Section 16. Analog-to-Digital Converter (ADC)

HIGHLIGHTS

This section of the manual contains the following major topics:

16.1 Introduction .................................................................................................................. 16-2

16.2 Control Registers ......................................................................................................... 16-6

16.3 Overview of Sample and Conversion Sequence ....................................................... 16-17

16.4 ADC Configuration..................................................................................................... 16-27

16.5 ADC Interrupt Generation .......................................................................................... 16-33

16.6 Analog Input Selection for Conversion....................................................................... 16-35

16.7 Specifying Conversion Results Buffering for Devices with DMA................................ 16-44

16.8 ADC Configuration Example ...................................................................................... 16-48

16.9 ADC Configuration for 1.1 Msps ................................................................................16-49

16.10 Sample and Conversion Sequence Examples for Devices without DMA .................. 16-51

16.11 Sample and Conversion Sequence Examples for Devices with DMA ....................... 16-63

16.12 Analog-to-Digital Sampling Requirements ................................................................. 16-73

16.13 Reading the ADC Result Buffer .................................................................................16-74

16.14 Transfer Functions ..................................................................................................... 16-76

16.15 ADC Accuracy/Error................................................................................................... 16-78

16.16 Connection Considerations........................................................................................ 16-78

16.17 Operation During Sleep and Idle Modes .................................................................... 16-79

16.18 Effects of a Reset....................................................................................................... 16-79

16.19 Special Function Registers ........................................................................................ 16-80

16.20 Design Tips ................................................................................................................ 16-81

16.21 Related Application Notes.......................................................................................... 16-82

16.22 Revision History ......................................................................................................... 16-83

dsPIC33F/PIC24H Family Reference Manual

16.1 INTRODUCTION

This document describes the features and associated operational modes of the Successive

Approximation (SAR) Analog-to-Digital Converter (ADC) available on the dsPIC33F/PIC24H

families of devices.

The ADC module can be configured by the user application to function as a 10-bit, 4-channel

ADC (for devices with 10-bit only ADC) or a 12-bit, single-channel ADC (for devices with

selectable 10-bit or 12-bit ADC).

Figure 16-1 illustrates a block diagram of the ADC module for devices with DMA. Figure 16-2

illustrates a block diagram of the ADC module for devices without DMA.

The dsPIC33F/PIC24H ADC module has the following key features:

• SAR conversion

• Up to 1.1 Msps conversion speed

• Up to 32 analog input pins

• External voltage reference input pins

• Four unipolar differential Sample and Hold (S&H) amplifiers

• Simultaneous sampling of up to four analog input pins

• Automatic Channel Scan mode

• Selectable conversion trigger source

• Up to 16-word conversion result buffer

• Selectable Buffer Fill modes (not available on all devices)

• DMA support, including Peripheral Indirect Addressing (not available on all devices)

• Operation during CPU Sleep and Idle modes

Depending on the device variant, the ADC module may have up to 32 analog input pins,

designated AN0-AN31. These analog inputs are connected by multiplexers to four S&H

amplifiers, designated CH0-CH3. The analog input multiplexers have two sets of control bits,

designated as MUXA (CHySA/CHyNA) and MUXB (CHySB/CHyNB). These control bits select a

particular analog input for conversion. The MUXA and MUXB control bits can alternatively select

the analog input for conversion. Unipolar differential conversions are possible on all channels

using certain input pins (see Figure 16-1 Figure 16-2 and ).

Channel Scan mode can be enabled for the CH0 S&H amplifier. Any subset of the analog inputs

(AN0 to AN31 based on availability) can be selected by the user application. The selected inputs

are converted in ascending order using CH0.

The ADC module supports simultaneous sampling using multiple S&H channels to sample the

inputs at the same time, and then performs the conversion for each channel sequentially. By

default, the multiple channels are sampled and converted sequentially.

For devices with DMA, the ADC module is connected to a single-word result buffer. However,

multiple conversion results can be stored in a DMA RAM buffer with no CPU overhead when

DMA is used with the ADC module. Each conversion result is converted to one of four 16-bit

output formats when it is read from the buffer.

Note: This family reference manual section is meant to serve as a complement to device

data sheets. Depending on the device variant, this manual section may not apply to

all dsPIC33F/PIC24H devices.

