December 2023
BE18400 Tri-Band PoE 10G Insight Managed
WiFi 7 Access Point
Model WBE758
Installation Guide
Access Point Model WBE758
Package contents Overview Step 1: Connect the WBE758 to your network
Mount plate
1
Status LED
Port cover (comes attached)
Shallow clip
The AP is designed to use a PoE cable for power and Internet, but you can use a separately
purchased 12V (3.5A) power adapter and Ethernet cable:
• Use a PoE cable: Connect one end of an Ethernet cable to the LAN/PoE port of the AP and
connect the other end to a PoE++ switch port that supplies 802.3bt PoE++ power. Make
sure that the switch has Internet connectivity.
• Use a 12V (3.5A) power adapter: Connect the power adapter’s DC plug to the AP, and
insert the power adapter in a power outlet.
Next, connect one end of an Ethernet cable to the LAN/PoE port of the AP, and connect the
other end to a port on a switch or router with an Internet connection.
The power LED on the AP lights. For more Information, see the table with LED information.
The AP receives an IP address from a DHCP server (usually a router in your network). If your
network does not include a DHCP server, the AP uses its default IP address: 192.168.0.100.
Solid amber: The AP is starting or the Reset button was pressed.
Slow blinking amber: The Internet connection is in the process of being set up.
Fast blinking amber:ThermwareisbeingupdatedortheAPisintheprocessof
being reset to factory defaults because the Reset button was pressed.
Solid green: The AP is functioning in standalone mode or is not connected to Insight.
Slow blinking green:Insufcientpower(below802.3bt).
Solid blue : The AP is functioning in Insight mode, and is connected to Insight.
2.5G
10G
10G
2.5G2.5G
Router
Sample connections
Internet
PoE++ switch
(MS510TXUP)
WBE758
WiFi clients
Insight cloud
WAX630
WiFi 6 AP
WAX610Y
WiFi 6
outdoor AP
Surge
protectors
Dual core
uplinks
BeforeyouinstalltheWBE758accesspoint(AP)atitspermanentlocation,rsttesttheAPby
connecting it to your network and powering it up.
After starting up and during setup, the LED can light in these colors:
1
2
3
4
Continue to step 2 on the back page
Deep clip
NOTE: Other LED behavior exists, including LED behavior for an Insight Instant Mesh
network. For more information about the LED behavior, see the user manual, which you
can download by visiting netgear.com/support/download.
CAUTION: After you are done testing the AP, power off the AP and let it cool down for
10 minutes before you mount it at its permanent location.
CAUTION: Terms of Use
This device must be professionally installed. It is the installer’s responsibility to follow local
country regulations including operations within legal frequency channels, output power
and DFS requirements. Vendor or Reseller or Distributor is not responsible for illegal
wireless operations. Please see Device’s Terms and Conditions for more details.
NOTE: The multiple mounting options for the AP are described in the NETGEAR Pro WiFi
Mount Installation Guide, which you can download from netgear.com/support/download.
Visit netgear.com/support to get your questions answered and access the latest downloads.
You can also check out our NETGEAR Community for helpful advice at
community.netgear.com.
Support and Community
Si ce produit est vendu au Canada, vous pouvez accÊder à ce document en français canadien à
https://www.netgear.com/support/download/.
(If this product is sold in Canada, you can access this document in Canadian French at
https://www.netgear.com/support/download/.)
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy.
By using this device, you are agreeing to NETGEAR’s Terms and Conditions at
https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the device to
your place of purchase within your return period.
Do not use this device outdoors. The PoE source is intended for intra building connection only.
Applicable to 6 GHz devices only: Only use the device indoors. The operation of 6 GHz devices
is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device
ispermittedinlargeaircraftwhileyingabove10,000feet.Operationoftransmittersinthe
5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft
systems.
Regulatory and Legal
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
Š NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR
trademarks are used for reference purposes only.
NETGEAR INTERNATIONAL LTD
Floor 6, Penrose Two
Penrose Dock, Cork, T23 YY09, Ireland
Step 2. Access and manage the AP
Your new AP supports the NETGEAR Insight cloud-based management platform for remote
management.Insightoffersautomatedmonitoringandnotications,plusadd-onserviceslike
Insight Instant Mesh that are not available in standalone mode. Alternatively, you can manage
the AP locally in standalone mode through the device UI.
For information about creating an Insight Premium account or Insight Pro account, visit
kb.netgear.com/000044343. Your my.NETGEAR.com account is also your Insight account,
so your credentials let you log into the Insight Cloud Portal or the Insight app. For more
information, visit the following pages:
• netgear.com/business/services/insight
• kb.netgear.com/000061848
To manage the AP, use one of the methods in this table:
A. Insight Cloud Portal
remote management
NETGEAR Insight Cloud Portal
See A. Use the NETGEAR Insight Cloud Portal to manage the AP
B. Insight app
remote management
NETGEAR Insight app
See B. Use the NETGEAR Insight app to manage the AP
C. Standalone
local management
Web browser
See C. Use a web browser to manage the AP in standalone mode
A. Use the NETGEAR Insight Cloud Portal to manage the AP
The Insight Cloud Portal provides access to a complete set of remote management tools,
including the topology view. For Insight Pro users, it offers a quick way to add multiple APs at the
same time.
1. Make sure that the AP is connected to the Internet.
