iConverter® Gx AN Media Converter
STANDALONE AND PLUG-IN MODULE
USER MANUAL
Page 2
Table of Contents
1.0 Overview ...........................................................................................................................3
1.1 General Description 3 ..................................................................................................
2.0 Port Structure....................................................................................................................3
2.1 Overview ...................................................................................................................3
2.1.1 RJ-45 and Fiber Ports 3 ..................................................................................
3.0 Installation Procedure 4 .......................................................................................................
3.1 Overview ...................................................................................................................4
3.2 ConguringDIP-switches ......................................................................................4
3.2.1 DIP-switchSettings ......................................................................................4
3.3 InstallingtheModuleandConnectingCables ..........................................................6
3.3.1 Plug-InModules ..............................................................................................6
3.3.2 StandaloneModules .......................................................................................7
3.4 VerifyingOperation ...................................................................................................8
4.0 ConguringtheModuleviaCommandLineInterface.......................................................8
4.1 Overview ...................................................................................................................8
4.2.1 SFP Status 12 ....................................................................................................
5.0 GxANSpecications ......................................................................................................14
6.0 TroubleshootingGuide ...................................................................................................15
6.1 Overview .................................................................................................................15
6.1.1 Power Issues 15 .................................................................................................
6.1.2 Fiber Issues 15 ...................................................................................................
6.1.3 RJ-45 Issues 16 .................................................................................................
7.0 Warranty .........................................................................................................................17
8.0 CustomerServiceInformation ........................................................................................18
1.0 OVERVIEW
This document describes the installation and conîš¿guration of the iConverter Gx AN standalone and plug-in
modules.
1.1 GENERAL DESCRIPTION
The Omnitron iConverter® Gx AN provides 1000BASE-T copper to 1000BASE-X ber media conversion.
The îš¿ber optic port supports auto and forced negotiation conîš¿guration via DIP-switches. The RJ-45 port
automatically detects and advertises the Duplex and Pause abilities of connected copper devices.
The iConverter Gx AN models with îš¿xed-îš¿ber connectors are available with multimode (MM) dual-îš¿ber,
single-mode (SM) dual-îš¿ber and single-mode single-îš¿ber (SF) options. They support ST, SC and LC
connectors with distances up to 2km over MM îš¿ber, 140km over SM îš¿ber and 40km over SF. The Gx AN
Small Form Pluggable (SFP) model supports a wide variety of 1000BASE-X SFP transceivers.
The Gx AN plug-in module is a managed media converter when installed in a chassis with a management
module such as the Network Management Module (NMM2) or a module with integrated management. The
standalone module is an unmanaged media converter supporting DIP-switches for conîš¿guration options.
2.0 PORT STRUCTURE
2.1 OVERVIEW
The front panel of the Gx AN provides access to the copper and îš¿ber ports. The îš¿ber port will vary
depending on the connector type; ST, SC, LC or SFP supporting 1000BASE-X transceivers.
2.1.1 RJ-45 and Fiber Ports
The îš¿ber interface supports the 1000BASE-X protocol. The îš¿ber interface operates in manual mode or
auto-negotiation and supports Full-Duplex operation.
The RJ-45 port supports 1000BASE-T protocols, auto-negotiation mode for Half and Full-Duplex. When
the îš¿ber port is operating in manual mode, the RJ-45 port can be conîš¿gured to negotiate to a speciîš¿c
duplex mode.
Page 3
