions can be set up or changed.
1 Lock. Press / key to select " " option. p q
2. Press or key to enter " " submenu, "Enter Password" menu will appear, enter your KuOLock
4-digit password to enter " ” submenu .Lock (the default and universal password is 1980)
Lock System
Set the Lock function on or off.
Lock System1. Press / key to select " " option. p q
2. Press /p q key to select "On" or "Off".
Set Password
Password1. Press / key to select "Set " option. p q
2. Enter your 4-digit password to enter "Set Password" submenu.
Choose any 4-digits for your new password and enter them. As soon
as the 4 digits are entered, the cursor skipped to “Confirm Password”
item, re-enter the same 4 digits, and your new password has been
memorized.
When the programs is locked, you can also press the menu key, Info
key and so on. Then you can press / key to call back the t u
input-password window.
Parental Guidance
This option only used in DTV mode.
1. Press / key to select “Parental Guidance" option. p q
2.Prsee / key to select the lock level of the Parental Rate.p q
Please Enter Password
Lock
Subtitle
This used to set Subtitle
Turn on or turn off the subtitle function.
HBBTV
This used to set HBBTV
Turn on or turn off the HBBTV function.
Subtitle
Subtitle
Primary
Secondary
Hearing Impaired
Off
ENGLISH
ENGLISH
Off
Return
MENU
31
Menu system instruction
Auto Search
Program Edit
DTV Manual Search
ATV Manual Search
Signal Information
Channel
Program Edit
9 Nine Digital
90 Nine Digital HD
99 Nine Guide
1BBC1
2C-04
3C-06
4C-08
5C-12
6C-23
7S-02
BlockDelete Skip Fav
Sofeware Update (OAD)
OAD SCAN
Return
MENU Info
Move
Before your television can begin memorizing the available channels,
you must specify the type of signal source that is connected to the
TV (i.e. an antenna or a cable system).
1. Press key to display the main menu on the screen.MENU
2. Press / key to select "Channel" option. p q
3. Press OK or key to enter "Channel" submenu. u
Auto Search
1. Press / key to select "Auto Search" option. p q
2. Press or key to confirm. then a notice window will be uENTER
displayed on the screen.
Select "Start" to start search or "Cancel" to cancel it.
When searching, press EXIT key to exit tuning at any moment. Press
MENU key to skip DTV tuning when searching DTV, skip ATV tuning
when searching ATV.
3. After all the available channels are stored, the searching menu will exit.
Program Edit
After the program is searched, select “Program Edit” in the “Channel”
menu, press “ ” button, program can be edited such as delete or ENTER
skip according to the user's habit.
Skip (Blue) Button
This function can help shield certain program. Program skips when
selecting program by the “ button on the TV or remote control./p q”
1. Select the program to be shielded in the“Program Edit”.
2. Press “Skip” (Blue) button, the skip mark is displayed at the left side
of the program and this program is shielded.
3. To cancel the Skip function, enter the channel edit menu, select the
shielded program and press “Skip” (Blue) button, the skip mark at the
left side of the program disappears then program is recovered.
Delete (Red) Button
This function can help delete program.
1. Select the program to be deleted in the "Program Edit".
2. Press "Delete"(Red) button, the program will be deleted.
Favorite(Yellow) button
This function can help store the favorite program then these programs can be quickly selected.
1. Select the program which is favorite.
2. Press “Fav” (Yellow) Button, the favorite mark is displayed at the left side of the program and this
program is store into the Favorites.
3.T o cancel the Favorite function, enter the program edit menu, select the program and press
“Fav” (Yellow) button, the favorite mark at the left side of the program disappears.
Block (green) Button
This function can help Lock on unlock the program.
1. Select the program to be Locked in the “Program Edit”.
2. Press "Block"(Green) button, and input the right password, the lock mark is displayed at the left
side of the program.
3. Press “Block ”(green) button again , the program will be unlocked.
Move (Info) Button
This function can move channel.
32
Menu system instruction
DTV Manual Search
Enter digital number and press “ ” to select DTV Channel.ENTER
ATV Manual Search
1. Press / key to select "ATV Manual Search" option. p q
2. Press or key to enter submenu.uENTER
Current CH
1. Press / key to select the second item. p q
2. Press / key to select current channel.t u
Color System
Select ATV video system type function.
System
Select ATV audio system type function.
Search
You can use button to search channels from low frequency u
to high frequency and use button to search channels from t
high frequency to low frequency. When you have searched a
channel, the searching will be paused and you can press it
again for other channels after you store the channel.