2. On a computer or tablet, visit insight.netgear.com.
3. Enter the email address and password for your NETGEAR account and click the NETGEAR
Sign In button.
4. If you are an Insight Pro user, select the organization to which you want to add the AP.
5. Add a new network location where you want to add the AP, or select an existing network
location.
The device admin password that you set for the network location replaces the existing
admin password on all devices that you add to the network location.
6. Click the ( ) button.+ Add Device
NOTE: If you are an Insight Pro user, you can either add a single device or you can add
multipleInsight-manageddevicesbyuploadingadevicelistinaCSVle.
7. In the Add New Device pop-up page, enter the AP’s serial number and MAC address, then
click .Go
8. Optionally change the device name of the AP, then click Next.
Apagedisplaysaconrmationthatsetupisinprogress.
NOTE: IftheAPisonlinebutInsightdoesnotdetecttheAP,therewallatthephysical
location where the AP is located might prevent communication with the Insight cloud.
Inthatsituation,addportandDNSentriesforoutboundaccesstotherewall.Formore
information, see kb.netgear.com/000062467.
TheAPautomaticallyupdatestothelatestInsightrmwareandInsightlocation
conguration.Thismighttakeupto10minutes,duringwhichtimetheAPwillrestart.
The LED lights solid blue when the AP is connected to Insight. The AP is now an Insight
managed device that is connected to the Insight cloud-based management platform.
B. Use the NETGEAR Insight app to manage the AP
TheInsightappprovidesaconvenientwaytoaddnewdevices,receivereal-timenotications,
and manage your network from anywhere.
1. Connect your mobile device to the AP’s setup SSID (WiFi network name) using one of these
methods:
• Scan the QR code: Scan the QR code on the AP label to connect to the setup SSID.
• Connect manually: The setup SSID is on the AP label and is shown in the format
NETGEARxxxxxx-SETUP, where xxxxxx are the last six digits of the AP’s MAC address.
The default WiFi passphrase is sharedsecret.
2. Open the NETGEAR Insight app.
3. Enter the email address and password for your account and tap LOG IN.
4. Select a network location, or add a new network location where you want to add the AP by
tapping the Next button OK and then tapping .
The device admin password that you set for the network location replaces the existing
admin password on all devices that you add to the network location.
In most situations, Insight detects the AP automatically, which can take several minutes.
5. To add the AP to your network location, do one of the following:
• If the AP is automatically detected and listed in the Insight Manageable Devices section,
tap the icon for the AP, and then tap the button.ADD DEVICE
• If the AP is not automatically detected, or you prefer to use another method to add the
AP, tap the icon in the top bar, and do one of the following:+
-Tap the SCAN BARCODE OR QR CODE button, and then scan the AP’s code.
-Tap the Enter Serial Number and MAC Address link, and then manually enter the
AP’s serial number and MAC address.
6. If prompted, name the AP and tap the Next button.
TheAPautomaticallyupdatestothelatestInsightrmwareandInsightlocation
conguration.Thismighttakeupto10minutes,duringwhichtimetheAPwillrestart.
The LED lights solid blue when the AP is connected to Insight. The AP is now an Insight
managed device that is connected to the Insight cloud-based management platform.
C. Use a web browser to manage the AP in standalone mode
1. Connect your computer or mobile device to the AP’s setup SSID (WiFi network name) using
one of the following methods:
• Scan the QR code: Scan the QR code on the AP label to connect to the setup SSID.
• Connect manually: The setup SSID is on the AP label and is shown in the format
NETGEARxxxxxx-SETUP, where xxxxxx are the last six digits of the AP’s MAC address.
The default WiFi passphrase is sharedsecret.
2. On your computer, launch a web browser and, in the address bar, enter .aplogin.net
Yourbrowsermightdisplayasecuritywarningbecauseoftheself-signedcerticateon
the AP, which is expected behavior. You can proceed, or add an exception for the security
warning. For more information, see kb.netgear.com/000062980.
3. Enter the AP user name and default password. The user name is admin. The default
password is password. The user name and password are case-sensitive.
4. Select the Web-browser (Local) radio button.
The Day Zero Easy Setup page displays.
5. Follow the instructions on the Day Zero Easy Setup page, and then click the button.Apply
We recommend that you make a note of the new admin password, SSID (WiFi network
name), WiFi passphrase, and IP address to keep in a safe place.
A message displays to indicate that your settings are being applied.
6. If the WiFi connection of your computer or mobile device is terminated, reconnect to the AP
using the new SSID and WiFi passphrase that you set on the Day Zero Easy Setup page.
7. When the login page displays, you can log in to the AP using your new admin password to
conguretheAP.
ForinformationaboutconguringtheAP,seetheusermanual,whichyoucandownloadby
visiting netgear.com/support/download.
We recommend that you register your AP with NETGEAR.
8. To register your AP with NETGEAR, from a computer or mobile device that is connected
to the Internet, visit my.NETGEAR.com to log in or create a new account, then click the
Register New Product button to register your AP.
AconrmationemailissenttoyourNETGEARaccountemailaddress.
CAUTION: IfyouaddtheAPtoInsightbeforeconnectingittopowerforthersttime,
wait 10 minutes to allow the default login credentials to be replaced by the Insight
network location credentials. However, if you want to manage the AP as a standalone
device,donotaddtheAPtoInsightbeforeconnectingittopowerforthersttime.You
canalwaysaddtheAPtoInsightafterinitialconguration.

