User Guide &
Owners Manual
OWC Mercury Elite-AL Pro Qx2 Table of Contents
1 INTRODUCTION
1.1 SYSTEM REQUIREMENTS
1.1.1 Mac Requirements
1.1.2 PC Requirements
1.1.3 Supported Hard Drives
1.2 PACKAGE CONTENTS
1.3 ABOUT THIS MANUAL
1.4 PORT VIEW & CABLE CONNECTIONS
1.5 DETAILED VIEW
1.5.1 LED Indication & Buttons
1.5.2 RAID Selector Switch
1.5.3 Smart Fan
1.5.4 Buzzer
1.5.5 2TB Switch
1.6 RAID MODES
1.6.1 Disk Spanning
1.6.2 Disk Striping (RAID 0)
1.6.3 Disk Mirroring (RAID 1)
1.6.4 Disk Mirroring with Striping (RAID 10)
1.6.5 Disk Striping with Parity (RAID 5)
1.6.6 Changing the RAID mode
2 SYSTEM SETUP
5 APPENDIX
6 CUSTOMER SERVICE
6.1 BEFORE CONTACTING CUSTOMER SERVICE
6.2 CUSTOMER SERVICE HOURS OF OPERATION
2.1 HARD DRIVE ASSEMBLY
2.2 REPLACING HARD DRIVES
2.3 CONNECTIONS TO COMPUTER
3 FORMATTING
3.1 MACINTOSH FORMATTING
3.2 REMOVING AN EXISTING GUID PARTITION (PRECONFIGURED SOLUTIONS)
3.3 WINDOWS FORMATTING
4 TROUBLESHOOTING & TIPS
4.1 TROUBLESHOOTING
4.2 USAGE TIPS
5.1 FAQ
5.2 ABOUT DATA BACKUP
1.1 System Requirements
1.1.1 Mac Requirements
•Minimum PowerPC G4 Processor, 128MB RAM
•eSATA interface, Mac OS X 10.3 or later (OR)
•FireWire interface, Mac OS X 10.2 or later (OR)
•USB 2.0 interface, Mac OS X 10.2 or later
1.1.2 PC Requirements
•Minimum 500MHz Intel Pentium 3 Processor, 128MB RAM
•eSATA interface, Windows XP / Vista (OR)
•FireWire interface, Windows 2000 / XP / Vista (OR)
•USB 2.0 interface, Windows 2000 / XP / Vista / Windows 7
1.1.3 Supported Hard Drives
•Up to 4 3.5” SATA-I or SATA-II hard drives (1.5Gb/s or 3.0Gb/s)
•40GB - 2.0TB per HDD (must install at least 2 drives)
•Hard Drives of identical capacity / model are required
For a list of recommended hard drives, please see this web page:
http://www.macsales.com/Qx2drives
1.2 Contents
1.3 About This Manual
Firmware, images, and descriptions may vary slightly between this manual and the
unit shipped. Functions and features may change depending on the rmware version.
Please visit the product webpage for the most recent specications.
Item Quantity
➀ OWC Mercury Elite-AL Pro Qx2 1
➁ Hard Drive Tray 4
➂ eSATA cable 1
➃ 1394B FireWire 800 cable 1
➄ 1394A (FireWire 400) cable 1
➅ USB 2.0 (A-B) cable 1
➆ Power cable 1
➇ Drive Keys 2
➈ User Guide & Owner’s Manual 1
➉ Software CD Bundle (solutions only) 1
Hard Drives (not pictured - solutions only) 4
OWC Mercury Elite-AL Pro Qx2 Chapter 1 - Introduction
1 INTRODUCTION
User Guide &
Owners Manual
➀
➁
➂
➈
➇
➅➄➃ ➆ ➉