Fine-Tune
1. Press / key to select the third item. p q
2. Press / key to select a better frequency for current channel.t u
Signal Information ( )Used only in DTV
Signal Information1. Press / key to select “ " option.p q
2. Press “ ”or key ,you can see the i of the DTV channel. ENTER unformation
NOTE:
Signal Quality/Signal Strength (DTV Only): Unlike analogue channels,
which can vary in reception quality, digital channels must have perfect
reception quality or you will not receive them at all. So, unlike analogue
channels, you are not able fine tune a digital channel. If the signal strength
indicates that the signal is weak, a possible solution is to adjust your
antenna to increase the signal strength. Continue to adjust the antenna until you find the best
position with the strongest signal.
Sofeware Update (OAD)
Turn on or turn off OAD software update function.
OAD SCAN
This option only used in DTV mode.
1. Press / button to select “OAD Scan” option.p q
2. Press button to search system software update file from DTV broadcast.ENTER
DTV Manual Search
UHF CH 40
ENTER Search
Bad Normal Good
DTV
Radio
Data
Press ENTER to search
Return
ATV Manual Search
Current CH 1
Color System PAL
System BG
Search
Fine-Tune
Save Return
Frequency 471.31 MHz
MENU
MENU
Channel
Channel 37
Name Nine Melbourne
Modulation DVBT
Quality 53
Strength 9
0
0
0
33
1.Press the “Menu” to enter, then pitch on the ”Option”,and press “ ”” or click the right button ENTER
to enter the submenu.
2.Pitch on the "Network Configuration",and press “ ” or click right button to enter the "Network ENTER
Configuration".
3.When the wired network is used, if select dynamic IP address setting, pitch on the "DHCP" in
the "Network Configuration", then click the "Setting", and press the “ ” button to enter.ENTER
If select static IP address setting, pitch on the "Static" in the "Network configuration", then setting
up the IP, Nemask, Gateway and DNS in sequence. When the setting complete, pitch on the
"Setting" and press the “ ”.ENTER
Network Setting
OSD Language
OSD Time
Reset
Network Configuration
Software Upadate
Internet Update Check
Info
Setting
IP 169. 254. 018. 061
Ne 5. 000
Gateway 172. 016. 088. 254
DNS 172. 016. 064. 058
STATUS WIFI LAN
Network Configuration DHCP
Fail
PC Adjust
Sound
Function
Time
Option
Lock
Channel
34
IP 169. 254. 018. 061
Ne 5. 000
Gateway 172. 016. 088. 254
DNS 172. 016. 064. 058
STATUS WIFI LAN
Network Configuration DHCP
Fail
4.If shows "Success" " ", the WLAN on the bottom right corner will turn to green from red, and
it means the network connect successfully; If shows Fail it means the network can not connect, " ",
please check whether the net wire and router connect successfully or not.
5. Select the "WIFI" in the Network Configuration before using WIFI connecting.
STATUS WIFI LAN
Network Configuration Static
IP 172. 016. 067. 130
Netmask 255. 255. 254. 000
Gateway 172. 016. 066. 254
DNS 172. 016. 064. 081
STATUS
SSID Not Connected
Password
Network Configuration DHCP
IP . 000
Netmask 000. 000. 000. 000
Gateway 000. 000. 000. 000
DNS 000. 000. 000. 000
Scan AP
WIFI LAN
Scanning...
Network Setting
Setting
Setting
Setting
35
Pitch on the "Setting" press the to confirm., “ ”ENTER
If shows "Success" the "WIFI" on the bottom right corner ,
will turn to green from red, and it means the network
connect successfully; If shows "Fail" it means the network ,
can not connect, please check whether the wireless router
connects successfully or not.
STATUS
SSID Not Conn ect ed
Pas sword
Net work Co nfiguration DHCP
IP . 000
Net ma sk 000 . 000 . 000. 000
Gat eway 000. 000. 000. 000
DNS 000. 0 00. 0 00. 0 00
Sca n AP
WIFI LAN
Fail
Network Setting
Setting
36
Sign in
Get ready to watch thousands of TV shows and movies .
Enter your email address
1 2 3 4 5 6 7 8 9 0
q w e r ty u io p
a s d f ghjk l
l
l
z x c v b n m
@gmail com.@yhoo com tw. . @hotmail com.
!#$ @ com
³
³
³
³
x
Back Next
Remember Email
ê
Email address
Need help signing in? Visit http://help netflix com . .
Press “HOME” key to enter internet interface
1. NETFLIX
Œ Use arrow key to Select button, then press “ENTER” key to enter NETFLIX.
Use arrow button to select one video and press “ENTER” key to play.
Press “MENU” key to exit playing.
