SATELLITE WATER FILTRATION SYSTEM
FS7025 FS7075 FS7005
WAT E R DR I N K I N G S Y ST E M S
OWNER’S MANUAL
HEALTH CLAIM PERFORMANCE CLASSIFIED BY NSF.
This system has been tested according to NSF/ANSI 42 and 53 for the reduction of the
substances listed below.
The concentration of the indicated substances in water entering the system was reduced
to a concentration less than or equal to the permissable limit for water leaving the system,
as specified in NSF/ANSI 42 and 53.
OPERATING SPECIFICATIONS:
• Capacity: 9,450 litres
• Pressure Requirement: 10-125 psi (0.7 - 8.6 bar), non-shock.
• Temperature: 2-38O C
• Flow Rate: 0 - 1.9 litres per minute.
GENERAL INSTALLATION / OPERATION/MAINTENANCE
REQUIREMENTS:
• Space required: 460mm x 225mm (allows space for cartridge replacement)
• Install cartridge vertically or horizontally with stabilizing support bracket.
• Flush new cartridge at full flow for 2–3 minutes until air is purged.
• Replace cartridges when capacity is reached, or when flow becomes too slow, but at least annually.
SPECIAL NOTICES:
• Installation instructions, parts and service availability, and standard warranty are included with
the product when shipped.
• This drinking water system must be maintained according to manufacturer’s
instructions, including replacement of filter cartridges.
• Do not use with water that is microbiologically unsafe, or of unknown quality without adequate
disinfection before or after the system.
• The contaminants or other substances removed or reduced by the water
treatment system are not necessarily in your water.
• Check for compliance with state and local laws and regulations.
FS7025, FS7075, FS7005
Performance Data
Important Notice:
Read this performance data sheet and compare the capabilities of this
unit with your actual water treatment needs.
FEATURES:
Filters water through designer filter tap
Provides quality filtered water without compromising on flow rate
Easy installation and space saving design
Compatible with any bench top including solid surface
Suitable for vertical or horizontal installation to maximise cupboard space
Finely filters to 1 micron and polishes mains water to a premium quality for:
• Drinking
• Cooking
The latest carbon block filtration technology absorbs:
• Chlorine
• Bad tastes
• Odours
Maintains healthy minerals and salts as well as fluoride
Helps to prevent the build up of limescale
Simple, easy to change cartridge replacements
• Dirt
• Rust
• Cysts (e.g. giardia & cryptosporidium)
• Tea & coffee
• Washing fruits & vegetables
*Tested using flow rate=0.5gpm; pressure=60psig; pH=7.5 ± 0.5; temp=20oC ± 2.5oC †NTU=Nephelometric Turbidity Units
Max. Permissible
Subtance Influent Challenge Product Water Reduction Minimum Average
Requirements Concentration Concentration Requirements Reduction
Standard 42 Aesthetic Effects
Chlorine 2.0mg/L±10% 5ppm ≥50% - 98%
Particulate at least 10,000 - ≥85% - 99.8%
Class 1 particles particles/mL
<1um
Standard 53 Health Effects
Cyst Minimum 50,000/L - 99.95% 99.99% 99.99%
Turbidity 11±1 NTU
† 0.5 NTU1 - 98% 99%
Check for compliance with state and local laws and regulations. Product performance is
dependant upon incoming water conditions. This drinking water system must be maintained
according to the manufacturer’s instructions, including replacement of cartridge.
AS3497
Lic.WMKA22045
IAPMO R&T OCEANA
This appliance meets the domestic water treatment
appliance Standards AS/NZS3497 for the following
water treatment processes:
WARNING: FOR CORRECT OPERATION
OF THIS APPLIANCE IT IS ESSENTIAL
TO OBSERVE THE MANUFACTURER’S
INSTRUCTIONS.
CLASS TREATMENT TYPE FUNCTION PASS
I.
II. II (a)
II (b)
III (c)
III.
IV.
Microbiological Status
Bacteriostatic
Microbiological Treatment
Bacteria Removal
Virus Removal
Protozoa Removal
Turbidity and Particulate
Reduction
Taste and Odour Reduction
Will stop bacteria increasing but will
not stop them unless IIa is passed.
