Seite 1/6
Cardioid Pattern Tube Microphone
Marshall Electronics
Professional Audio Division, El Segundo, CA
Phone: (310) 333-0606 (800) 800-6608 Fax: (310) 333-0688
www.mxlmics.com www.mogamicable.com sales@mxlmics.com
SOLO
User Manual
SOLO
Warranty
Marshall microphones are guaranteed against defects in material and workmanship for three
years (except tube which is 90 days) from date of purchase. Should you encounter any problem
with this unit, promptly contact the company you purchased it from for assistance. The original
dated sales receipt will be necessary for any warranty claim. Do not send any unit directly to us
without prior authorization from our service department!
Warranty coverage is limited to repair or replacement (at our option) of the microphone, and
does not cover incidental damages due to use of this unit, nor damage caused by accidental
misuse of this product.
Marshall Electronics
User Manual
SOLO
Revelation Solo Features
Carefully unpack your MXL Revelation Solo Cardioid Pattern Tube microphone to verify that
all of the components are included. Your MXL Revelation Solo includes the following:
• Revelation Solo Microphone
• 15ft 7-pin Mogami® cable
• 15ft XLR Mogami® microphone cable
• Revelation Solo power supply
• Shockmount
• Aluminum flight case
• Cleaning cloth
If any of the above items are missing or damaged, contact the company you purchased
it from for assistance.
Power Requirements
The MXL Revelation Solo uses an EF86 tube that requires a dedicated power sup-
ply unit (included with your microphone). Even if your mixer has phantom power, it is
recommended that you defeat the phantom power as a precautionary measure when it
is not needed to power other mics that you might also be using.
This supply is switchable between 110 volts and 220 volts AC. In North America, the
microphone ships in the 110 volts AC position and in the 220 Volts AC position for
export. However, you always want to ensure that the power supply voltage is correctly
set for your local voltage as permanent damage to the microphone and/or power supply
may occur if the incorrect voltage setting is selected. Every Marshall Electronics MXL
microphone has been thoroughly checked before shipping; so if you do not hear sound,
check that the power supply is switched on.
Caution
Do not “hot plug” the mic. Always ensure that the power supply is off when plugging
and unplugging the included 7-pin cable from the microphone to avoid damaging the
microphone and power supply.
Bass Roll-off Switch
Cardioid Pattern Tube Condenser
Type: Microphone
Diaphragm: 6 micron diaphragm
Tube Type: EF86
Frequency Range: 20 Hz-20 kHz
Polar Pattern: Cardioid
Sensitivity: -40 dB re 1 V/Pa
Impedance: 140 ohms
Pre-Attenuation Switch: 0 dB, -10 dB
S/N Ratio: 76 dB
Equivalent Noise Level: 18dBA (A-weighted IEC 651)
Max SPL for 0.5% THD: 138 dB SPL
High Pass Filter: 12 dB/octave @ 125Hz
Revelation Power Supply Unit
Power Requirements: 110/220 VAC, 50/60Hz
Size: 7 1/2” X 2 1/2” (mic only)
Weight: 2lbs (mic only)
Metal Finish: Dark Violet and Chrome
Specifications