Please consult the note at the beginning of the “Analog-to-Digital Converter

(ADC)” chapter in the current device data sheet to check whether this document

supports the device you are using.

Device data sheets and family reference manual sections are available for

download from the Microchip Worldwide Web site at: http://www.microchip.com

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

For devices without DMA, the ADC module is connected to a 16-word result buffer. The ADC

result is available in four different numerical formats (see Figure 16-14).

Note 1: A ‘y’ is used with MUXA and MUXB control bits to specify the S&H channel numbers

(y = 0 or 123).

2: Depending on a particular device pinout, the ADC can have up to 32 analog input

pins, designated AN0 through AN31. In addition, there are two analog input pins for

external voltage reference connections (VREF+, VREF-). These voltage reference

inputs can be shared with other analog input pins. The actual number of analog

input pins and external voltage reference input configuration depends on the

specific device. For further details, refer to the specific device data sheet.

dsPIC33F/PIC24H Family Reference Manual

Figure 16-1: ADC Block Diagram for Devices with DMA

SAR ADC

S/H0

S/H1

AN0

AN31

AN1

VREFL

CH0SB<4:0>

CH0NA CH0NB

AN0

AN3

CH123SA

AN9

VREFL

CH123SB

CH123NA CH123NB

AN6

S/H2

AN1

AN4

CH123SA

AN10

VREFL

CH123SB

CH123NA CH123NB

AN7

S/H3

AN2

AN5

CH123SA

AN11

VREFL

CH123SB

CH123NA CH123NB

AN8

CH1(2)

CH0

CH2(2)

CH3(2)

CH0SA<4:0>

CHANNEL

SCAN

CSCNA

Alternate

Note 1: VREF+, VREF- inputs can be multiplexed with other analog inputs. For details, refer to the “Pin Diagrams” section in the specific device

data sheet.

2: Channels 1, 2 and 3 are not applicable for the 12-bit mode of operation.

Input Selection

VREFH VREFL

V +REF (1) AV AVDD SS

V -REF (1)

VCFG<2:0>

Bus Interface

ADC1BUF0

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

Figure 16-2: ADC Block Diagram for Devices without DMA

SAR ADC

S/H0

S/H1

ADC1BUF0

ADC1BUF1

ADC1BUF2

ADC1BUFF

ADC1BUFE

AN0

AN31

AN1

VREFL

CH0SB<4:0>

CH0NA CH0NB

AN0

AN3

CH123SA

AN9

VREFL

CH123SB

CH123NA CH123NB

AN6

S/H2

AN1

AN4

CH123SA

AN10

VREFL

CH123SB

CH123NA CH123NB

AN7

S/H3

AN2

AN5

CH123SA

AN11

VREFL

CH123SB

CH123NA CH123NB

AN8

CH1(2)

CH0

CH2(2)

CH3(2)

CH0SA<4:0>

CHANNEL

SCAN

CSCNA

Alternate

Note 1: VREF+, VREF- inputs can be multiplexed with other analog inputs. For details, refer to the “Pin Diagrams” section in the specific device

data sheet.

2: Channels 1, 2 and 3 are not applicable for the 12-bit mode of operation.

Input Selection

VREFH VREFL

V +REF (1) AV AVDD SS

V -REF (1)

VCFG<2:0>

dsPIC33F/PIC24H Family Reference Manual

16.2 CONTROL REGISTERS

The ADC module has ten Control and Status registers. These registers are:

•ADxCON1: ADCx Control Register 1

•ADxCON2: ADCx Control Register 2

•ADxCON3: ADCx Control Register 3

•ADxCON4: ADCx Control Register 4

•ADxCHS123: ADCx Input Channel 1, 2, 3 Select Register

•ADxCHS0: ADCx Input Channel 0 Select Register

•AD1CSSH: ADC1 Input Scan Select Register High

•ADxCSSL: ADCx Input Scan Select Register Low

•AD1PCFGH: ADC1 Port Configuration Register High

•ADxPCFGL: ADCx Port Configuration Register Low

The ADxCON1, ADxCON2 and ADxCON3 registers control the operation of the ADC module.

The ADxCON4 register sets up the number of conversion results stored in a DMA buffer for each

analog input in the Scatter/Gather mode for devices with DMA. The ADxCHS123 and ADxCHS0

registers select the input pins to be connected to the S&H amplifiers. The ADCSSH/L registers

select inputs to be sequentially scanned. The ADxPCFGH/L registers configure the analog input

pins as analog inputs or as digital I/O.