Will remove or inactivate bacteria.
Will remove or inactivate virus.
Will remove or inactivate
Cryptosporidium and Giardia.Will
not remove or inactivate bacteria and
virus unless II(a) and II(b) is passed.
Reduces Cloudiness
Reduces Tastes and Odours
N/A
N/A
N/A
3
3
3
System tested and Classified by
Underwriters Laboratories Inc
against NSF/ANSI Standards
42 and 53 for the reduction of:
Std. No 42 -
Aesthic Effects
Chemical Reduction
Chlorine
Taste & Odour
Mechanical Filtration
Nominal Particulate Class 1
Std. No 53 -
Health Effects
Mechanical Filtration
Cyst
Turbidity
WATER QUALITY
WATER FILTER
ANSI/NSF
STANDARDS
42 AND 53
3LSD
Distributed by:
Tasman Sinkware Pty Ltd.
51 Naweena Rd, Regency Park, SA, 5010
1300 137 465
sinkware@oliverisinks.com.au
oliveri.com.au
INSTALLATION INSTRUCTIONS
1. Open Carton and Inspect Parts. Installation
Parts included – refer installation diagram
Item No.
Cistern Tap 1
/2” fbsp x 1
/2” mbsp (1)
Dual Check Valve 1
/ ”2 fbsp x 1
/ ”2 mbsp (2)
Pex Hose 750mm (3)
Head Assembly (4)
Filter Cartridge (5)
Pex Hose 550mm (6)
Filter Tap (7)
Filter Monitor Alarm (8)
Mounting Screws (9)
IMPORTANT NOTES
• When installing this filter system in a new home or
kitchen please ensure that the cold water lines under
the sink are flushed to remove all debris within the
pipes, before installation of the water filter system.
• This Water Filtration System should be installed in
accordance with any local Water Authority by-laws.
Australian Standard AS3500
• Where water pressure exceeds 860 kPa a suitable
pressure limiting valve should be installed prior to
connection to the filter system.
2. Connect to Water Supply
It is advisable to turn off the water supply at the
mains before commencing installation.
Check to see if separate water connection is provided.
IF A SEPARATE WATER CONNECTION IS NOT
PROVIDED
• Locate the cistern tap mounted on the wall
underneath the sink for the existing cold water
line.
• Turn off isolation cistern tap and disconnect
attached fittings.
Attach the following parts to the existing cistern tap
according to the Connection Diagram below
Using plumbing tape:
• Attach the following parts to the cistern tap
according to the Connection Diagram below.
Brass Female Tee 1
/ 2” BSP*
Brass Nipple 1
/2” BSP – 1
/ 2” BSP (x2)*
Cistern Tap supplied
• Reconnect the cold water line to the available
1
/2” connection. Firmly tighten all connections
* Parts not included with system.
3. Undersink Mounting Position
This Water Filter System can be installed in either
the horizontal or vertical position.
a) Vertical Installation
Measure 460m from the base of the cabinet (or
shelf), and mark the mounting location for the
top of the filter head. Make sure that there is
adequate space to avoid crimping the water line
flex hoses. Also make sure your chosen location
offers easy access for future cartridge changes.
b) Horizontal Position Measure 460mm
horizontally, and mark the mounting location
for the side of the filter head and end of the
filter cartridge. Make sure that there is adequate
space to avoid crimping the water line flex
hoses. Also make sure your chosen location
offers easy access for future cartridge changes.
4. Important - If necessary you can easily change
the direction of the flow of water through
the inlet and outlet of the filter system. You
will notice on the head assembly that the inlet
is shown by the word “IN” and the outlet is
shown by the word “OUT”. To change direction,
simply remove the four (4) screws that hold
the mounting bracket to the head assembly
and replace/refit the mounting bracket in the
opposite direction. This allows flexibility when
choosing the desired location for your filter
system.
a) Apply plumbing tape to the Pex Hose 3/8” male
connection (item 3). Wrap tape in direction of the
thread to ensure a tight fit and avoid leaks. Screw
this connection to the inlet side of the filter head
assembly (item 4). Repeat same for the Pex Hose
(Item 6) on the outlet side of the Head Assembly
(Item 4)
b) Securely mount the Filter Head Assembly
(item 4) on the cabinet wall using two of the
mounting screws (item 9) provided.
