U ’ GSER S UIDE
S I M P L Y A M A Z I N G
•IMPORTANT•
SAVE THIS BOOKLET!
Includes:
• Safety Warnings
• Parts List
• Operating Instructions
• Accessories List
• Warranty
• Trouble Diagnosis
Compact
Canister
Vacuum
72197-01 REV A
Models
BB877-RD
®
ITEM
1. Vacuum cleaner housing with paper filter bag and micro filter
installed
2. Adjustable shoulder strap
3. Flexible hose with built-in adapter for easy insertion in vacuum or
blower port
4. Crevice tool
5. Fabric tool
6. Bare floor and wall tool
7. Tool adapter tube for fitting tools directly to vacuum when not
using hose
8. Two extension wands
9. Dusting brush
10. Tool Caddy
Table of Contents
Maintenance, Important Electrical Information, Parts Included,
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
To Operate, Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Warranty, Safeguards, Accessories, Troubleshooting Guide . . page 4
Maintenance
Your Oreck Compact Vacuum Cleaner is a product of precise
engineering. The motor bearings are permanently lubricated and should
not be oiled.
Save your sales or purchase slip. Should your Oreck appliance require
warranty service, present this slip to the Authorized Service Center as
your proof of purchase date.
Important Electrical Information
MOTOR PROTECTION SYSTEM: If fine materials such as soot,
cement, plaster dust, copy machine powder, etc. are picked up,
the bag surface may seal and cause the motor to shut off to
avoid overheating. If this happens, turn the switch off and unplug
the cleaner. Replace filter bag. Check and clear any clogs in
hose or accessories. After approximately 30 minutes the motor
will have cooled and the cleaner will be ready to use.
Note: The cleaner must remain unplugged for 30 minutes
for motor to cool and system to reset.
2
BEFORE OPERATING CLEANER,
READ ALL INSTRUCTIONS IN
THIS MANUAL CAREFULLY.
When using an electrical appliance, basic
precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS VACUUM CLEANER
WARNING
To reduce the risk of fire,
electric shock, or injury:
IMPORTANT SAFETY
INSTRUCTIONS
• Do not leave appliance unattended when plugged in.
Unplug from outlet when not in use and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
• Use only as described in this manual.
• Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service
center.
• Do not pull or carry by cord, use cord as a handle, close
door on cord, or pull cord around sharp edges or corners.
Do not run appliance over cord. Keep cord away from
heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair and anything
else that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of body
away from openings and moving parts.
• Do not use to pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
• Do not use without filter bag assembly in place.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids,
such as gasoline, or use in areas where they may be
present.
SAVE THESE INSTRUCTIONS
Household Use Only
Parts Included
1
2
3
4
5
6
7
8
9
10
3
To Operate
Plug cord into electrical outlet.
Shoulder Strap
fig. 1a Insert end of shoulder strap into slot in front of On/Off power
switch. Pull through three to four inches and insert into plastic
clip. One inch of strap must be completely through clip. Insert
other end of strap through slot located at back of handle. Insert
end into clip and pull through. Adjust length by pulling strap
through clip. Strap must go through both front and back clips.
IMPORTANT: Before using shoulder strap, pull both ends to be sure it is
secure.
Power Switch
fig. 1b Push the power switch located on handle to the “ON” (I) position.
Hose & Tool Installation
fig. 2 The flexible hose uses a Shurlock™ locking system that
prevents hose removal unless intended. To install hose,
align “J” slot in hose coupling with tab inside the suction
port. Insert hose in port. Twist collar clockwise to lock
hose coupling in port. Twist counterclockwise and pull to
remove hose.
fig. 3 NOTE: When installing tools directly to blower or suction port
without using hose, tool adapter tube must be used.
Blower Port
fig. 4 The blower port is located at the rear of the machine. Installation
of tools is the same as described for suction port.
Attach Caddy and Insert Tools
fig. 5 Locate caddy clip indents at top rear corners of appliance. Place
appliance on firm, nonslip surface or hold in your lap. Grasp
handle firmly. Place end of caddy in outside indent then strongly
push and pull other end of caddy into opposite indent. Be sure
rims on caddy openings face up. Avoid trapping fingers when
caddy snaps on; painful pinch could result. If caddy needs to be
removed, a large flat-head screwdriver inserted under caddy clip
at indent can be used to carefully pry caddy loose.
fig. 6 Pull cord through center opening in caddy and push until it is
seated at back of slot at rear of center opening in caddy.
fig. 7 Insert crevice tool, brush and fabric tool into caddy in spaces
provided.
Cord Dump
fig. 8 Twist cord dump to easily release stored cord.
Maintenance
Changing the Filter Bag
fig. 9 Use only genuine Oreck XL filter bags. Stand unit on its back.
Twist knob counterclockwise to release front plate. Lift out front
plate.
fig. 10 Remove used bag and insert fresh bag. The cardboard rim fits
smoothly into the recessed top.
fig. 9 Replace the front plate and close unit by turning knob clockwise.
fig. 11 IMPORTANT: The white gasket glued in the housing must be in
place or unit will not operate properly. Replace if needed.
Replacing Micro Filter
Stand unit on its back.
fig. 9 Stand unit on its back. Twist knob and lift out front plate.
fig. 10 Remove disposable bag.
fig. 12 Remove old filter from bottom inside unit. Replace with new
filter.
A replacement filter is supplied in each package of 12 Oreck XL filter
bags or you may order filters separately.
1 2
3 4
5 6
7 8
9 10
11 12
b
a
SUCTION PORT
ADAPTER TUBE BLOWER PORT
WHITE GASKET MICRO
FILTER