16.2.1 ADC Result Buffer

For devices with DMA, the ADC module contains a single-word result buffer, ADC1BUF0. For

devices without DMA, the ADC module contains a 16-word dual-port RAM, to buffer the results.

The 16 buffer locations are referred to as ADC1BUF0, ADC1BUF1, ADC1BUF2, ..., ADC1BUFE

and ADC1BUFF.

Note: After a device reset, the ADC buffer register(s) will contain unknown data.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

R/W-0 U-0 R/W-0 R/W-0 U-0 R/W-0 R/W-0 R/W-0

ADON — ADSIDL ADDMABM(2) — AD12B(2) FORM<1:0>

bit 15 bit 8

R/W-0 R/W-0 R/W-0 U-0 R/W-0 R/W-0 R/W-0

HC,HS

R/C-0

HC, HS

SSRC<2:0> — SIMSAM ASAM SAMP DONE

bit 7 bit 0

Legend: HC = Cleared by hardware HS = Set by hardware C = Clear only bit

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15 ADON: ADC Operating Mode bit

1 = ADC module is operating

0 = ADC is off

bit 14 Unimplemented: Read as ‘0’

bit 13 ADSIDL: Stop in Idle Mode bit

1 = Discontinue module operation when device enters Idle mode

0 = Continue module operation in Idle mode

bit 12 ADDMABM: DMA Buffer Build Mode bit(3)

1 = DMA buffers are written in the order of conversion. The module provides an address to the DMA

channel that is the same as the address used for the non-DMA stand-alone buffer

0 = DMA buffers are written in Scatter/Gather mode. The module provides a Scatter/Gather address to

the DMA channel, based on the index of the analog input and the size of the DMA buffer

bit 11 Unimplemented: Read as ‘0’

bit 10 AD12B: 10-bit or 12-bit Operation Mode bit(2)

1 = 12-bit, 1-channel ADC operation

0 = 10-bit, 4-channel ADC operation

bit 9-8 FORM<1:0>: Data Output Format bits

For 10-bit operation:

11 sddd dddd dd00 0000 = Signed fractional (DOUT = , where s d = sign, = data)

10 = Fractional (DOUT = dddd dddd dd00 0000)

01 ssss sssd dddd dddd = Signed integer (DOUT = , where s d = sign, = data)

00 = Integer (DOUT = 0000 00dd dddd dddd)

For 12-bit operation:

11 sddd dddd dddd 0000 = Signed fractional (DOUT = , where s d = sign, = data)

10 = Fractional (DOUT = dddd dddd dddd 0000)

01 ssss sddd dddd dddd = Signed Integer (DOUT = , where s = sign, d = data)

00 = Integer (DOUT = 0000 dddd dddd dddd)

bit 7-5 SSRC<2:0>: Sample Clock Source Select bits

111 = Internal counter ends sampling and starts conversion (auto-convert)

110 = Reserved

101 = Motor Control PWM2 interval ends sampling and starts conversion(1)

100 = GP timer (Timer5 for ADC1, Timer3 for ADC2) compare ends sampling and starts conversion

(2)

011 = Motor Control PWM1 interval ends sampling and starts conversion(1)

010 = GP timer (Timer3 for ADC1, Timer5 for ADC2) compare ends sampling and starts conversion

001 = Active transition on INT0 pin ends sampling and starts conversion

000 = Clearing sample bit ends sampling and starts conversion

bit 4 Unimplemented: Read as ‘0’

Note 1: This clock source is not available on all devices. Refer to the specific device data sheet for availability.

2: This bit is not available on all devices. Refer to the “Analog-to-Digital Converter” chapter in the specific

device data sheet for availability.

dsPIC33F/PIC24H Family Reference Manual

bit 3 SIMSAM: Simultaneous Sample Select bit (only applicable when CHPS<1:0> = 01 1x or )

When AD12B = 1, SIMSAM is: U-0, Unimplemented, Read as ‘0’

1 = Samples CH0, CH1, CH2, CH3 simultaneously (when CHPS<1:0> = 1x); or

Samples CH0 and CH1 simultaneously (when CHPS<1:0> = 01)

0 = Samples multiple channels individually in sequence

bit 2 ASAM: ADC Sample Auto-Start bit

1 = Sampling begins immediately after last conversion. SAMP bit is auto-set

0 = Sampling begins when SAMP bit is set

bit 1 SAMP: ADC Sample Enable bit

1 = ADC S&H amplifiers are sampling

0 = ADC S&H amplifiers are holding

If ASAM = 0, software can write ‘1’ to begin sampling. Automatically set by hardware if ASAM = 1.