5. Connect Dual Check Valve – (item 2)
IMPORTANT – It is a legal requirement under
Australian Plumbing Standards that the Dual
Check Valve be installed. If this part is not
installed all warranties are null and void.
a) Apply plumbing tape to the 1/2” male
connection on the outlet of the existing cistern
tap. Wrap tape in direction of the threads to
ensure a tight fit and avoid leaks. Screw on the
Dual Check Valve (item 2) and secure.
6. Attach Pex Hose (item 3)
Connect the 1
/2” female end of the Pex Hose (item
3) to the 1
/2” male end of Dual Check Valve.
7. Install the Filter Tap (refer diagram)
Assemble and mount the tap. Tighten locking
nut beneath the sink to secure the tap firmly in
position. If a hole for the filter tap is not provided,
then use a drill or hole cutter to cut a 12.7mm (1
/2”)
hole in the sink or counter top where the tap is to
be located.
Please ensure that you use plumbing tape when
connecting the chrome brass adaptor to the
bottom of the filter tap.
8. Attach Filtered Water to Cold Water Line of
Filter Tap
Take the braided pex hose from the outlet of the
head assembly and connect to the chrome brass
adaptor at the bottom of the filter tap.
9. Flush the Filter Cartridge
a) Turn water supply back on at either the mains
or at the cold water mini cistern tap.
b) At this stage check for leaks and fix if necessary
c) Turn kitchen tap on and flush the filter
cartridge for at least 2–3 minutes. Collect
water in container and use for garden etc.
NOTE – Flushing the filter cartridge is important to
remove air from the system and any loose carbon
powder. At first the water may appear cloudy due
to compressed trapped air in the filter and hoses.
However the cloudiness will disappear over time
and with use.
10. Installing the Filter Monitor Alarm (item 8)
The filter monitor alarm (item 8) is supplied to
assist you with knowing when it is time to replace
your filter cartridge. Regular annual cartridge
replacement ensures that your filter system is
maintained in accordance with the manufacturers
recommendations.
a) Remove plastic wrapper from monitor and
remove installation instructions.
b) On the back of the monitor - pull the tab back.
c) The LED and buzzer will cycle 3 times to
confirm the start.
d) It is programmed to flash and sound again in
11 months.
e) Remove the two adhesive tapes from the
back of the monitor and locate/mount in a
convenient location under your kitchen sink.
NOTES
1) This installation must comply with all
applicable state and local regulations.
2) Do not use with water that is
microbiologically unsafe or of an unknown
quality without disinfection before or after
the system.
3) When storing filtered water in a refrigerator
please ensure the container has an air tight
seal / lid.
Tasman Sinkware warrants to you, the first person
who has purchased and used the unit (“you”) that
this unit is free from defects due to faulty material and
workmanship in accordance with the conditions set out
in this document. This warranty is provided to you in
addition to your rights at law, including but not limited
to your rights under the Trade Practices Act 1074 (Cth)
and applicable legislation in your Australian State or
Territory.
What this warranty covers:
This warranty covers defects due to faulty material and
workmanship of the unit supplied to you:
• For a period of 6 years from the date of purchase in
respect of the entire unit, excluding the Replaceable
Elements. The Replaceable Elements are consumable
components and all parts of the unit which can be
replaced including but not limited to the filter or water
treatment cartridge if there is a defect in the filter or
cartridge. This does not include the replacement of
the filter or cartridge to extend the life of the filter or
cartridge. The life of the filter cartridge is affected by
water quality, usage and water pressure. The warranty
only extends to the original purchaser of the unit.