Ž Use arrow key to browse the pages. press “MENU” key to return to main menu and press
“EXIT” key to exit.
2. Youtube
Œ Use arrow key to Select button, then press “ENTER” key to enter Youtube.
Use arrow button to select one video and press “ENTER” key to play.
Ž .Press key to open or close control menu when playingq
Internet
37
3.Twitter
Œ Use arrow key to Select button, then press “ENTER” key to enter Twitter.
Input the right Email and password, then select “Authorize app” button and press “ENTER”
key to log in.
Ž Use arrow key to browse the pages. press “MENU” key to return to main menu and
press “EXIT” key to exit twitter.
Red key: log in or log out twitter.
Green key: refresh current page.
Yellow key: write new tweet.
Blue key: Search tweet.
Internet
38
4.Facebook
Œ Use arrow key to Select button, then press “ENTER” key to enter Facebook.
Input the right Email and password,
select “log In” button, then press
“ENTER” key to log in.
Ž Press arrow key to browse the pages and press “ENTER” key to view.
Press “MENU” key to return the main menu.
Press “EXIT” key to exit Facebook.
Red key: log in or log out Facebook.
Green key: refresh current page.
5.Accuweather
Œ Use arrow key to Select button, then press “ENTER” key to enter Accuweather.
Input a city or zip code press select to get the weather information.
Internet
Produktspezifikationen
| Marke: | Palsonic |
| Kategorie: | Fernsehen |
| Modell: | PT3215SH |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Palsonic PT3215SH benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Fernsehen Palsonic
31 August 2024
31 August 2024
31 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
Bedienungsanleitung Fernsehen
- Fernsehen Samsung
- Fernsehen Infiniton
- Fernsehen Clatronic
- Fernsehen Acer
- Fernsehen Sanyo
- Fernsehen BenQ
- Fernsehen Lexibook
- Fernsehen Manhattan
- Fernsehen Manta
- Fernsehen Medion
- Fernsehen Philips
- Fernsehen Sony
- Fernsehen Sweex
- Fernsehen Tevion
- Fernsehen Zalman
- Fernsehen Panasonic
- Fernsehen LG
- Fernsehen MX Onda
- Fernsehen AEG
- Fernsehen Siemens
- Fernsehen Electrolux
- Fernsehen Küppersbusch
- Fernsehen OK
- Fernsehen Vox
- Fernsehen TechniSat
- Fernsehen XD Enjoy
- Fernsehen Denver
- Fernsehen ECG
- Fernsehen Intenso
- Fernsehen MarQuant
- Fernsehen Bush
- Fernsehen Telefunken
- Fernsehen Thomson
- Fernsehen Trevi
- Fernsehen BEKO
- Fernsehen Blaupunkt
- Fernsehen Grundig
- Fernsehen Schneider
- Fernsehen Sharp
- Fernsehen Aspes
- Fernsehen Brandt
- Fernsehen Daewoo
- Fernsehen Pyle
- Fernsehen Mitsubishi
- Fernsehen Finlux
- Fernsehen Haier
- Fernsehen High One
- Fernsehen Hisense
- Fernsehen Luxor
- Fernsehen NABO
- Fernsehen Nordmende
- Fernsehen Salora
- Fernsehen SEG
- Fernsehen Smart Brand
- Fernsehen Svan
- Fernsehen Techwood
- Fernsehen Vestel
- Fernsehen Philco
- Fernsehen Schaub Lorenz
- Fernsehen Aiwa
- Fernsehen Alphatronics
- Fernsehen AudioSonic
- Fernsehen Coby
- Fernsehen Bang And Olufsen
- Fernsehen DIFRNCE
- Fernsehen Lenco
- Fernsehen Mpman
- Fernsehen ODYS
- Fernsehen Pioneer
- Fernsehen Polaroid
- Fernsehen Jay-Tech
- Fernsehen JVC
- Fernsehen Krüger And Matz
- Fernsehen Muse
- Fernsehen Nokia
- Fernsehen Optoma
- Fernsehen PEAQ
- Fernsehen Xiaomi
- Fernsehen Abus
- Fernsehen Megasat
- Fernsehen Walker