If SSRC = 000, software can write ‘0’ to end sampling and start conversion. If SSRC ≠ 000,

automatically cleared by hardware to end sampling and start conversion.

bit 0 DONE: ADC Conversion Status bit

1 = ADC conversion cycle is completed

0 = ADC conversion not started or in progress

Automatically set by hardware when analog-to-digital conversion is complete. Software can write ‘0’ to

clear DONE status (software not allowed to write ‘1’). Clearing this bit does NOT affect any operation

in progress. Automatically cleared by hardware at the start of a new conversion.

Note 1: This clock source is not available on all devices. Refer to the specific device data sheet for availability.

2: This bit is not available on all devices. Refer to the “Analog-to-Digital Converter” chapter in the specific

device data sheet for availability.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

R/W-0 R/W-0 R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0

VCFG<2:0> — — CSCNA CHPS<1:0>

bit 15 bit 8

R-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

BUFS — SMPI<3:0>(1,2) BUFM ALTS

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15-13 VCFG<2:0>: Converter Voltage Reference Configuration bits

bit 12-11 Unimplemented: Read as ‘0’

bit 10 CSCNA: Input Scan Select bit

1 = Scan inputs for CH0+ during Sample A bit

0 = Do not scan inputs

bit 9-8 CHPS<1:0>: Channel Select bits

When AD12B = 1, CHPS<1:0> is: U-0, Unimplemented, Read as ‘0’

1x = Converts CH0, CH1, CH2 and CH3

01 = Converts CH0 and CH1

00 = Converts CH0

bit 7 BUFS: Buffer Fill Status bit (only valid when BUFM = 1)

1 = ADC is currently filling the second half of the buffer. The user application should access data in the

first half of the buffer

0 = ADC is currently filling the first half of the buffer. The user application should access data in the

second half of the buffer

bit 6 Unimplemented: Read as ‘0’

Note 1: For devices with DMA, the SMPI<3:0> bits are referred to as the Increment Rate for DMA Address Select

bits.

2: For devices without DMA, the SMPI<3:0> bits are referred to as the Number of Samples Per Interrupt

Select bits.

3: The VREF+ and VREF- pins are not available on all devices. Refer to the “Pin Diagrams” section in the

specific device data sheet for availability.

VREFH VREFL

000 AVDD AVss

001 External VREF+(3) AVss

010 AVDD External VREF-(3)

011 External VREF+(3) External VREF-(3)

1xx AVDD AVss

dsPIC33F/PIC24H Family Reference Manual

bit 5-2 SMPI<3:0>: Sample and Conversion Operation bits(1,2)

For devices with DMA:

1111 = Increments the DMA address after completion of every 16th sample/conversion operation

1110 = Increments the DMA address after completion of every 15th sample/conversion operation

•

0001 = Increments the DMA address after completion of every 2nd sample/conversion operation

0000 = Increments the DMA address after completion of every sample/conversion operation

For devices without DMA:

1111 = ADC interrupt is generated at the completion of every 16th sample/conversion operation

1110 = ADC interrupt is generated at the completion of every 15th sample/conversion operation

•

0001 = ADC interrupt is generated at the completion of every 2nd sample/conversion operation

0000 = ADC interrupt is generated at the completion of every sample/conversion operation

bit 1 BUFM: Buffer Fill Mode Select bit

1 = Starts filling the first half of the buffer on the first interrupt and the second half of the buffer on the

next interrupt

0 = Always starts filling the buffer from the start address

bit 0 ALTS: Alternate Input Sample Mode Select bit

1 = Uses channel input selects for Sample A on first sample and Sample B on next sample

0 = Always uses channel input selects for Sample A

Note 1: For devices with DMA, the SMPI<3:0> bits are referred to as the Increment Rate for DMA Address Select

bits.

2: For devices without DMA, the SMPI<3:0> bits are referred to as the Number of Samples Per Interrupt

Select bits.