What this warranty does not cover:
This warranty does not cover the unit or a Replaceable
Element of the unit where:
• The defect, fault or failure is attributable, or
substantially attributable to misuse, abuse, accident,
misapplication, neglect, freezing, oxidizing agents
(including but not limited to chlorine, ozone,
chloramines and other related components) or act of
God;
• The unit has been in conditions which do not conform
to the recommended design guidelines or has been
operated in a manner which is contrary to Tasman
Sinkware’s printed instructions;
PRODUCT
SPECIFICATION
• Usage: For mains cold
water only.
• Temperature Range: 2-38oC
• Min.-Max. Working
Pressure:10-125 psi
(0.7-8.6 bar)
• Service Flow Rate:
0–3 Litres per minute*
• Capacity: 9,450 litres*
• Rating: 1 micron
• Removes/Reduces:
Chlorine, cysts, giardia,
cryptosporidium, bad taste
and odours, and all particles
down to 1 micron in size
• This filter does not remove
fluoride
• Filter Change: Annually or
sooner if flow rate becomes
inconveniently slow.
• The unit has not been installed in accordance with
Tasman Sinkware’s printed instructions and has not
been installed in compliance with all applicable laws,
regulations and industry standards;
• The unit has not been used in accordance with the
manufacturer’s instructions;
• The unit does not meet the conditions for use
described in the owner’s manual or performance data
sheet for this unit
• You use accessories or components which do not
meet Tasman Sinkware’s specifications as set out in the
Owners Manual;
• The defect, fault or failure is due to normal wear and
tear;
• The defect, fault or failure has occurred where the unit
has been used reasonably or has reached its serviceable
life;
• The serial or model number label of the unit is
removed or defaced;
• The unit is serviced, modified, altered or repaired
by an unauthorized or unqualified person;
How to make a claim under this warranty:
To make a claim under this warranty you must contact
Tasman Sinkware within 21 days of the defect, fault or
failure occurring. Tasman Sinkware’s Warranty Contact
number is 1300 13 7465. At the time of repair or
replacement under your warranty claim you must provide
to Tasman Sinkware:
• Proof that you purchased the unit from an authorized
retailer or dealer within the warranty time; and
• A copy of a certificate which certifies that the unit was
installed in compliance with our printed installation
instructions and all applicable laws, regulations and
industry standards. Tasman Sinkware will only pay for
repair or replacement upon receipt of proof of your
purchase showing the date of purchase.
Limitation of Liability of Tasman Sinkware under
this warranty: Where a warranty exists or is implied by
law, Tasman Sinkware liability is limited (to the extent
that it can be limited) to repair or replacement of the
faulty Replaceable Element or the unit or an equivalent
unit. Tasman Sinkware may, in its discretion, choose
whether it shall repair or replace any unit or Replaceable
Element or Tasman Sinkware may choose to pay to you
the cost of replacing the Replaceable Element or the unit
or the cost of having the unit repaired. To the extent
permitted by law, Tasman Sinkware assumes no liability
whatsoever and disclaims all liability for direct, indirect or
consequential loss, or special, general or other damage
or expense caused by or arising out of:
• Any failure to install or use the unit in accordance
with the Manufacturer’s Instructions, the Installation
and Operating manual or Tasman Sinkware’s printed
instructions; or
• The purpose for which you are purchasing the unit.
You acknowledge that the quality of water supplied and
your water usage rate and influent water pressure may
vary seasonally or over a period of time.
In addition to this water characteristics can differ if the
unit is relocated or the environment changes.
You acknowledge that Tasman Sinkware does not know
your requirements and cannot and does not warrant that
the unit is fit for the purpose for which you intend to
use the unit or is appropriate for the purpose for which
you intend to use the unit. Tasman Sinkware does not
authorize others to assume any obligation on its behalf
even if you inform them of the purpose for which you
intend to use this unit.
WARNING Tasman Sinkware does not recommend
making alterations to your existing plumbing to
accommodate this filter system. If you wish to modify
existing plumbing you must comply with AS 3500 and
use a licensed plumber. Where internal water pressure
exceeds 860 kPa a Watermark approved Pressure
Limiting Valve must be installed prior to the filter system.
WARNING The contaminants or other substances
removed or reduced by this water treatment system are
not necessarily in your water supply. Do not use with
water that is microbiologically unsafe or of an unknown
quality without disinfection before or after the system.
