OPERATOR'S MANUAL

MANUEL de L'UTILISATEUR

MANUAL del OPERADOR

TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND OPERATOR'S

MANUAL.

AFIN DE RÉDUIRE LE RISQUE DE BLESSURES, L'UTILISATEUR DOIT LIRE ET BIEN

COMPRENDRE LE MANUEL DE L'UTILISATEUR.

PARA REDUCIR EL RIESGO DE LESIONES, EL USUARIO DEBE LEER Y ENTENDER EL

MANUAL DEL OPERADOR.

M12™ CORDLESS PROPEX™ EXPANSION TOOL

ÉLARGISSEUR PROPEX™ M12™

HERRAMIENTA PARA EXPANSIÓN M12™ PROPEX™

Cat. No.

No de cat.

2432-20

PERSONAL SAFETY

GENERAL POWER TOOL SAFETY WARNINGS

WORK AREA SAFETY

ELECTRICAL SAFETY

• Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

• Do not operate power tools in explosive atmo-

spheres, such as in the presence of ﬂ ammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

• Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiﬁ ed plugs and matching outlets will

reduce risk of electric shock.

• Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and

refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Do not expose power tools to rain or wet condi-

tions. Water entering a power tool will increase

the risk of electric shock.

• Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

• When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use

of a cord suitable for outdoor use reduces the risk

of electric shock.

• If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

• Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may

result in personal injury.

• Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves

away from moving parts. Loose clothes, jewel-

lery or long hair can be caught in moving parts.

• If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used. Use of

dust collection can reduce dust-related hazards.

WARNING READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS.

Failure to follow the warnings and instructions may result in electric shock, ﬁ re and/or

serious injury. Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or

battery-operated (cordless) power tool.

POWER TOOL USE AND CARE

• Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the

rate for which it was designed.

• Do not use the power tool if the switch does not

turn it on and o. Any power tool that cannot be

controlled with the switch is dangerous and must

be repaired.

• Disconnect the plug from the power source

and/or the battery pack from the power tool

before making any adjustments, changing

accessories, or storing power tools. Such

preventive safety measures reduce the risk of

starting the power tool accidentally.

• Store idle power tools out of the reach of chil-

dren and do not allow persons unfamiliar with

the power tool or these instructions to operate

the power tool. Power tools are dangerous in the

hands of untrained users.

• Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts

and any other condition that may affect the

power tool’s operation. If damaged, have the

power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

• Use the power tool, accessories and tool bits

etc., in accordance with these instructions,

taking into account the working conditions and

the work to be performed. Use of the power tool

for operations dierent from those intended could

result in a hazardous situation.

• Stay alert, watch what you are doing and use

common sense when operating a power tool. Do

not use a power tool while you are tired or under

the inﬂ uence of drugs, alcohol or medication. A

moment of inattention while operating power tools

may result in serious personal injury.

• Use personal protective equipment. Always

wear eye protection. Protective equipment such

as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions

will reduce personal injuries.

• Prevent unintentional starting. Ensure the

switch is in the o-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

your ﬁ nger on the switch or energising power tools

that have the switch on invites accidents.

• Recharge only with the charger speciﬁ ed by

the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of ﬁ re

when used with another battery pack.

BATTERY TOOL USE AND CARE

FUNCTIONAL DESCRIPTION

SYMBOLOGY

SPECIFICATIONS

Cat. No. Volts DC Max PEX-A Diameter Expander Heads Lubricant

2432-20 12 3/8" - 1" 3/8" - 1" MILWAUKEE M12™

ProPEX™ or Uponor Standard

Expander Cone

Grease

Cat.No. 49-08-2400

Direct Current

Underwriters Laboratories, Inc.

United States and Canada

SPECIFIC SAFETY RULES

• Use power tools only with speciﬁ cally desig-

nated battery packs. Use of any other battery

packs may create a risk of injury and ﬁ re.

• When battery pack is not in use, keep it away

from other metal objects like paper clips,

coins, keys, nails, screws, or other small metal

objects that can make a connection from one

terminal to another. Shorting the battery termi-

nals together may cause burns or a ﬁ re.

• Under abusive conditions, liquid may be eject-

ed from the battery; avoid contact. If contact

accidentally occurs, ﬂ ush with water. If liquid

contacts eyes, additionally seek medical help.

Liquid ejected from the battery may cause irritation

or burns.

SERVICE

• Have your power tool serviced by a qualiﬁ ed

repair person using only identical replacement

parts. This will ensure that the safety of the power

tool is maintained.

• Use tool only to expand PEX-a material. Other

materials may split or crack, causing leaking.

ASSEMBLY

WARNING Recharge only with the char-

ger speciﬁ ed for the battery. For speciﬁ c charg-

ing instructions, read the operator’s manual

supplied with your charger and battery.

Inserting/Removing the Battery

To remove the battery, push in the release buttons

and pull the battery pack away from the tool.

To insert the battery, slide the pack into the body of

the tool. Make sure it latches securely into place.

Changing Expander Heads

To remove an expander head, unscrew from tool

counterclockwise.

To install an expander head, screw onto tool clock-

wise. Hand tighten securely. Do not over tighten.

The expander head must ﬁ t snuggly against the

shoulder of the tool.

Fuel Gauge

To determine the amount of charge left in the bat-

tery, pull the trigger. The Fuel Gauge will light up

for 2-3 seconds.

To signal the end of charge, 1 light on the fuel gauge

will ﬂ ash for 2-3 seconds.