3: The VREF+ and VREF- pins are not available on all devices. Refer to the “Pin Diagrams” section in the

specific device data sheet for availability.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

ADRC — — SAMC<4:0>(1,2)

bit 15 bit 8

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

ADCS<7:0>

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15 ADRC: ADC Conversion Clock Source bit

1 = ADC Internal RC Clock

0 = Clock Derived from System Clock

bit 14-13 Unimplemented: Read as ‘0’

bit 12-8 SAMC<4:0>: Auto Sample Time bits(1,2)

11111 = 31 TAD

•

00001 = 1 T

00000 = 0 TAD

bit 7-0 ADCS<7:0>: ADC Conversion Clock Select bits

11111111 = Reserved

•

01000000 = Reserved

00111111 = TCY · (ADCS<7:0> + 1) = 64 · TCY = TAD

•

00000010 = TCY · (ADCS<7:0> + 1) = 3 · TCY = TAD

00000001 = TCY · (ADCS<7:0> + 1) = 2 · TCY = TAD

00000000 = TCY · (ADCS<7:0> + 1) = 1 · TCY = TAD

Note 1: This bit is only used when the SSRC<2:0> bits (ADxCON1<7:5>) = 111.

2: If SSRC<2:0> = 111, the SAMC bit should be set to at least ‘1’ when using one S&H channel or using

simultaneous sampling. When using multiple S&H channels with sequential sampling, the SAMC bit

should be set to ‘0’ for the fastest possible conversion rate.

dsPIC33F/PIC24H Family Reference Manual

U-0 U-0 U-0 U-0 U-0 U-0 U-0 U-0

— — — — — — — —

bit 15 bit 8

U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-0 R/W-0

— — — — — DMABL<2:0>

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15-3 Unimplemented: Read as ‘0’

bit 2-0 DMABL<2:0>: DMA Buffer Locations per Analog Input bits

111 = Allocates 128 words of buffer to each analog input

110 = Allocates 64 words of buffer to each analog input

101 = Allocates 32 words of buffer to each analog input

100 = Allocates 16 words of buffer to each analog input

011 = Allocates 8 words of buffer to each analog input

010 = Allocates 4 words of buffer to each analog input

001 = Allocates 2 words of buffer to each analog input

000 = Allocates 1 word of buffer to each analog input

Note: This register is not available in devices without DMA. Refer to the “Direct Memory Access (DMA)”

chapter in the specific device data sheet for availability.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-0 R/W-0

— — — — — CH123NB<1:0> CH123SB

bit 15 bit 8

U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-0 R/W-0

— — — — — CH123NA<1:0> CH123SA

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15-11 Unimplemented: Read as ‘0’

bit 10-9 CH123NB<1:0>: Channel 1, 2, 3 Negative Input Select for Sample B bits

When AD12B = 1, CHxNB is: U-0, Unimplemented, Read as ‘0’

11 = CH1 negative input is AN9, CH2 negative input is AN10, CH3 negative input is AN11

10 = CH1 negative input is AN6, CH2 negative input is AN7, CH3 negative input is AN8

0x = CH1, CH2, CH3 negative input is V

REFL

bit 8 CH123SB: Channel 1, 2, 3 Positive Input Select for Sample B bit

When AD12B = 1, CHxSA is: U-0, Unimplemented, Read as ‘0’

1 = CH1 positive input is AN3, CH2 positive input is AN4, CH3 positive input is AN5

0 = CH1 positive input is AN0, CH2 positive input is AN1, CH3 positive input is AN2

bit 7-3 Unimplemented: Read as ‘0’

bit 2-1 CH123NA<1:0>: Channel 1, 2, 3 Negative Input Select for Sample A bits

When AD12B = 1, CHxNA is: U-0, Unimplemented, Read as ‘0’

11 = CH1 negative input is AN9, CH2 negative input is AN10, CH3 negative input is AN11

10 = CH1 negative input is AN6, CH2 negative input is AN7, CH3 negative input is AN8

0x = CH1, CH2, CH3 negative input is V

REFL

bit 0 CH123SA: Channel 1, 2, 3 Positive Input Select for Sample A bit

When AD12B = 1, CHxSA is: U-0, Unimplemented, Read as ‘0’

1 = CH1 positive input is AN3, CH2 positive input is AN4, CH3 positive input is AN5