Produktspezifikationen

Marke: Netgear
Kategorie: Nicht kategorisiert
Modell: WBE758

Brauchst du Hilfe?

Wenn Sie Hilfe mit Netgear WBE758 benĂśtigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Nicht kategorisiert Netgear

Netgear

Netgear ProSafe AX743 Bedienungsanleitung

6 Oktober 2024
Netgear

Netgear JGS516 Bedienungsanleitung

4 Oktober 2024
Netgear

Netgear XS508M Bedienungsanleitung

2 Oktober 2024
Netgear

Netgear GS108Ev4 Bedienungsanleitung

1 Oktober 2024
Netgear

Netgear ProSafe AXM762 Bedienungsanleitung

1 Oktober 2024
Netgear

Netgear VPN01L Bedienungsanleitung

28 September 2024
Netgear

Netgear Orbi RBE972SB Bedienungsanleitung

26 September 2024
Netgear

Netgear Orbi RBK652S Bedienungsanleitung

25 September 2024
Netgear

Netgear Nighthawk MS90 Bedienungsanleitung

25 September 2024
Netgear

Netgear ProSafe AX745 Bedienungsanleitung

23 September 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung fĂźr -Kategorien-

DAS Audio

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024
Ferplast

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024
AEG

AEG MECK52 Bedienungsanleitung

16 Oktober 2024
Makita

Makita UR012G Bedienungsanleitung

16 Oktober 2024
Stihl

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024
Ernesto

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024
IFM

IFM AC901S Bedienungsanleitung

16 Oktober 2024
Nedis

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024
AEG

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024
ART

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
