Seite 1/2

NAC3PX-TOP

NAC3MPX-TOP

NAC3MPX-WOT-TOP

NAC3FPX-TOP

NAC3FPX-WOT-TOP

NAC3FPX-ST-TOP

Power IN

Power OUT

NAC3FX-W-TOP

(Connector)

NAC3MX-W-TOP

(Plug connector)

-w

P S

JET

-w

P S

JET

250

JET

250

NAC 3M X-W

250

JET

250

NAC 3M X-W

NAC3FX-W-TOP

(Connector)

NAC3MX-W-TOP

(Plug connector)

Power IN

CONNECTOR ASSIGNMENT:

APPLIANCE INLET APPLIANCE OUTLET APPLIANCE INLET / OUTLET

uCombination

40 - 50 mm

250

JET

250

P S

JET

ASSEMBLY INSTRUCTION

NAC3FX-W-TOP power TRU 1CON E TOP

|®

A. APPLICATION INSTRUCTION

B. ASSEMBLY INSTRUCTION

[0.32"]

8 mm

[ ”]0.787

2 mm0

[ ”]0.9

PE 23 mm

Separate the

housing from the

bushing (cable

remain in bushing)

Approval based:

Rating:

Cable Type:

Strain Relief:

Cable O.D.:

VDE

EN 60320-1/EN60320-2-2

250 V ac / 16 A

H05VV-F3G 1.0 mm , Length max. 2 m

H05VV-F3G 1.5 - 2.5 mm2

H07RN-F3G 1.5 mm2

White chuck

6.0 - 12.0 mm

UL 498 / CSA C22.2 No. 182.3

250 V ac / 20 A

SJTOW, SJOOW 3 x 12 AWG

White chuck

6.0 - 12.0 mm

VDE (EN 60320-1/EN60320-2-2) UL (UL 498 / CSA C22.2 No. 182.3)

Place chuck over the

cable.

Prepare cable as

shown.

Page 1BDA 541

Application:

The power TRUE1 system is certified as connector with breaking cap ity accordingCON a ac

0625. an appliance coupler and interconnection coupler.IEC 60320, VDE It is intended for use as

anIt serves to supply power to appliance and from an appliance to other equipment.

To be installed by qualified person only.

Recommendation:

Wire Pulling Lubricant - LUB-I/0.95

from 3MT M

AInsert cable into the bushing and housing.

Note: “Apply cable pulling

lubricant to cable jacket.”

[0.32"]

8 mm

[ ”]0.787

2 mm0

[ ”]0.9

PE 23 mm

power TRUE1 TOP line is full backward compatible with the preceding power TRUE1 products.CON CON

UL50E environmental rating

Enclosure Type 4 when mated with attachment plug NAC3MX-W-TOP or mated with appliance inlet

NAC3MPX*-TOP with sealing cover SCNAC-MPX and NAC3PX-TOP with sealing cover SCNAC-PX.

-w

250

P S

JET

-w

250

P S

JET

ASSEMBLY INSTRUCTION powerCON TRUE1 TOP

Page 2

Slide the cable into the contacts and clamp with

the screw with Torx size T8.

VDE ULWiring

blackLbrownÞ

whiteNblueÞ

green/yellow greenÞ

Slide intochuck onto insert (1) and then both

housing .(2)

Important: Align the chuck by positioning the

nose into keyway.

Slide the bushing up the cablecable clamp (3)

and with the tool (4) as shown (5).tighten it

Important: Black O-ring to hide to achieve IP

protection (6).

(Tool available: Art. No. HTAC)

-w

Torque Value 0.7 Nm

Torx size

www.neutrik.com

Find more details of power TRUE1 TOP on www.neutrik.com.CON

Important:

Push and turn simultaneously.

Draft. Nr.: BDA 541 Update: .20111.07 8

I I

Neutrik AG LI T: +423 / 237 24 24 F: +423 232 53 93/

Neutrik USA Inc. USA T: +1 704 / 972 3050 F: +1 704 438 9202/

Neutrik ( )

UK Ltd. UK T: +44 1983 / 811 441 F: +44 1983 811 439/

Neutrik Vertriebs GmbH DE / NL / AT/DK T: +49 8131 / 280 890 F: +49 8131 280 830/

Neutrik France FR T: +33 1 4131 6750 F: +33 1 4131 0511/ /

Neutrik Tokyo Ltd. JP T: +81 3 3663 4733 F: +81 3 3663 4796/ /

Neutrik Hong Kong Ltd. HK T: +852 2687 6055 F: +852 2687 6052/ /

Neutrik India Pvt. Ltd. IND T: + F: +91 22 26163 54091/ 982 05 43 424 /

Data subject to change without prior notice. 201 NEUTRIK ALL RIGHTS RESERVED8 . NEUTRIK are registered trademark of NEUTRI AG. .© ® ®

JET

CAUTION

To ensure protection

category, do not expose the

connection to bending forces

(e.g. do not attach loads to

the cable, no free-dangling

cable windings etc.).

FORCE

SAFETY WARNING

For safety and certification reasons the connector must be

replaced in case of any broken parts or .excessive wear and tear

FOR DISASSEMBLY - OPEN TWIST LOCK!

1. Press with screw driver to unlock

Turn bushing 360°.2.

Repat step 1 + 2 until bushing is unscrewed.3.

Torque Value 2.0 Nm

PRESS FIRMLY

Wrench size

13 mm

Produktspezifikationen

Marke:	Neutrik
Kategorie:	Wandsteckdose
Modell:	NAC3FX-W-TOP
Produktfarbe:	Black, White
Internationale Schutzart (IP-Code):	IP65
Material:	Bronze, Polyacetal resin, Polyamide
Stecker:	CuSn0.2
Betriebstemperatur:	-30 - 80 °C
Zertifizierung:	UL498, ENEC, IEC
Menge pro Packung:	1 Stück(e)
Stromstärke:	16 A
Spannung:	250 V
AWG Kabelgröße:	12
Außendurchmesser:	12 mm
Kerngröße:	2.5 mm²
Abschirmung Steckverbinder:	Ja
Durchschlagfestigkeit:	4 V
Kontaktwiderstand:	3 mΩ
Lebensdauer (Zyklen):	5000
Material Ummantelung:	Polyoxymethylen (POM)
Material Verriegelungselement:	Zink