0 = CH1 positive input is AN0, CH2 positive input is AN1, CH3 positive input is AN2

dsPIC33F/PIC24H Family Reference Manual

R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CH0NB — — CH0SB<4:0>(1)

bit 15 bit 8

R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CH0NA — — CH0SA<4:0>(1,2)

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15 CH0NB: Channel 0 Negative Input Select for Sample B bit

Same definition as bit 7.

bit 14-13 Unimplemented: Read as ‘0’

bit 12-8 CH0SB<4:0>: Channel 0 Positive Input Select for Sample B bits

(1)

Same definition as bit<4:0>.

bit 7 CH0NA: Channel 0 Negative Input Select for Sample A bit

1 = Channel 0 negative input is AN1

0 = Channel 0 negative input is V

REFL

bit 6-5 Unimplemented: Read as ‘0’

bit 4-0 CH0SA<4:0>: Channel 0 Positive Input Select for Sample A bits(1,2)

11111 = Channel 0 positive input is AN31

11110 = Channel 0 positive input is AN30

•

00010 = Channel 0 positive input is AN2

00001 = Channel 0 positive input is AN1

00000 = Channel 0 positive input is AN0

Note 1: The AN16 through AN31 pins are not available for ADC2.

2: These bits have no effect when the CSCNA bit (ADxCON2<10>) = 1.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CSS31 CSS30 CSS29 CSS28 CSS27 CSS26 CSS25 CSS24

bit 15 bit 8

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CSS23 CSS22 CSS21 CSS20 CSS19 CSS18 CSS17 CSS16

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15-0 CSS<31:16>: ADC Input Scan Selection bits

(1,2)

1 = Select ANx for input scan

0 = Skip ANx for input scan

Note 1: ADC2 only supports analog inputs AN0-AN15; therefore, no ADC2 Input Scan Select Register High exists.

2: A maximum of 16 inputs (any) can be scanned.

Note: This register is not available in devices without DMA. Refer to the “Analog-to-Digital Converter (ADC)”

chapter in the specific device data sheet for availability.

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CSS15(3) CSS14(3) CSS13(3) CSS12 CSS11 CSS10 CSS9 CSS8

bit 15 bit 8

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

CSS7 CSS6 CSS5 CSS4 CSS3 CSS2 CSS1 CSS0

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 15-0 CSS<15:0>: ADC Input Scan Selection bits(1,2)

1 = Select ANx for input scan

0 = Skip ANx for input scan

Note 1: On devices with less than 16 analog inputs, all ADxCSSL bits can be selected by the user. However,

inputs selected for scan without a corresponding input on device convert VREF-.

2: A maximum of 16 inputs (any) can be scanned.

3: This bit is not available in devices without DMA. Refer to the “Analog-to-Digital Converter (ADC)”

chapter in the specific device data sheet for availability.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

16.3 OVERVIEW OF SAMPLE AND CONVERSION SEQUENCE

Figure 16-3 illustrates that the analog-to-digital conversion is a three step process:

1. The input voltage signal is connected to the sample capacitor.

2. The sample capacitor is disconnected from the input.

3. The stored voltage is converted to equivalent digital bits.

The two distinct phases, sample and conversion, are independently controlled.

Figure 16-3: Sample Conversion Sequence

16.3.1 Sample Time

Sample Time is when the selected analog input is connected to the sample capacitor. There is a

minimum sample time to ensure that the S&H amplifier provides a desired accuracy for the

analog-to-digital conversion (see 16.12 “Analog-to-Digital Sampling Requirements”).

The sampling phase can be set up to start automatically upon conversion or by manually setting

the Sample bit (SAMP) in the ADC Control Register 1 (ADxCON1<1>). The sampling phase is

controlled by the Auto-Sample bit (ASAM) in the ADC Control Register 1 (ADxCON1<2>).

Table 16-1 lists the options selected by the specific bit configuration.

Table 16-1: Start of Sampling Selection

If automatic sampling is enabled, the sampling time (TSMP) taken by the ADC module is equal to

the number of TAD cycles defined by the SAMC<4:0> bits (ADxCON3<12:8>), as shown by

Equation 16-1.

Equation 16-1: Sampling Time Calculation

If manual sampling is desired, the user software must provide sufficient time to ensure adequate

sampling time.

