Seite 1/5
11
12
56
55
57
58
60
61
1
26
3
54
67
53
51
52(2x)
10
75
72
74
45
46
14(10x)
65
32
33
24
49
14(3x)
25
26
27
73
39
37
47
38
50
48
40
41
36(2x)
35(2x)
60
62
14 37 38
39 51
66
48 49
50 74
68
60 62
63
69
76
1 3 5
26 76
70
NOTE:
Gearcase Assembly #72
contains a series of
planetary and sun
gears that are
enclosed
here.
60
59
60
63
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
0
00
*
See detail
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 34-80-0020 Retaining Ring (1)
3 40-50-6420 Return Spring (1)
4 45-98-0275 Clutch Yoke (1)
5 --------------- Slide Clutch (1)
10 45-88-1940 Washer (1)
11 32-40-2395 Input Gear (1)
12 36-18-0610 Input Shaft (1)
14 06-82-2025 M3.5 x 15 Pan Hd. Plastite T-10 Screw (13)
24 45-24-0920 Shuttle Lock (1)
25 28-20-2540 Left Cover (1)
26 45-88-1945 Washer (2)
27 34-80-0270 Retaining Ring (1)
32 40-50-1475 Detent Spring (1)
33 43-72-0430 Detent (1)
35 45-88-1980 Spring Washer (2)
36 05-81-0205 M3 x 6 Pan Hd. Phillips Screw (2)
37 42-70-1125 Clip (1)
38 --------------- Housing-Left (1)
39 43-98-0570 Speed Dial (1)
40 34-80-1120 Retaining Ring (1)
41 32-40-0800 Input Gear (1)
45 40-50-1635 Spring (1)
46 23-38-0625 EOT Actuator (1)
47 31-01-1725 Light Pipe with fuel gauge label (1)
48 --------------- Battery Contact Plate Assembly (1)
49 --------------- Switch (1)
50 --------------- PCB Assembly (1)
51 --------------- Housing-Right (1)
52 05-88-0985 M3.5 x 26 Pan Hd. Phillips Screw (2)
53 05-88-1610 M3.5 x 10 Pan Hd. T-10 Screw (1)
55 42-52-0440 Cartridge Mounting Cap (1)
56 45-88-2640 Wave Washer (1)
57 45-88-1495 Flat Washer (1)
58 06-55-0900 Hex Nut (1)
59 44-70-0330 Plunger (1)
60 45-04-2015 M5 x .8 Flat Hd. Phillips Screw (2)
61 31-01-1910 10 Oz. Cartridge Holder (1)
54-06-2460
M12™ CORDLESS CAULK and ADHESIVE GUN
E34A2441-20 SEE PAGE 5
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 4
Feb. 2014
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
62 44-94-0490 10 Oz. Rack (1)
63 31-44-3170 Rack Handle (1)
65 42-70-0055 Housing Connection Clip (1)
66 31-44-3175 Handle Assembly (1)
67 28-20-0310 Right Cover Assembly (1)
68 23-66-3135 Switch Assembly (1)
69 44-94-0495 10 Oz. Rod Assembly (1)
70 14-08-0240 Clutch Gear Assembly (1)
72 14-30-0400 Gearcase Assembly (1)
73 14-29-0725 Output Gear Assembly (1)
74 --------------- EOT Switch (1)
75 23-30-0950 Motor Assembly with Drive Hub (1)
76 --------------- Output Gear Assembly (1)
77 12-20-2441 Service Nameplate (1)
78 10-20-3672 Warning Label (1)
See page 4
for additional
cartridge systems
42-70-0058
Improved
Design
Original
Design
42-70-0055
*
M12™ tools utilize two different Housing
Connection Clip designs depending on the
Handle Set . See page two for details.
42-70-0055
42-70-0058
42-70-0058
Recess in early handle
sets may only have the
slots to accommodate a
housing clip. Use 42-70-0055
only in this situation.
Slots
Recess in newer handle
sets have two slots, a
dimple and a tab cavity to
accommodate the newer
housing clip design.
Slots
Dimple
Tab Cavity
Updated M12™ Handle Sets utilize Housing
Connection Clips No. 42-70-0055 and 42-70-
0058. (The 42-70-0058 is a preferred upgrade).
Install this clip design by aligning the side rails
of the clip with the two slots in the handle set.
Gently push into place with the aid of a small
flat blade screwdriver or a similar instrument.