- Fernsehen Akai
- Fernsehen Arçelik
- Fernsehen Caratec
- Fernsehen Changhong
- Fernsehen Chiq
- Fernsehen Continental Edison
- Fernsehen Dual
- Fernsehen Dyon
- Fernsehen Edenwood
- Fernsehen Ferguson
- Fernsehen Funai
- Fernsehen GoGEN
- Fernsehen Hannspree
- Fernsehen Hitachi
- Fernsehen Horizon
- Fernsehen Hyundai
- Fernsehen JTC
- Fernsehen Kernau
- Fernsehen Loewe
- Fernsehen Metz
- Fernsehen MT Logic
- Fernsehen Orava
- Fernsehen Orion
- Fernsehen Reflexion
- Fernsehen Star-Light
- Fernsehen Strong
- Fernsehen TCL
- Fernsehen Tesla
- Fernsehen Toshiba
- Fernsehen Allview
- Fernsehen Casio
- Fernsehen Sencor
- Fernsehen Icy Box
- Fernsehen Element
- Fernsehen ViewSonic
- Fernsehen Dell
- Fernsehen Lenovo
- Fernsehen Cecotec
- Fernsehen Nikkei
- Fernsehen Xiron
- Fernsehen Opera
- Fernsehen Sagem
- Fernsehen Antarion
- Fernsehen Xoro
- Fernsehen Humax
- Fernsehen Logik
- Fernsehen CGV
- Fernsehen LTC
- Fernsehen Bluesky
- Fernsehen Orima
- Fernsehen Proline
- Fernsehen NEC
- Fernsehen Marantz
- Fernsehen TEAC
- Fernsehen Packard Bell
- Fernsehen Westinghouse
- Fernsehen AOC
- Fernsehen NextBase
- Fernsehen Vivax
- Fernsehen Uniden
- Fernsehen Kogan
- Fernsehen Innoliving
- Fernsehen Magnum
- Fernsehen Smart Tech
- Fernsehen JGC
- Fernsehen Soundmaster
- Fernsehen Sylvania
- Fernsehen Qilive
- Fernsehen Doffler
- Fernsehen NewStar
- Fernsehen Zenith
- Fernsehen Insignia
- Fernsehen Roadstar
- Fernsehen SereneLife
- Fernsehen Woxter
- Fernsehen Sogo
- Fernsehen Peerless-AV
- Fernsehen RCA
- Fernsehen Oppo
- Fernsehen Vivo
- Fernsehen AYA
- Fernsehen Furrion
- Fernsehen Seiki
- Fernsehen Alba
- Fernsehen Aldi
- Fernsehen Daitsu
- Fernsehen Digihome
- Fernsehen E-motion
- Fernsehen Emerson
- Fernsehen GPX
- Fernsehen Graetz
- Fernsehen HKC
- Fernsehen Hoher
- Fernsehen ILive
- Fernsehen Naxa
- Fernsehen Online
- Fernsehen Onn
- Fernsehen Oyster
- Fernsehen Premier
- Fernsehen Reflex
- Fernsehen Rm 2000
- Fernsehen Saba
- Fernsehen Sbr
- Fernsehen Sunny
- Fernsehen Sunstech
- Fernsehen TechLine
- Fernsehen Technika
- Fernsehen Tele 2
- Fernsehen Grunkel
- Fernsehen Tve
- Fernsehen Viewpia
- Fernsehen Vision Plus
- Fernsehen Vizio
- Fernsehen Voxx
- Fernsehen Wharfedale
- Fernsehen Yasin
- Fernsehen Ziggo
- Fernsehen Videocon
- Fernsehen Bauhn
- Fernsehen Planar
- Fernsehen Monster
- Fernsehen Mitsai
- Fernsehen Proscan
- Fernsehen Kunft
- Fernsehen Nevir
- Fernsehen Seura
- Fernsehen EKO
- Fernsehen SunBriteTV
- Fernsehen Kemo
- Fernsehen V7
- Fernsehen Astar
- Fernsehen QBell Technology
- Fernsehen Visco
- Fernsehen Majestic
- Fernsehen DirecTV
- Fernsehen HCI
- Fernsehen Mach Power
- Fernsehen MBM
- Fernsehen Inno-Hit
- Fernsehen Elements
- Fernsehen Cello
- Fernsehen Pantel
- Fernsehen FFalcon
- Fernsehen Coocaa
- Fernsehen SYLVOX
- Fernsehen ISymphony
- Fernsehen Aristona
- Fernsehen Apex
- Fernsehen Tucson
- Fernsehen Kubo
- Fernsehen Avtex
- Fernsehen NPG
- Fernsehen Telesystem
- Fernsehen ATYME
- Fernsehen Lin
- Fernsehen Tivax
- Fernsehen H&B
- Fernsehen Norcent
- Fernsehen TELE System
- Fernsehen Belson
- Fernsehen Elbe
- Fernsehen Mitzu
- Fernsehen Voxicon
- Fernsehen Aconatic
- Fernsehen Mitchell & Brown
- Fernsehen FOX Electronics
- Fernsehen Mystery
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