SAR

ADC

Sample Time Conversion Time

SOC

Trigger

Note: The ADC module requires a finite number of analog-to-digital clock cycles to start

conversion after receiving a conversion trigger or stopping the sampling process.

Refer to the TPCS parameter in the “Electrical Characteristics” chapter of the spe-

cific device data sheet for further details.

ASAM Start of Sampling Selection

0Manual sampling

1Automatic sampling

TSMP = SAMC<4:0> • TAD

dsPIC33F/PIC24H Family Reference Manual

16.3.2 Conversion Time

The Start of Conversion (SOC) trigger ends the sampling time and begins an analog-to-digital

conversion. During the conversion period, the sample capacitor is disconnected from the

multiplexer, and the stored voltage is converted to equivalent digital bits. The conversion time for

10-bit and 12-bit modes are shown in Equation 16-2 and Equation 16-3. The sum of the sample

time and the analog-to-digital conversion time provide the total conversion time.

For correct analog-to-digital conversion, the analog-to-digital conversion clock (TAD) must be

selected to ensure a minimum TAD time. Refer to the “Electrical Characteristics” chapter of the

specific device data sheet for the minimum TAD specifications for 10-bit and 12-bit modes.

Equation 16-2: 10-bit ADC Conversion Time

Equation 16-3: 12-bit ADC Conversion Time

The SOC can be triggered by a variety of hardware sources or controlled manually in user soft-

ware. The trigger source to initiate conversion is selected by the SOC Trigger Source Select bits

(SSRC<2:0>) in the ADC Control register (ADxCON1<7:5>). Table 16-2 lists the conversion

trigger source selection for different bit settings.

Table 16-2: SOC Trigger Selection

Table 16-3 lists the sample conversion sequence with different sample and conversion phase

selections.

Note: 12-bit mode is not available on all devices. Refer to the “Analog-to-Digital

Converter (ADC)” chapter in the specific device data sheet for availability.

TCONV = 12 • TAD

Where:

TCONV = Conversion Time

TAD = ADC Clock Period

Where:

TCONV = Conversion Time

TCONV = 14 • TAD

TAD = ADC Clock Period

SSRC<2:0>(1) SOC Trigger Source

000 Manual Trigger

001 External Interrupt Trigger (INT0)

010 Timer Interrupt Trigger

011 Motor Control PWM Special Event Trigger

100 Timer Interrupt Trigger

111 Automatic Trigger

Note 1: The SSRC<2:0> selection bits should not be changed when the ADC module is

enabled.

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

16.3.5 Automatic Sample and Automatic Conversion Sequence

16.3.5.1 CLOCKED CONVERSION TRIGGER

The Auto Conversion method provides a more automated process to sample and convert the

analog inputs as shown in Figure 16-6. The sampling period is self-timed and the conversion

starts automatically upon termination of a self-timed sampling period. The Auto Sample Time bits

(SAMC<4:0>) in the ADxCON3 register (ADxCON3<12:8>) select 0 to 31 ADC clock cycles (TAD)

for sampling period. Refer to the ecific device data“Electrical Characteristics” chapter of the sp

sheet for a minimum recommended sampling time (SAMC value).

The SSRC<2:0> bits are set to ‘ ’ to choose the internal counter as the sample clock source,111

which ends sampling and starts conversion.

Figure 16-6: Automatic Sample and Automatic Conversion Sequence

Sample Time Conversion Time

SAMP

Sample Time

3 4

Conversion

Note 1: Sampling starts automatically after conversion.

2: Conversion starts automatically upon termination of self timed sampling period.

3: Sampling starts automatically after conversion.

4: Conversion starts automatically upon termination of self timed sampling period.

N • TAD N • TAD

Conversion

Section 16. Analog-to-Digital Converter (ADC)

Analog-to-Digital

Converter (ADC)

16.3.6 Multi-Channel Sample Conversion Sequence

Multi-channel ADC modules typically convert each input channel sequentially using an input

multiplexer. Simultaneously sampling multiple signals ensures that the snapshot of the analog

inputs occurs at precisely the same time for all inputs, as shown in Figure 16-8.

Certain applications require simultaneous sampling, especially when phase information exists

between different channels. Sequential sampling takes a snapshot of each analog input just

before conversion starts on that input, as shown in Figure 16-8. The sampling of multiple inputs

is not correlated. For example, motor control and power monitoring require voltage and current

measurements and the phase angle between them.