IMPORTANT This filter is designed to be used with
mains/city water supplies.
CAUTION Safely isolate the water supply prior to
installing the filter system to avoid injury and
property damage.
Our goods come with guarentees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have
all the goods repaired or replaced if the good fails to be
of acceptable quality and the failure does not amount to
a major failure.
Refer to oliveri.com.au for warranty details.
Product Specifications: The unit must only be used for a portable
water source and with cold water (with a temperature range
between 2 and 38° C).
FS7025, FS7075, FS7005
WARRANTY
(1) Cistern Tap 1
/2” fbsp x 1
/2” mbsp
(2) Dual Check Valve 1
/ ”2 fbsp x 1
/ ”2 mbsp
(3) Pex Hose 750mm
(4) Head Assembly
(5) Filter Cartridge
(6) Pex Hose 550mm
(7) Filter tap
(8) Filter Monitor Alarm
(9) Mounting Screws
Hot Water Line
Filtered
cold
water
Cold
Water
Line
FILTER ALARM
4
3
2
1
5
6
8
9
7
* Subject to water quality and usage
TO FILTER
TO MIXER
EXISTING COLD
WATER CISTERN TAP
2
1
CONNECTION DIAGRAM
TAP INSTALL DIAGRAM
RUBBER WASHER
PLASTIC WASHER
LOCKING WASHER
NUT
CHROME BRASS ADAPTOR
Owners Manual
Produktspezifikationen
| Marke: | Oliveri |
| Kategorie: | Wasserfilter |
| Modell: | FS7025 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Oliveri FS7025 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Wasserfilter Oliveri
31 August 2024
15 April 2024
Bedienungsanleitung Wasserfilter
- Wasserfilter Philips
- Wasserfilter Verbatim
- Wasserfilter Sunbeam
- Wasserfilter Panasonic
- Wasserfilter LG
- Wasserfilter AEG
- Wasserfilter Electrolux
- Wasserfilter Jata
- Wasserfilter Tefal
- Wasserfilter Eldom
- Wasserfilter Smeg
- Wasserfilter Solac
- Wasserfilter GE
- Wasserfilter Haier
- Wasserfilter Bartscher
- Wasserfilter Midea
- Wasserfilter Zanussi
- Wasserfilter Eheim
- Wasserfilter JBL
- Wasserfilter Laica
- Wasserfilter Terraillon
- Wasserfilter Jura
- Wasserfilter Franke
- Wasserfilter Ufesa
- Wasserfilter Imetec
- Wasserfilter Fluval
- Wasserfilter Juwel
- Wasserfilter Grohe
- Wasserfilter Brita
- Wasserfilter EcoWater
- Wasserfilter Aarke
- Wasserfilter Breville
- Wasserfilter Kent
- Wasserfilter Eden
- Wasserfilter Fisher & Paykel
- Wasserfilter BWT
- Wasserfilter Katadyn
- Wasserfilter Oase
- Wasserfilter Zodiac
- Wasserfilter AstralPool
- Wasserfilter T.I.P.
- Wasserfilter Avanti
- Wasserfilter Everpure
- Wasserfilter Baracuda
- Wasserfilter Pureit
- Wasserfilter Flama
- Wasserfilter MSR
- Wasserfilter Ionmax
- Wasserfilter Waterdrop
- Wasserfilter Aquasure
- Wasserfilter Consul
- Wasserfilter Fiap
- Wasserfilter Waterco
- Wasserfilter LifeStraw
- Wasserfilter PUR
- Wasserfilter Sera
- Wasserfilter Tunze
- Wasserfilter Zip
- Wasserfilter Aqua Medic
- Wasserfilter Billi
- Wasserfilter ZeroWater
- Wasserfilter Beemur
- Wasserfilter Puretec
- Wasserfilter Hydor
- Wasserfilter Aquael
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
15 Oktober 2024
15 Oktober 2024
15 Oktober 2024
24 September 2024
24 September 2024
24 September 2024
24 September 2024
18 September 2024
12 September 2024
