Seite 1/6
GARDEN
SHREDDER
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 36V (2 x 18V)
No Load Speed: 3,000/min
Cutting Diameter: 25mm max.
Blades: 3, Reversible
Noising Rating: 100dB
Collection Bag: 55 Litres
Weight: 10.74kg
PXGSS-3625
STANDARD EQUIPMENT
Shredder Housing
ozito.com.au
Axle, Wheel Caps
WARRANTY
1123
CORDLESS
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty. Warranty excludes consumable parts and included accessories, for
example: bearings, blades, push stick, hex key, collection bag and wheels.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO. 25 Fox Drive, Dandenong South, Victoria 3175, Australia.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
Push Stick, Collection Bag
Wheels, Stand
Socket Screws & Washers
Wheel Spacers, Hex Key
Assembly
Screw x 2
ONLINE MANUAL
Scan this QR Code with your mobile
device to take you to the online manual.
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
Fitting the Wheels and Stand
WARNING! ENSURE THE MACHINE IS SWITCHED
OFF AND BATTERIES ARE DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
1
8
2
3
4
14
6
7
1. Hopper
2. Transport Handle
3. Hopper Lock
4. Hex Key Storage
5. On/Off Switch
6. Collection Bag Hook
7. Motor Housing
8. Stand
9. Transport Wheels
10. Hex Key
11. Push Stick
12. Collection Bag
13. Discharge Chute
14. Battery Cover
15. Hopper Housing
CORDLESS GARDEN SHREDDER
BATTERY & CHARGER
This tool is compatible with all battery and
chargers from the Ozito PXC Range.
9
11
12
13
5
1. Carefully place the shredder
housing upside down on a at
surface. Place each leg of the
stand into the two holes at the
base of the shredder housing.
2. Using a screwdriver (not
included) secure the legs
using the two assembly
screws provided, turn in
a clockwise direction to
tighten.
3. Thread the axle through the
holes in the stand.
4. Place wheel spacer over each
protruding end of the axle.
10
15
ab
2. PREPARATION
Note: Ensuring that the larger
inner diameter of the wheel is
facing outwards. This allows the
wheel cap to be tted.
5. Insert each wheel over
the wheel spacers, then
secure with washer and
socket screws.
6. Insert a screwdriver through the
holding hole on the axle and
tighten the socket screws with hex
key provided, turn in a clockwise
direction. Inserting and Removing the Batteries
Only use 2 batteries with the same capacity (Ah). Always use 2
batteries with the same charge state with the garden shredder.
Run Time
Hold open the cover and insert
two fully charged batteries into
the battery mounts, align the ribs
of the battery with the battery
mounts as you slide the battery in
so that they click into place.
The operating time of the PXC battery (the amount that can be shredded
with a single battery charge) is largely dependent on the state of the
shrubbery (e.g. Density, moisture, thickness, etc.) and the battery
charge level. Never combine full and half-full batteries or batteries with
different capacities (Ah).
Frequently turning the equipment on and off will also reduce the
runtime and amount that you can shred. If the operating time of the PXC
battery (runtime) is still unsatisfactory in spite of the above measures,
you can remedy the problem by using a PXC battery with a larger
capacity (Ah).
7. Place the wheel
cap onto the
wheels; ensure the
three tabs on the
caps latch onto the
recesses on the
wheels.
8. Once fully assembled
carefully lift the shredder
into its correct position
supported by the stand and
wheels.
9. For easy access and safe
storage of your push
stick, slide it onto the
holder located on the right
underside of the shredder.
Note: The cover is spring loaded and is self-closing. Magnets hold the
cover shut.
To remove, press and hold the
battery release tab to release, (a)
then slide the battery out .(b)
Collection Bag
Hang the collection bag on the
hooks located on both sides of the
shredder.
Note: The Hex Key storage location
is on the rear
of the shredder
directly above the
on/off switch.