Trigger Lock

To lock the trigger, push the trigger lock from the

left side of the tool. The trigger will not work while the

switch is in the locked position. Lock the trigger when

storing the tool and when the tool is not in use.

To unlock the trigger, push the trigger lock from

the right side of the tool.

1. Expander head

2. Trigger

3. Trigger lock

4. LED

5. Fuel gauge

6. Belt hook

7. Expander cone

OPERATION

WARNING To reduce the risk of injury,

wear safety goggles or glasses with side

shields.

WARNING Always remove battery

pack before changing or removing acces-

sories. Only use accessories specifically

recommended for this tool. Others may be

hazardous.

CAUTION Improper lubrication (too much

or too little) may result in faulty connections,

which could result in property damage.

CAUTION Use only MILWAUKEE M12™

ProPEX™ expander heads or Uponor Stan-

dard expander heads. The use of incorrectly

sized expansion heads may result in faulty

connections, which could result in property

damage.

Making PEX Tubing Connections

To ensure a proper connection:

Remove the expander head and remove any dirt •

and debris.

Use a clean, lint-free cloth to apply a thin •

coat of MILWAUKEE Expander Cone Grease

Cat.No. 49-08-2400 to the expander cone. Do

not over-lubricate.

CAUTION When using Uponor Standard

expansion heads, properly rotate the tubing

after each expansion to create even, smooth

expansion marks. Not rotating the tubing may

cause deep grooves and faulty connections,

which could result in leaking and property

damage.

Continue until the tubing and ring are ﬂ ush with 5.

the expander head shoulder.

Remove the tubing when the segments are 6.

contracted and release the trigger. To avoid

over-expanding the tubing, do not keep tool in

the expanded position with tubing in place.

Wipe excess grease from inside tubing.7.

Slide the tubing over the ﬁ tting until it is ﬂ ush with 8.

the ﬁ tting shoulder. Connection may be tight. If

unable to slide tubing over the ﬁ tting, remove

from ﬁ tting and expand one additional time.

Tubing should ﬁ t tight against the ﬁ tting shoulder. 9.

If more than 1/16" gap between tubing and shoul-

der, cut 2" off the end of the tubing and restart

procedure with a new ProPEX™ Ring.

Ring Size Number of Expansions with Ring*

3/8" PEX 6-7

1/2" PEX 7-8

5/8" PEX 9-10

3/4" PEX 11-12

1" PEX 17-18

* Fewer or more expansions may be necessary, as

inﬂ uenced by weather and technique.

• Store tool with expander head installed to

protect expander cone from damage.

• Keep ﬁ ngers away from expander head during

use. When expander head contracts, pinching can

occur.

• Maintain labels and nameplates. These carry

important information. If unreadable or missing,

contact a MILWAUKEE service facility for a free

replacement.

• WARNING: Some dust created by power sanding,

sawing, grinding, drilling, and other construction

activities contains chemicals known to cause

cancer, birth defects or other reproductive harm.

Some examples of these chemicals are:

•lead from lead-based paint

•crystalline silica from bricks and cement and other

masonry products, and

• arsenic and chromium from chemically-treated

lumber.

Your risk from these exposures varies, depending

on how often you do this type of work. To reduce

your exposure to these chemicals: work in a well

ventilated area, and work with approved safety

equipment, such as those dust masks that are spe-

cially designed to ﬁ lter out microscopic particles.

Insert the expander head into the PEX tubing. 3.

Pull the trigger. The expander head will expand, 4.

retract, and rotate slightly in each cycle.

NOTE: When Uponor

Standard expander

heads are used, the

head will NOT rotate

automatically. Each

time the segments

contract, gently push

the tubing up onto the expander head and rotate

1/8 turn in either direction.

Do not expand tubing beyond the tool's capac-•

ity (1").

Pull trigger and verify that the expander head is •

rotating after each cycle when using MILWAUKEE

M12™ ProPEX™ expander heads.

Cut the PEX tubing to the needed length. Use 1.

only cutters designed for PEX tubing. Make

sure the cut is perpendicular to the length of

the tubing.

Slide the ProPEX2. ™ Ring over

the end of the tubing until it

butts aginst the ring stop.

If the ring does not have a

stop, leave an over-hang of

no more than 1/16". When using 3/8" ProPEX

™,

refer to "3/8" ProPEX™ Rings" for proper as-

sembly.

7ring

1/16"

tubing

Expansion

markings

inside tubing

Incorrect

Correct

Produktspezifikationen

Marke:	Milwaukee
Kategorie:	Nicht kategorisiert
Modell:	M12 2432-20

Brauchst du Hilfe?

Wenn Sie Hilfe mit Milwaukee M12 2432-20 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Milwaukee

Milwaukee M12 302-21 Bedienungsanleitung

14 Oktober 2024

Milwaukee M12 HammerVac 2306-22 Bedienungsanleitung

30 September 2024

Milwaukee M12 Fuel 2522-21XC Bedienungsanleitung

18 September 2024

Milwaukee 9689-20 Bedienungsanleitung

16 September 2024

Milwaukee M12 TOUGHSHELL 204-21 Bedienungsanleitung

14 September 2024

Milwaukee M12 FUEL 2567-22 Bedienungsanleitung

14 September 2024

Milwaukee M18 Radius ONE-KEY 2150-20 Bedienungsanleitung

4 September 2024

Milwaukee MXF041 Bedienungsanleitung

4 September 2024

Milwaukee ROLL-ON 3300R Bedienungsanleitung

4 September 2024

Milwaukee MXF NRG Bedienungsanleitung

4 September 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
