Audio Zone Amplifier
2 x 20 watts
Installation Guide
500 162
© MuxLab Inc. 2015 - - - -A 94 000805 A / SE 000805
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
• Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
• Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
• To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water. Keep the pro duct away from liquids.
• Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
• Using supplies or parts not meeting the product’s specifications may cause damage,
deterioration or malfunction.
• Refer all servicing to qualified service personnel.
• Install the device in a place with good ventilation to avoid damage due to
overheating.
• Unplug the power cord when left unused for a long period of time.
• Do not put any heavy items on the unit or on extension cable.
• Do not remove the housing of the device as you may be exposed to dangerous
voltage or other hazards.
• Information on disposal of devices: do not burn or mix with general household
waste, please treat them as normal electrical wastes.
• Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
• Please read this user manual carefully before using this product.
© MuxLab Inc. 2015 2
Contents
Introduction ............................................................................................................... 4 1.
1.1. Introduction to the 500216 ............................................................................. 4
1.2. Features ......................................................................................................... 4
1.3. Package Content ........................................................................................... 5
Specification .............................................................................................................. 6 2.
System Connection ................................................................................................... 7 3.
3.1. Safety Precautions ......................................................................................... 7
3.2. System Diagram ............................................................................................ 7
3.3. Audio Output .................................................................................................. 7
3.3.1. Default output: 2x20 Watt @ 4-ohm ..................................................... 7
3.3.2. Bridge connection: 1x40 Watt @ 8-ohm .............................................. 8
3.3.3. Dual -mono Output 8...............................................................................
3.4. Connection of Microphone ............................................................................. 9
3.4.1. 48V phantom power input mode .......................................................... 9
3.4.2. MIC input mode ................................................................................... 9
3.4.3. LINE input mode .................................................................................. 9
Operation of the Control Panel and the IR Remote ................................................. 10 4.
4.1. Operation of the Control Panel .................................................................... 10
4.1.1. Audio switching .................................................................................. 10
4.1.2. Volume and Equalization control ........................................................ 10
4.2. Using of the IR Remote ................................................................................ 11
4.2.1. IR Remote buttons ............................................................................. 11
4.2.2. IR Remote codes ............................................................................... 11
Operations of RS232 Control .................................................................................. 12 5.
5.1. RS232 Communication Commands ............................................................. 12
Panel Drawing ......................................................................................................... 13 6.
Troubleshooting & Maintenance .............................................................................. 14 7.
Regulatory Compliance ................................................................................................ 15
© MuxLab Inc. 2015 3
