Seite 1/8
2
SAFETY WARNINGS AND
SAFETY WARNINGS AND
SAFETY WARNINGS AND
SAFETY WARNINGS AND SAFETY WARNINGS AND GUIDELINES
GUIDELINES
GUIDELINES
GUIDELINESGUIDELINES
ï‚· Turn off and unplug all equipment prior to making electrical connections, including
speaker wire connections.
ï‚· Reduce the volume level prior to making any change to the audio input source, e.g.,
changing radio stations or changing CDs.
ï‚· Ensure that the speaker terminal cover is properly secured to maintain the IPX6
waterproof rating.
ï‚· When using this speaker as part of a constant voltage speaker system, ensure that
the amplifier power is at least 20% higher than the total power settings of the
connected speakers.
ï‚· Most speaker damage is caused by clipping, which is heard as distortion. If you hear
distortion, reduce the volume level until the audio is no longer distorted.
ï‚· Take care to ensure that the speaker wire connections are properly polarized.
Inverted polarization can result in unnatural or attenuated sound, especially in the
bass frequencies.
ï‚· Do not use chemical cleaners or solvents to clean this speaker. Use only a soft, dry
cloth. Moisten the cloth with warm water for particularly stubborn deposits.
INTRODUCTION
INTRODUCTION
INTRODUCTION
INTRODUCTION INTRODUCTION
Thank you for purchasing this Outdoor Horn Speaker!
This high fidelity horn speaker features a 90Hz to 20kHz frequency response and 99dB SPL.
It carries an IPX6 ingress protection rating, making it safe for use in all weather conditions.
Featuring a built-in step-down transformer with three taps, it can be installed as part of a
70V or 100V constant voltage speaker array.
3
FEATURES
FEATURES
FEATURES
FEATURES FEATURES
ï‚· All weather outdoor speaker with an IPX6 ingress protection rating
ï‚· 90Hz ~ 20kHz frequency response
ï‚· 116dB sound pressure level
ï‚· Built-in step-down transformer for use in a 70V or 100V constant voltage speaker
array
ï‚· Handles up to 50-watts of power
ï‚· Includes mounting bracket
PACKAGE CONTENTS
PACKAGE CONTENTS
PACKAGE CONTENTS
PACKAGE CONTENTSPACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below.
1x Outdoor horn speaker with mounting bracket
1x User's manual
CONSTANT VOLTAGE V
CONSTANT VOLTAGE V
CONSTANT VOLTAGE V
CONSTANT VOLTAGE VCONSTANT VOLTAGE VS 8-OHM SPEAKER SY
S 8-OHM SPEAKER SY
S 8-OHM SPEAKER SY
S 8-OHM SPEAKER SYS 8-OHM SPEAKER SYSTEMS
STEMS
STEMS
STEMS STEMS
A constant voltage speaker system differs from a traditional 8-ohm speaker system in that
it uses a step-up transformer at the audio source to raise the voltage and lower the current
on the transmission line. At the speaker end, a step-down transformer converts the signal
back to a normal speaker level voltage. This reduces power loss during transmission, which
allows for the use of longer speaker wire runs using smaller gauge wire.
Additionally, a constant voltage speaker system allows for the use of multiple speakers on
each channel, without the need for complicated impedance calculations and
configurations. In a constant voltage system, all speakers on a given channel are connected
in parallel and the complicated impedance calculations are replaced by simple wattage
calculations.