Figure 16-8: Simultaneous and Sequential Sampling

Figure 16-9 and Figure 16-10 illustrate the ADC module supports simultaneous sampling using

two S&H or four S&H channels to sample the inputs at the same instant and then perform the

conversion for each channel sequentially.

The Simultaneous Sampling mode is selected by setting Simultaneous Sampling bit (SIMSAM)

in the ADC Control Register 1 (ADxCON1<3>). By default, the channels are sampled and

converted sequentially. Table 16-4 lists the options selected by a specific bit configuration. The

CHPS<1:0> bits determine the channels to be sampled, either sequentially or simultaneously.

Table 16-4: Start of Sampling Selection

SIMSAM Sampling Mode

0Sequential sampling

1Simultaneous sampling

AN0

AN1

AN2

AN3

Simultaneous

Sampling

Sequential

Sampling

dsPIC33F/PIC24H Family Reference Manual

Figure 16-9: 2-Channel Simultaneous Sampling (ASAM = 1)

For simultaneous sampling, the total time taken to sample and convert the channels is shown by

Equation 16-4.

Equation 16-4: Channel Sample and Conversion Total Time, Simultaneous Sampling

Selected

Sample 1

CH0

CH1

Convert 1

SOC

Trigger

Sample 2

Convert 2

Sample/Convert Sequence 1 Sample/Convert Sequence 2

2 43

Note 1: CH0-CH1 Input multiplexer selects analog input for sampling. The selected analog input

is connected to the sample capacitor.

2: On SOC Trigger, CH0-CH1 sample capacitor is disconnected from the multiplexer to

simultaneously sample the analog inputs. The analog value captured in CH0 is

converted to equivalent digital bits.

3: The analog voltage captured in CH1 is converted to equivalent digital bits.

4: CH0-CH1 Input multiplexer selects next analog input for sampling. The selected analog

input is connected to the sample capacitor.

5: On SOC Trigger, CH0-CH1 sample capacitor is disconnected from the multiplexer to

simultaneously sample the analog inputs. The analog value captured in CH0 is

converted to equivalent digital bits.

TSIM TSIM

TS I M TS M P M TC ONV

⋅( )+=

Where:

TSIM = Total time to sample and convert multiple channels with simultaneous sampling.

TSMP = Sampling Time (see Equation 16-1)

TCONV = Conversion Time (see Equation 16-2)

M = Number of channels selected by the CHPS<1:0> bits.

Produktspezifikationen

Marke:	Microchip
Kategorie:	Nicht kategorisiert
Modell:	PIC24HJ128GP210A

Brauchst du Hilfe?

Wenn Sie Hilfe mit Microchip PIC24HJ128GP210A benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Microchip

Microchip ATECC608B Bedienungsanleitung

5 September 2024

Microchip HV860 Bedienungsanleitung

5 September 2024

Microchip EVB-LAN9255 Bedienungsanleitung

5 September 2024

Microchip LX4580 Bedienungsanleitung

5 September 2024

Microchip LX7720 Bedienungsanleitung

5 September 2024

Microchip MIC24067 Bedienungsanleitung

28 August 2024

Microchip MIC24066 Bedienungsanleitung

28 August 2024

Microchip LAN8671 Bedienungsanleitung

27 August 2024

Microchip PIC32CX1025SG60128 Bedienungsanleitung

24 August 2024

Microchip TC1016 Bedienungsanleitung

24 August 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

BEKO BBVM17400B Bedienungsanleitung

4 Dezember 2024

DeWalt DXV34PTA Bedienungsanleitung

4 Dezember 2024

DeWalt DCF414 Bedienungsanleitung

4 Dezember 2024

DeWalt DXIRFFP25 Bedienungsanleitung

4 Dezember 2024

DeWalt DXIR1A1A2P3 Bedienungsanleitung

4 Dezember 2024

DeWalt DCE450 Bedienungsanleitung

4 Dezember 2024

DeWalt DCMAS5713 Bedienungsanleitung

4 Dezember 2024

DeWalt DCMASBC1 Bedienungsanleitung

4 Dezember 2024

DeWalt DXKH180E Bedienungsanleitung

4 Dezember 2024

DeWalt DWE46150 Bedienungsanleitung

4 Dezember 2024