Be sure that the clip is properly seated in both
slots and that the tab of the clip snaps down in
the round dimpled cavity of the handle set. Be
sure that the clip is flush to sub-flush to the end
of the handle set. To remove the clip, use the
same small flat blade screwdriver or a similar
instrument and lift up on the clip tab while
pushing the clip out of the handle set. Use a
needle nose pliers to gently rebend the clip tab
if necessary. If the tab on the clip is damaged
during this process and is loose or will not stay
in place, replace with a new 42-70-0058 clip.
Early M12™ Handle Sets utilize Housing
Connection Clip No. 42-70-0055. Install this
clip design by aligning the side rails of the clip
with the two slots in the handle set. Gently
push into place with the aid of a small flat
blade screwdriver or a similar instrument. Be
sure that the clip is properly seated in both
slots and that the clip is flush to sub-flush to
the end of the handle set. To remove the clip,
use the same small flat blade screwdriver or a
similar instrument and push the clip out of the
handle set. If the clip is loose or will not stay in
place, a needle nose pliers can be used to
gently bend/pinch the side rails of the clip. If
the clip is damaged do not use, replace with a
new 42-70-0055 housing clip.
Slots
Dimples
Recess in this
handle set design
has slots and dimples
to secure a housing clip.
The 42-70-0055 can be
used but the 42-70-0058 is
preferred in this situation.
Newer M12™ Handle Sets utilize Housing
Connection Clip No. 42-70-0058. Install this
clip design by aligning the side rails of the clip
with the two slots in the handle set. Gently
push into place with the aid of a small flat blade
screwdriver or a similar instrument. Be sure
that the clip is properly seated in both slots and
that the tab of the clip snaps down in the
rectangular cavity of the handle set. Be sure
that the clip is flush to sub-flush to the end of
the handle set. To remove the clip, use the
same small flat blade screwdriver or a similar
instrument and lift the clip tab out of the cavity
while pushing the clip out of the handle set.
Use a needle nose pliers to gently rebend the
clip tab if necessary. If the tab on the clip is
damaged during this process and is loose or
will not stay in place, replace with a new
42-70-0058 clip.
#4
Clutch Yoke
#26
Washer
#1
Retaining
Ring
#3
Return Spring
#5 Slide Clutch
#70
Clutch Gear
Assembly
#72
Gearcase
Assembly
INSTALLING/REMOVING CLUTCH COMPONENTS
FROM GEARCASE ASSEMBLY
#39
Speed
Dial
#38
Left
Housing
Slot for light pipe
Slot for PCB assembly
#37 Clip
#47
Light Pipe
#50
PCB Assembly
Insert speed dial #39 into hole at rear of left housing halve #38. Secure dial
with clip #37. Set dial to the '1' position at the arrow in the housing. Speed
dial will turn in a counterclockwise direction.
Align board edges of PCB assembly #50 and the face plate edges of the
light pipe #47 with the slots in the housing halve.
Carefully insert the PCB assembly and light pipe into the slots. Route the
blue and black wires from the PCBA (for the EOT switch #74) into the wire
trap of handle halve above motor. Align the double fl ats of the speed dial
with the double fl ats in the hole of the potentiometer. Gently apply pressure
to engage shaft of speed dial in hole of potentiometer. Press and fully seat
PCBA and light pipe in the handle halve.
NOTE: Clutch Yoke #4 is to be the fi rst clutch component installed and the last component removed from the gearcase assembly.
Install side pins of clutch yoke #4 into the pivot sockets of the gearcase.
Insert slide clutch #5 onto clutch yoke with raised
driving lugs of the slide clutch oriented as shown.
Lugs are to face clutch gear assembly #70.
Place the return spring #3 into the recessed pocket
of the gearcase.
While holding slide clutch in place on the clutch
yoke, gently pivot the two parts into the clutch/gear
cavity of gearcase. the slide clutch may have NOTE:
to be slightly lifted out of place on the yoke during
the pivoting process to avoid any interference with
the cavity walls.
Be sure return spring is still in place in the recess
pocket of gearcase when the clutch yoke and slide
clutch are completely pivoted in place.
Press clutch yoke lever to assure proper operation
in pocket. If spring comes out of recess, start over.
Hold the lever of the clutch yoke completely down
to draw in the return spring and slide clutch. Place
shaft of the clutch gear assembly #70 through the
holes in the slide clutch and gearcase assembly.
Secure the clutch gear assembly with washer #26
and retaining ring #1.
LUBRICATION NOTES:
Type ‘P’ Grease
No. 49-08-4250, 1.5 oz. / 42g tube
Prior to reinstalling, clean gear assemblies
with a clean, dry cloth. Lightly coat all parts
highlighted here with ‘P’ grease.
